Descripción
1.53 inch Circular Tft Screen Description
1.53 inch circular TFT screen with IPS wide viewing angle, featuring excellent display performance. It is suitable for consumer electronics, such as knob screens, data monitoring, etc.
15-year LCD factory direct sales. We have extensive experience in R&D and manufacturing of small-size, medium and large-size LCD screens. With reasonable prices, a one-year warranty, and professional R&D capabilities to solve technical issues.
1.53" LCD Display Specifications
| Número de modelo | R153G3D-003 |
|---|---|
| Talla | 1.53 |
| Resolución | 366*366 |
| Contorno Dimensión | 40.47*41.87*1.56 |
| Área activa | 38.16*38.16 |
| Brillo(cd/m²) | 300 |
| Interfaz | SPI |
| Ver Dirección | IPS |
| Temperatura de funcionamiento | -20~60 |
| Temperatura de almacenamiento | -20~70 |
| Vida útil del LED | 20000 |
| Soporte de pantalla táctil | No |
| Relación de contraste | 500:1 |
| Fuente de alimentación | 3.3V |
| Tipo de pantalla | LCD en color |
3.5" Round Display Custom Solutions

Optimice sus soluciones de cableado
Ajuste la longitud, la posición y el pinout de sus cables, o añada conectores adicionales para mejorar la funcionalidad. Obtenga una solución de cable personalizada diseñada para agilizar sus conexiones y garantizar un rendimiento seguro y fiable.

Personalización de la interfaz LCD
Seleccione entre una amplia gama de opciones de interfaz o consulte a nuestros expertos para encontrar la ideal para su proyecto. Podemos integrar HDMI, USB, SPI, VGA y más en su pantalla, ayudándole a cumplir sus objetivos de diseño de forma eficiente.

Mejore la experiencia del usuario con la tecnología de pantalla táctil
Mejore su experiencia de usuario con tecnología de pantalla táctil capacitiva o resistiva. Personalizaremos el grosor del cristal y la forma del panel táctil para garantizar un ajuste perfecto a sus requisitos de diseño.

Tapa de cristal a medida
Equipe su pantalla con una cubierta de cristal cortada a medida para aumentar la durabilidad y el rendimiento. Elija entre varios grosores y opte por la adhesión óptica para protegerla de la humedad y la suciedad, garantizando una solución duradera y fiable.
1.53-Inch Round LCD Display FAQ
Will the bezel cover any of my dial labels or icons?
Use the 1.53-inch diagonal to shortlist round displays, then check the exact drawing for fit. Make a mask from the active circle and bezel drawing. Get the native pixel layout first, then try your dial, long labels and controls with the mask applied at that layout before committing to the enclosure.
How do I check that the driver and artwork align with the visible circle?
For the listed SPI interface, check the exact controller, SPI mode, logic levels and update time with a representative screen. Check orientation and any address-window offsets in the initialization code, then show a marked test grid to verify the center and edge alignment.
Should I choose a round display or place a rectangular display behind a round bezel?
Compare the visible arc, text clipping, module clearance and flex routing for both approaches. Use the listed 300 cd/m² to shortlist the display, then judge the assembled product with its final cover and ambient lighting. A mock-up with your longest labels will show how much of the nominal screen you can actually use.
Can I add custom cover glass, change the flex cable, or add touch?
Send the visible circle, cover outline and thickness, desired flex exit and touch interface. We can evaluate a cover-only design and a separate touch assembly around the panel.
What affects the cost and lead time of a custom round display sample?
Include your cover drawing, host board, sample quantity and annual volume. We can quote the proposed changes, any one-time tooling or engineering, sample price and production MOQ separately. Ask for distinct sample and production lead times on the quoted drawing revision.
Información complementaria
| Tamaño: | |
|---|---|
| Resolución: | |
| Interfaz: | |
| Temperatura de funcionamiento: | -0℃~60℃ |
| Brillo (cd/m²): | 300 |
| Compatible con pantallas táctiles: | |
| Tipo de pantalla: |
