23.1 inch Shelf Strip Screen Android OS Interface USB/DC IN

SKU: DS30048
Tamaño:

Resolución:

Interfaz:

,

Compatible con pantallas táctiles:

abc

23.1 inch Shelf Strip Screen, Offering resolution 1920*158, Play in landscape or portrait mode, Featured IPS panel, One monitor split screen, Various sizes

Solicitar precios por volumen







    Descripción

    23.1 inch Shelf Strip Screen main features:

    • Horizontal and vertical playback, switch at will, suitable for different installation requirements, horizontal and vertical screen placement two display modes.
    • Intelligent split-screen playback, can play multiple pictures and videos at the same time, the split-screen area can be adjusted at will.
    • Smart shelves and shelf strip screens can be used for smart shelf solutions in the new retail environment. Through the remote platform, unified remote publishing and management of product electronic tags can be achieved. At the same time, product advertising content can be displayed to enhance visual performance and help promote products.
    23.1 Shelf strip screen



    23.1 inch Shelf Strip Screen specification
    Display Tamaño de la pantalla 23,1 pulgadas
    Área activa 585.6(H)X48.19(V)
    Esquema 597.4*60.4*15
    Tipo de pantalla a-Si TFT-LCD
    Número de píxeles 1920*158
    Relación de aspecto 16:1
    Luminancia 400 cd/m2
    Relación de contraste 3000:1
    Ángulo de visión 89/89/89/89 (Typ.)(CR≥10)
    Profundidad de color  16.7M    68% NTSC
    Respuesta 8 (Typ.)(G to G) ms
    Paso de píxeles 0.305×0.305 mm
    Placa base CPU RK PX30
    Ram 1G(optional)
    Flash 8G(optional)
    O/S 7.1
    Interfaz USB/DC IN
    Máquina Aspecto y estructura Chapa metálica
    Color Black(optional)
    Periférico
    Alimentación DC12V 2A
    Consumo de energía ≦15W
    Temperatura de funcionamiento 0℃~50℃
    Temperatura de almacenamiento -20℃~60℃
    Tamaño Corton
    Método de instalación Colgante de pared
    Peso neto 1Kg
    Dimensiones del producto 23.1 inch shelf edge lcd display

    Descargar

    23.1-Inch 1920 × 158 Monitor FAQ

    Will this monitor fit with the cables and controls accessible?

    Use the 23.1-inch diagonal to shortlist monitors, then check the exact drawing for fit. Compare the case depth, mount or stand, cable bend and access to the controls against your setup. Test the actual cable exit before approving a tight installation.

    Industrial touch monitor selection guide

    Can my computer, media player, or controller run this monitor?

    For the listed USB interface, verify the port’s role, driver support and power needs on the exact configuration.

    How should I compare this monitor with another for my installation?

    Try your typical desktop, menu or signage layout on a 1920 × 158 canvas before choosing a monitor. Compare readable text size at the intended distance, connector access and whether the installation needs a portable stand or fixed mounting. Compare the candidates with the same content, cover and lighting, then select against your minimum contrast and viewing-angle requirements.

    Can I specify the mount, ports, power adapter, or touch configuration?

    Share the enclosure or stand drawing, input sources, orientation and required ports. We can check available mounts, power and touch configurations and confirm which parts can be quoted together.

    What should I send for a monitor quote and sample schedule?

    Include the source ports and modes, mounting setup, accessories, quantities and required date. Ask for the hardware, accessories and any one-time setup itemized, with sample cost, production quantity breaks and separate delivery dates.

    Información complementaria

    Tamaño:

    Resolución:

    Interfaz:

    ,

    Compatible con pantallas táctiles:

    Soluciones de exposición personalizadas

    Trabaje con nuestros expertos en ingeniería para crear la pantalla perfecta para su aplicación.
