10.1 Inch 800×1280 Portrait LVDS IPS LCD Display Module

SKU: DS20348
Tamaño:

Resolución:

Interfaz:

Temperatura de funcionamiento:

-0℃~60℃

Brillo (cd/m²):

250

Compatible con pantallas táctiles:

Tipo de pantalla:

Cost-effective 10.1" 800x1280 portrait IPS LCD with LVDS interface. Unlike standard MIPI portrait displays, our LVDS design cuts BOM cost sharply. Ideal for industrial, medical & smart home HMI.

Solicitar precios por volumen







    Descripción

    10.1-inch portrait (vertical) panels Key Advantages

    In the display industry, 10.1-inch portrait (vertical) panels almost universally use a MIPI interface. MIPI requires more complex driver ICs, higher PCB layer counts, and additional signal-conditioning components — all of which add cost. The MQ101R1120H01 was engineered from the ground up with an LVDS interface, leveraging mature, low-cost LVDS driver infrastructure while maintaining full 800×1280 portrait resolution. The result: a vertically oriented display that costs substantially less than comparable MIPI alternatives, without compromising optical performance.



    Technical Specifications

    Número de modelo MQ101R1120H01
    Talla 10,1 pulgadas
    Resolución 800(RGB)*1280
    Contorno Dimensión 143.1 (H) × 228.55 (V) × 2.50 (D)
    Área activa 135.36 (H) × 216.58 (V)
    Brillo(cd/m²) 250
    Interfaz 6-bit / 8-bit LVDS
    Ver Dirección IPS
    Temperatura de funcionamiento -0~60
    Temperatura de almacenamiento -20~70
    Vida útil del LED 30000
    Soporte de pantalla táctil A medida
    Relación de contraste 800:1
    Fuente de alimentación 12V
    Tipo de pantalla LCD en color

    10.1" TFT Custom Solutions

    Optimice sus soluciones de cableado

    Ajuste la longitud, la posición y el pinout de sus cables, o añada conectores adicionales para mejorar la funcionalidad. Obtenga una solución de cable personalizada diseñada para agilizar sus conexiones y garantizar un rendimiento seguro y fiable.

    Personalización de la interfaz LCD

    Seleccione entre una amplia gama de opciones de interfaz o consulte a nuestros expertos para encontrar la ideal para su proyecto. Podemos integrar HDMI, USB, SPI, VGA y más en su pantalla, ayudándole a cumplir sus objetivos de diseño de forma eficiente.

    Mejore la experiencia del usuario con la tecnología de pantalla táctil

    Mejore su experiencia de usuario con tecnología de pantalla táctil capacitiva o resistiva. Personalizaremos el grosor del cristal y la forma del panel táctil para garantizar un ajuste perfecto a sus requisitos de diseño.

    custom touch

    Tapa de cristal a medida

    Equipe su pantalla con una cubierta de cristal cortada a medida para aumentar la durabilidad y el rendimiento. Elija entre varios grosores y opte por la adhesión óptica para protegerla de la humedad y la suciedad, garantizando una solución duradera y fiable.

    10.1-Inch 800 × 1280 LVDS LCD Display Module FAQ

    Will this display fit my enclosure and show the whole interface?

    Use the 10.1-inch diagonal to shortlist display modules, then check the exact drawing for fit. Overlay the visible area, module outline and flex exit on your enclosure drawing. Try your menus and text on a 800 × 1280 canvas before committing to the enclosure.

    What must my controller support to drive this display module?

    For the listed LVDS interface, match the connector pinout, channel count, data mapping and panel supply before applying power. Before connecting it, check the power rails and reset sequence in the module documentation.

    How should I compare this display with a similar module for my device?

    For the listed LCD, compare viewing-angle shifts and dark-screen appearance through the front cover. Use the listed 250 cd/m² to shortlist the display, then judge the assembled product with its final cover and ambient lighting. Compare the cost and space of any changes to the cable, host board or front cover.

    Can I change the flex cable, add a cover, or integrate touch?

    Send us the mounting drawing, permitted flex exit, connector and cover or touch requirements. We can review which of those changes can be made around the existing display and which require a different module.

    What determines the cost and lead time of a custom display sample?

    Include your display outline, interface, target sample date and estimated annual volume. We can quote the proposed changes, any one-time tooling or engineering, sample price and production MOQ separately. Ask for distinct sample and production lead times on the quoted drawing revision.
