The JC-2513A TFT Driver Board is a high-performance driver board that can accurately drive TFT screens. It has high stability and compatibility and can be widely applied to various display devices.
TTL: Applicable to the inspection of driver boards for liquid crystal display modules such as EJ050NA - 01G, AT070TN92, AT070TN94, AT080TN64, AT080TN52, EJ080NA - 05A, EJ080NA - 05B, TM080RDH01, and AT090TN12.
LVDS: Applicable to the inspection of high - definition 40PIN liquid crystal display module driver boards such as EJ070NA - 01J, N070LGE - L41, HJ070NA - 13A, HJ070NA - 13B, EJ070NA - 01F, ZJ070NA - 01P, NJ070NA - 23A, P070BAG - CM1, TM070JDHG30, EJ080NA - 04C, HE080IA - 01D, HJ080NA - 04L, HJ080IA - 01F, TM080TDH01, and TM080TDHG01.
✅Product Function Description
1 Supports HDMI, VGA, and CVBS video signal input.
2 The power input is DC +12V.
3 Features multi - function OSD operation.
4 Optional remote control function is available.
5 Auto - power - off when no signal is detected.
✅ Signal Input Standards
1 HDMI: (Universal version 1.2).
2 VGA: Supports resolutions of 800×480, 800×600, 1024×600, 1024×768, 1280×800 (refresh rate 60 - 75Hz).
Can this controller board drive my existing LCD panel?
Check the source input and the panel output independently against the source and LCD documentation. Send the complete LCD part number and connector photos. Check the panel supply and pinout, backlight power and enable or dimming signals before applying power.
Will this board support the resolution and refresh rate my source needs?
Treat 1024 × 768 as the listed maximum supported resolution. Check that the board firmware actually offers your panel’s exact timing and refresh. Check whether the source mode is accepted and whether the LCD will be driven at its native mode. Include the exact source and target mode in your request.
Should I use this board or order a controller already configured for my LCD?
Use UT-2660V.1 as the listed controller reference, then compare the full part number and revision on the label. Compare firmware availability, cable and backlight changes, mounting space and time to validate your panel. A matched board and cable can be easier to reproduce when the same LCD revision will be used in production.
Can the board be configured with a matched cable or panel firmware?
Send the complete panel label and datasheet, source input, panel connector and backlight details. We can review an available board and cable combination and confirm what firmware configuration is required.
What determines pricing and lead time for an LCD controller and cable set?
Include the full LCD model, input/output timing, cable requirement, sample quantity and required date. Ask for the hardware, accessories and any one-time setup itemized, with sample cost, production quantity breaks and separate delivery dates.
Información complementaria
Número de modelo
UT-2660V.1
Maximum supported resolution
1024*768
Model Source
HDMI/VGA/CVBS1/CVBS2
Output Interface
LVDS
Soluciones de exposición personalizadas
Trabaje con nuestros expertos en ingeniería para crear la pantalla perfecta para su aplicación.
