5 inch IPS 480*854 MIPI Outdoor LCD Display

UGS : DS20052
Taille :

Résolution :

Interface :

Température de fonctionnement :

-20℃~70℃

Luminosité (cd/m²) :

450

Prise en charge de l'écran tactile :

Type d'affichage :

5 inch Liquid crystal display module  480*854 Pixels  Serial MIPI Interface  40 pin FFC connection  Customized touch screen

Demande de tarification au volume







    Description

    5" Colour TFT Displays Features

    The 5 inch Liquid crystal display module features a resolution of 480x854 pixels, making it ideal for applications that require clear and detailed imagery. It has an active area of 61.56mm x 109.53mm and compact overall dimensions of 66.4mm x 120.05mm x 2.05mm, allowing for seamless integration into various device designs. The display provides an 80° viewing angle in all directions, ensuring consistent image quality and color accuracy. With a brightness level of 450 cd/m², it maintains excellent visibility in various lighting conditions.



    5" LCD Panel with MIPI interface

    The 5-inch TFT-LCD features a 40-pin MIPI for connectivity, enabling high-speed communication between the display and host device. MIPI is a widely adopted standard in embedded industries, facilitating efficient processor-to-display communication with high-speed data transfer rates essential for smooth video playback and responsive user interfaces. The 40-pin configuration includes a mix of power, ground, and signal pins, providing comprehensive connectivity while maintaining compactness. Additionally, MIPI employs differential signaling for data transfer, minimizing electromagnetic interference and enhancing signal integrity over longer distances.

    5.0" TFT-LCD Product Specifications

    Numéro de modèle  90-05015-001
    Taille 5.0
    Résolution 480*854
    Dimension de l'ébauche 66.4*120.05*2.05
    Zone active 61.56*109.53
    Luminosité (cd/m²) 450
    Interface MIPI
    Voir la direction ALL
    Température de fonctionnement -20~70
    Température de stockage -30~80
    Durée de vie des LED 20000
    Prise en charge de l'écran tactile Witout
    Rapport de contraste 800:1
    Alimentation électrique 3.3V
    Type d'affichage LCD couleur

    5.0" TFT LCD Custom Solutions

    Optimisez vos solutions de câblage

    Ajustez la longueur, la position et le brochage de vos câbles, ou ajoutez des connecteurs supplémentaires pour améliorer la fonctionnalité. Obtenez une solution de câblage personnalisée conçue pour rationaliser vos connexions et garantir des performances sûres et fiables.

    Personnalisation de l'interface LCD

    Choisissez parmi une gamme variée d'options d'interface ou consultez nos experts pour trouver celle qui convient le mieux à votre projet. Nous pouvons intégrer des interfaces HDMI, USB, SPI, VGA et autres dans votre écran, pour vous aider à atteindre efficacement vos objectifs de conception.

    Améliorer l'expérience de l'utilisateur grâce à la technologie de l'écran tactile

    Améliorez votre expérience utilisateur grâce à la technologie des écrans tactiles capacitifs ou résistifs. Nous personnaliserons l'épaisseur du verre et la forme de l'écran tactile pour qu'il réponde parfaitement à vos exigences en matière de conception.

    custom touch

    Verre de couverture sur mesure

    Équipez votre écran d'une vitre de protection découpée sur mesure pour améliorer sa durabilité et ses performances. Choisissez parmi différentes épaisseurs et optez pour le collage optique afin d'assurer une protection contre l'humidité et les débris, garantissant ainsi une solution durable et fiable.

    5-Inch 480 × 854 MIPI LCD Display Module FAQ

    Will this display fit my enclosure and show the whole interface?

    Use the 5-inch diagonal to shortlist display modules, then check the exact drawing for fit. Overlay the visible area, module outline and flex exit on your enclosure drawing. Try your menus and text on a 480 × 854 canvas before committing to the enclosure.

    What must my controller support to drive this display module?

    For the listed MIPI interface, match the display lane count, lane mapping, operating mode and panel initialization sequence. Before connecting it, check the power rails and reset sequence in the module documentation.

    How should I compare this display with a similar module for my device?

    For the listed LCD, compare viewing-angle shifts and dark-screen appearance through the front cover. Use the listed 450 cd/m² to shortlist the display, then judge the assembled product with its final cover and ambient lighting. Compare the cost and space of any changes to the cable, host board or front cover.

    Can I change the flex cable, add a cover, or integrate touch?

    Send us the mounting drawing, permitted flex exit, connector and cover or touch requirements. We can review which of those changes can be made around the existing display and which require a different module.

    What determines the cost and lead time of a custom display sample?

    Include your display outline, interface, target sample date and estimated annual volume. We can quote the proposed changes, any one-time tooling or engineering, sample price and production MOQ separately. Ask for distinct sample and production lead times on the quoted drawing revision.

    Solutions d'affichage personnalisées

    Informations complémentaires

    Taille :

    Résolution :

    Interface :

    Température de fonctionnement :

    -20℃~70℃

    Luminosité (cd/m²) :

    450

    Prise en charge de l'écran tactile :

    Type d'affichage :

    Solutions d'affichage personnalisées

    Travaillez avec nos experts en ingénierie pour créer le présentoir parfait pour votre application.
