DV366FBM-N10 BOE LCD Screen 36.6 inch 1920x290 Bar Type

SKU: DS50292
Tamaño:

Número de modelo

DV366FBM-N10

Resolución:

Interfaz:

Temperatura de funcionamiento:

-0℃~50℃

Brillo (cd/m²):

700

Compatible con pantallas táctiles:

Tipo de pantalla:

DV366FBM-N10 BOE LCD Screen, 36.6 inch, 1920x290, 89/89/89/89 IPS Screen, LVDS interface, 700 nits Sunlight readable for outdoor advertising.

Solicitar precios por volumen







    Descripción

    DV366FBM-N10 BOE LCD Screen Description

    BOE 36.6-inch Ultra-Wide LCD Strip Panel

    Engineered for reliability, this BOE panel delivers stable performance with 700-nit brightness and IPS full-view technology, ensuring consistent visuals from any angle. Equipped with LVDS for secure signal transmission, it is ideally suited for transportation applications such as:

    Train interior information displays
    Subway station route indicators
    Bus passenger notification systems

    The ultra-wide format and rugged design make it a trusted choice for mission-critical transit environments requiring 24/7 operation.

    36.6" TFT Display Specifications

    Número de modelo DV366FBM-N10
    Talla 36.6
    Resolución 1920*290
    Contorno Dimensión 960*174.35*16.9
    Área activa 919.3*138.85
    Brillo(cd/m²) 700
    Interfaz LVDS
    Ver Dirección ALL
    Temperatura de funcionamiento -0~50
    Temperatura de almacenamiento -20~60
    Vida útil del LED 50000
    Soporte de pantalla táctil No
    Relación de contraste 1200:1
    Fuente de alimentación 3.3V
    Tipo de pantalla LCD en color

    36.6" TFT LCD Custom Solutions

    Optimice sus soluciones de cableado

    Ajuste la longitud, la posición y el pinout de sus cables, o añada conectores adicionales para mejorar la funcionalidad. Obtenga una solución de cable personalizada diseñada para agilizar sus conexiones y garantizar un rendimiento seguro y fiable.

    Personalización de la interfaz LCD

    Seleccione entre una amplia gama de opciones de interfaz o consulte a nuestros expertos para encontrar la ideal para su proyecto. Podemos integrar HDMI, USB, SPI, VGA y más en su pantalla, ayudándole a cumplir sus objetivos de diseño de forma eficiente.

    Mejore la experiencia del usuario con la tecnología de pantalla táctil

    Mejore su experiencia de usuario con tecnología de pantalla táctil capacitiva o resistiva. Personalizaremos el grosor del cristal y la forma del panel táctil para garantizar un ajuste perfecto a sus requisitos de diseño.

    custom touch

    Tapa de cristal a medida

    Equipe su pantalla con una cubierta de cristal cortada a medida para aumentar la durabilidad y el rendimiento. Elija entre varios grosores y opte por la adhesión óptica para protegerla de la humedad y la suciedad, garantizando una solución duradera y fiable.

    BOE DV366FBM-N10 36.6-Inch Stretched Bar LCD FAQ

    How do I confirm that I need the BOE DV366FBM-N10?

    Send us a clear photo showing the full model suffix and revision on the old panel label, the connector side, and the equipment model. Start with the listed 36.6-inch display, then check the drawing for the outline, visible opening, thickness, mounting points and connector clearance.

    Can I reuse the existing LVDS cable and controller with the BOE DV366FBM-N10?

    Check the connector pinout, video timing, panel supply and backlight enable or dimming against the exact drawing. Send us the controller model or cable diagram before reusing the harness.

    TFT LCD datasheet integration guide

    How does the BOE DV366FBM-N10 compare with the Innolux S366AJ1-LE1?

    Both catalog listings show 36.6 inches, 1920 × 290 and LVDS. The catalog lists 0 °C to +50 °C for the BOE panel and −20 °C to +60 °C for the Innolux panel. Compare the outline and mounting points, connector position and pinout, power and backlight signals, and video timing. Test the original graphics and controls on a sample before approving a substitute.

    Compare Innolux S366AJ1-LE1

    Is the BOE DV366FBM-N10 still available, and how do I check for end of life?

    Send us the exact rear-label model and revision, requested quantity and required date. Ask for current supply for that revision and any dated manufacturer notice. If the revision is unavailable, we can review a candidate for sample qualification.

    Can I keep the original LCD and add touch, a cover, or a revised cable?

    The listed panel has no touch layer. We can review the cover, touch stack or cable around the original panel. Send us the enclosure drawing, required controller connections, sample quantity and production forecast. Ask for feasible changes, any one-time development charges, production MOQ and separate sample and production lead times.

    Información complementaria

    Tamaño:

    Número de modelo

    DV366FBM-N10

    Resolución:

    Interfaz:

    Temperatura de funcionamiento:

    -0℃~50℃

    Brillo (cd/m²):

    700

    Compatible con pantallas táctiles:

    Tipo de pantalla:

    Soluciones de exposición personalizadas

    Trabaje con nuestros expertos en ingeniería para crear la pantalla perfecta para su aplicación.
