2.0 inch Industrial lcd panel Custom MCU/RGB

UGS : DS20005
Taille :

Résolution :

Interface :

,

Température de fonctionnement :

-20℃~70℃

Luminosité (cd/m²) :

350

Prise en charge de l'écran tactile :

Type d'affichage :

2.0 inch Industrial lcd panel  170*220 pixels  RGB Interface  FFC ZIF Connection  Customized touch screen MCU/RGB Interface

Demande de tarification au volume







    Description

    2.0 inch Industrial lcd panel Module

    The 2.0 inch Industrial lcd panel active area measures 31.68 mm x 39.6 mm, while the overall dimensions are 38.38 mm x 51.3 mm x 2.2 mm, making the tft screen suitable for a variety of compact applications. Additionally, its resolution of 176 x 220 pixels, providing bright and clear visuals. MCU / RGB interface allows for smooth data transfer and enhances overall user experience. This lcd module functions within a temperature range of -20°C to 70°C, providing versatility for different environments, such as industrial control, medical wearable devices.



    Tailored to meet specific project requirements

    If your project demands unique dimensions or shapes, we can create custom outlines to fit your design. And also modify temperature tolerance and durability features for specific industrial or outdoor applications. This 2 inch tft display is designed to meet the requirements of various industries, including Io T, industrial automation, and handheld devices. Additionally, its compatibility with micro controllers makes it an excellent option for DIY projects and prototyping.

    2.0" TFT-LCD Product Specifications

    Numéro de modèle  90-02006-001
    Taille  2.0
    Résolution 176*220
    Dimension de l'ébauche 38.38*51.3*2.2
    Zone active 31.68*39.6
    Luminosité (cd/m²) 350
    Interface MCU/RGB
    Voir la direction 12 O"clock
    Température de fonctionnement -20~70
    Température de stockage -30~80
    Durée de vie des LED 20000
    Prise en charge de l'écran tactile Sans
    Rapport de contraste 300:1
    Alimentation électrique 3.3V
    Type d'affichage LCD couleur

    2.0" TFT LCD Custom Solutions

    Optimisez vos solutions de câblage

    Adjust the length, position, and pin out of your cables, or add additional connectors to enhance functionality. Get a customized cable solution designed to streamline your connections and ensure secure, reliable performance.

    Personnalisation de l'interface LCD

    Choisissez parmi une gamme variée d'options d'interface ou consultez nos experts pour trouver celle qui convient le mieux à votre projet. Nous pouvons intégrer des interfaces HDMI, USB, SPI, VGA et autres dans votre écran, pour vous aider à atteindre efficacement vos objectifs de conception.

    Améliorer l'expérience de l'utilisateur grâce à la technologie de l'écran tactile

    Améliorez votre expérience utilisateur grâce à la technologie des écrans tactiles capacitifs ou résistifs. Nous personnaliserons l'épaisseur du verre et la forme de l'écran tactile pour qu'il réponde parfaitement à vos exigences en matière de conception.

    Verre de couverture sur mesure

    Équipez votre écran d'une vitre de protection découpée sur mesure pour améliorer sa durabilité et ses performances. Choisissez parmi différentes épaisseurs et optez pour le collage optique afin d'assurer une protection contre l'humidité et les débris, garantissant ainsi une solution durable et fiable.

    2-Inch RGB LCD Display Module FAQ

    Will this display fit my enclosure and show the whole interface?

    Use the 2-inch diagonal to shortlist display modules, then check the exact drawing for fit. Overlay the visible area, module outline and flex exit on your enclosure drawing. Get the native pixel layout first, then try your menus and text at that layout before committing to the enclosure.

    What must my controller support to drive this display module?

    For the listed RGB interface, match data width, pixel clock, sync polarities and blanking to the panel timing sheet. Before connecting it, check the power rails and reset sequence in the module documentation.

    How should I compare this display with a similar module for my device?

    For the listed LCD, compare viewing-angle shifts and dark-screen appearance through the front cover. Use the listed 350 cd/m² to shortlist the display, then judge the assembled product with its final cover and ambient lighting. Compare the cost and space of any changes to the cable, host board or front cover.

    Can I change the flex cable, add a cover, or integrate touch?

    Send us the mounting drawing, permitted flex exit, connector and cover or touch requirements. We can review which of those changes can be made around the existing display and which require a different module.

    What determines the cost and lead time of a custom display sample?

    Include your display outline, interface, target sample date and estimated annual volume. We can quote the proposed changes, any one-time tooling or engineering, sample price and production MOQ separately. Ask for distinct sample and production lead times on the quoted drawing revision.

    Solutions d'affichage personnalisées

    Informations complémentaires

    Taille :

    Résolution :

    Interface :

    ,

    Température de fonctionnement :

    -20℃~70℃

    Luminosité (cd/m²) :

    350

    Prise en charge de l'écran tactile :

    Type d'affichage :

    Solutions d'affichage personnalisées

    Travaillez avec nos experts en ingénierie pour créer le présentoir parfait pour votre application.
