Écran LCD 12,1" G121EAN01.4 AUO 1280*800 Luminance 300 cd/m²

UGS : DS50022
Taille :

Numéro de modèle

G121EAN01.4

Résolution :

Interface :

Luminosité (cd/m²) :

300

Température de fonctionnement :

-30℃~ 85℃

Prise en charge de l'écran tactile :

Type d'affichage :

Ressources :

G121EAN01.4 from Brand AUO, Resolution 1280*800, Brightness 300cd/m² Operating Temperature from -30~85℃, LVDS 30 pin, Stable supply, Original A grade quality

Demande de tarification au volume







    Description

    G121EAN01.4 Key Features

    The AUO G121EAN01.4 is a 12.1-inch WXGA IPS display featuring a resolution of 1280 x 800 pixels and a pixel density of 124 PPI, delivering crisp and vibrant visuals. It boasts a typical luminance of 300 cd/m² and a high contrast ratio of 1000:1, ensuring excellent image quality and visibility. Utilizing AHVA technology, the display offers symmetrical viewing angles of 89 degrees in all directions, maintaining consistent image quality from various perspectives. With a fast response time of 25ms and a transmissive operating mode, it provides responsive performance. The display's rugged design includes a durable LVDS interface with a 50,000 connection lifecycle, a compact and lightweight build, and a wide operating temperature range of -30°C to 85°C. It operates on a standard 3.3V power supply, making it a versatile choice for a variety of applications.



    G121EAN01.4 Applications

    The AUO G121EAN01.4 display boasts key strengths such as a high-resolution WXGA panel, impressive luminance and contrast, wide viewing angles, and a robust design, making it suitable for a variety of applications. It is ideal for use in industrial automation and control systems, medical equipment and diagnostic devices, automotive infotainment and instrumentation, as well as in outdoor and rugged portable devices and digital signage and interactive kiosks.

    12.1" TFT-LCD Product Specifications

    Numéro de modèle G121EAN01.4
    Taille 12.1
    Résolution 1280*800
    Dimension de l'ébauche 278*184*9.64
    Zone active 261.12*163.2
    Luminosité (cd/m²) 300
    Interface LVDS
    Voir la direction ALL
    Température de fonctionnement -30~85
    Température de stockage -30~85
    Durée de vie des LED 50000
    Prise en charge de l'écran tactile Sans
    Rapport de contraste 1000:1
    Alimentation électrique 3.3V
    Type d'affichage LCD couleur

    12.1" TFT LCD Custom Solutions

    Optimisez vos solutions de câblage

    Ajustez la longueur, la position et le brochage de vos câbles, ou ajoutez des connecteurs supplémentaires pour améliorer la fonctionnalité. Obtenez une solution de câblage personnalisée conçue pour rationaliser vos connexions et garantir des performances sûres et fiables.

    Modifications de la carte de circuit imprimé

    Choisissez parmi une variété de variations dans la forme du circuit imprimé, la taille, la disposition des broches et des composants pour l'adapter parfaitement à votre application.

    Améliorer l'expérience de l'utilisateur grâce à la technologie de l'écran tactile

    Améliorez votre expérience utilisateur grâce à la technologie des écrans tactiles capacitifs ou résistifs. Nous personnaliserons l'épaisseur du verre et la forme de l'écran tactile pour qu'il réponde parfaitement à vos exigences en matière de conception.

    custom touch

    Verre de couverture sur mesure

    Équipez votre écran d'une vitre de protection découpée sur mesure pour améliorer sa durabilité et ses performances. Choisissez parmi différentes épaisseurs et optez pour le collage optique afin d'assurer une protection contre l'humidité et les débris, garantissant ainsi une solution durable et fiable.

    AUO G121EAN01.4 12.1-Inch LCD Replacement FAQ

    How do I confirm that I need the AUO G121EAN01.4?

    Send us a clear photo showing the full model suffix and revision on the old panel label, the connector side, and the equipment model. Start with the listed 12.1-inch display, then check the drawing for the outline, visible opening, thickness, mounting points and connector clearance.

    Can I reuse the existing LVDS cable and controller with the AUO G121EAN01.4?

    For the listed LVDS interface, match the connector pinout, channel count, data mapping and panel supply before applying power. Check the existing backlight supply and enable/dim signals as well. Two connectors that look identical can carry different signals.

    TFT LCD datasheet integration guide

    How does the AUO G121EAN01.4 compare with the Innolux G121ICE-L02?

    Both catalog listings show 12.1 inches, 1280 × 800 and LVDS. The catalog lists −30 °C to +85 °C for the AUO panel and −20 °C to +70 °C for the Innolux panel. Compare the outline and mounting points, connector position and pinout, power and backlight signals, and video timing. Test the original graphics and controls on a sample before approving a substitute.

    Compare Innolux G121ICE-L02

    Is the AUO G121EAN01.4 still available, and how do I check for end of life?

    Send us the exact rear-label model and revision, requested quantity and required date. Ask for current supply for that revision and any dated manufacturer notice. If the revision is unavailable, we can review a candidate for sample qualification.

    Can I keep the original LCD and add touch, a cover, or a revised cable?

    The listed panel has no touch layer. We can review the cover, touch stack or cable around the original panel. Send us the enclosure drawing, required controller connections, sample quantity and production forecast. Ask for feasible changes, any one-time development charges, production MOQ and separate sample and production lead times.

    Informations complémentaires

    Taille :

    Numéro de modèle

    G121EAN01.4

    Résolution :

    Interface :

    Luminosité (cd/m²) :

    300

    Température de fonctionnement :

    -30℃~ 85℃

    Prise en charge de l'écran tactile :

    Type d'affichage :
