10.1 Inch Bar Type LCD Display | 440×1920 Stretched Screen for Automotive & Smart Devices

UGS : DS20322
Taille :

Résolution :

Interface :

Température de fonctionnement :

-0℃~50℃

Luminosité (cd/m²) :

500

Prise en charge de l'écran tactile :

Type d'affichage :

High-performance 10.1 inch bar type LCD display with 440×1920 resolution, 500 nits brightness, and wide viewing angle. Ideal for automotive mirror systems, smart appliances, and industrial embedded applications.

Demande de tarification au volume







    Description

    10.1 Inch Bar LCD Display Description

    This 10.1-inch bar type LCD display is specifically engineered for space-constrained and vertically oriented applications where traditional screens cannot fit.
    With a 440×1920 high-resolution stretched format, it enables efficient information display in narrow spaces, making it ideal for automotive mirror systems, smart appliances, and industrial control interfaces.

    10.1 inch bar lcd Specifications

    Numéro de modèle QV101F6M-N10-1QP0
    Taille 10.1
    Résolution 440*1920
    Dimension de l'ébauche 64.98*266.39*4.6
    Zone active 57.948*252.864
    Luminosité (cd/m²) 500
    Interface MIPI
    Voir la direction IPS
    Température de fonctionnement -0~50
    Température de stockage -20~60
    Durée de vie des LED 30000
    Prise en charge de l'écran tactile Without(customization available)
    Rapport de contraste 1000:1
    Alimentation électrique 3.3V
    Type d'affichage LCD couleur

    10.1" TFT Custom Solutions

    Optimisez vos solutions de câblage

    Ajustez la longueur, la position et le brochage de vos câbles, ou ajoutez des connecteurs supplémentaires pour améliorer la fonctionnalité. Obtenez une solution de câblage personnalisée conçue pour rationaliser vos connexions et garantir des performances sûres et fiables.

    Personnalisation de l'interface LCD

    Choisissez parmi une gamme variée d'options d'interface ou consultez nos experts pour trouver celle qui convient le mieux à votre projet. Nous pouvons intégrer des interfaces HDMI, USB, SPI, VGA et autres dans votre écran, pour vous aider à atteindre efficacement vos objectifs de conception.

    Améliorer l'expérience de l'utilisateur grâce à la technologie de l'écran tactile

    Améliorez votre expérience utilisateur grâce à la technologie des écrans tactiles capacitifs ou résistifs. Nous personnaliserons l'épaisseur du verre et la forme de l'écran tactile pour qu'il réponde parfaitement à vos exigences en matière de conception.

    custom touch

    Verre de couverture sur mesure

    Équipez votre écran d'une vitre de protection découpée sur mesure pour améliorer sa durabilité et ses performances. Choisissez parmi différentes épaisseurs et optez pour le collage optique afin d'assurer une protection contre l'humidité et les débris, garantissant ainsi une solution durable et fiable.

    10.1-Inch 440 × 1920 Stretched Bar LCD Display FAQ

    Will this bar display fit my narrow opening and show the full interface?

    Use the 10.1-inch diagonal to shortlist bar displays, then check the exact drawing for fit. Compare the active width and height, bezel overlap and flex-cable exit with your drawing. Start with the listed 440 × 1920 pixel layout. If you mount the long edge horizontally, try a 1920 × 440 content layout and verify rotation on the intended host. Keep the panel’s native timing separate from the artwork orientation.

    Can I run a horizontal layout with this bar LCD and my controller?

    For the listed MIPI interface, match the display lane count, lane mapping, operating mode and panel initialization sequence. Confirm that the graphics pipeline can render the native mode and map rotation correctly. Test boot graphics and your application with the panel in its installed orientation.

    When should I choose this bar format over a conventional rectangular screen?

    Pick the bar format when the opening and the layout can use its long axis without cropping essential content. Compare the controller and mounting changes against a standard screen, then mock up text at the actual viewing distance. Use the listed 500 cd/m² to shortlist the display, then judge the assembled product with its final cover and ambient lighting.

    Bar screens and cut bar screens

    Can I change the flex exit, front cover, or touch configuration for a bar display?

    Send your visible opening, installed orientation, connector clearance and cover drawing. We can review flex routing and a cover or touch assembly around the existing bar panel, with feasibility checked against the drawing.

    How much does a custom bar display sample cost and how long does it take?

    Include the visible dimensions, driver interface, installed orientation, sample quantity and annual volume. We can quote the proposed changes, any one-time tooling or engineering, sample price and production MOQ separately. Ask for distinct sample and production lead times on the quoted drawing revision.

    Informations complémentaires

    Taille :

    Résolution :

    Interface :

    Température de fonctionnement :

    -0℃~50℃

    Luminosité (cd/m²) :

    500

    Prise en charge de l'écran tactile :

    Type d'affichage :
