IVO M101GWT9 R4 10.1 inch High Brightness Industrial LCD Display LVDS Interface Wide Temperature Range

COD: DS50260
Dimensioni:

Numero di modello

M101GWT9

Risoluzione:

Interfaccia:

Temperatura di esercizio:

-0℃~60℃

Supporto per touchscreen:

Tipo di display:

Resources:

IVO m101gwt9 r4 Rugged 10.1 inch LVDS LCD for Industrial Harsh Environments 350cd/m² Brightness Industrial Display.

Richiesta di prezzi a volume







    Descrizione

    M101GWT9 R4 General Desription

    The IVO M101GWT9 R4 is a 10.1-inch color LCD display engineered for demanding environments. With a resolution of 1024×600 and 350 cd/m² brightness, it ensures crisp visibility even under direct light. Its TN panel with 500:1 contrast ratio delivers reliable performance, while the LVDS interface guarantees stable signal transmission. Designed for industrial resilience, it operates seamlessly in temperatures from -0°C to 50°C and supports a 30,000-hour LED lifespan. The ultra-slim 5.2mm profile and 3.3V power supply make it ideal for space-constrained installations. Without touchscreen support, it prioritizes durability and cost-efficiency for fixed applications.



    Application & Performanc

    Perfect for industrial automation, POS systems, and embedded control panels, the M101GWT9 R4 excels in harsh conditions like factories, warehouses, and outdoor kiosks. Its wide operating temperature range ensures reliability in fluctuating climates, while the high brightness combats glare in sunlit areas. The LVDS interface minimizes electromagnetic interference, critical for precision machinery. Use it in medical devices, transportation dashboards, or IoT terminals where consistent performance and longevity are paramount.

    10.1" Product Specifications

    Diagonal Size 10.1 inch
    Pixel Number 1024×600
    Luminance 350
    Module Size 235×143×5.2
    Area attiva 222.72×125.28
    Viewing Direction TN
    View Angle(U/D/R/L) 70/70/70/70
    Interfaccia LVDS
    Rapporto di contrasto 500:1
    Temperatura di esercizio -0 ~ 50 °C
    Temperatura di stoccaggio -20 ~ 60 °C
    Durata del LED 30000
    Alimentazione 3.3V
    Supporto per touchscreen Senza
    Tipo di display Color TFT

    IVO LCD Display Custom Solutions

    Ottimizzate le vostre soluzioni via cavo

    Regolate la lunghezza, la posizione e la piedinatura dei vostri cavi o aggiungete connettori supplementari per migliorare la funzionalità. Ottenete una soluzione di cavi personalizzata, progettata per semplificare le connessioni e garantire prestazioni sicure e affidabili.

    PCB Modifications

    Choose from a variety of variations in PCB shape, size, pin and component layout to make it fully suitable for your application.

    Elevare l'esperienza dell'utente con la tecnologia touch screen

    Migliorate la vostra esperienza utente con la tecnologia touch screen capacitiva o resistiva. Personalizzeremo lo spessore del vetro e la forma del pannello tattile per garantire un adattamento perfetto ai vostri requisiti di progettazione.

    custom touch

    Vetro di copertura personalizzato

    Equipaggiate il vostro display con un vetro di copertura tagliato su misura per aumentare la durata e le prestazioni. Scegliete tra vari spessori e optate per l'incollaggio ottico per proteggere il display da umidità e detriti, garantendo una soluzione affidabile e duratura.

    IVO M101GWT9 R4 10.1-Inch LCD Replacement FAQ

    How do I confirm that I need the IVO M101GWT9 R4?

    Send us a clear photo showing the full model suffix and revision on the old panel label, the connector side, and the equipment model. Start with the listed 10.1-inch display, then check the drawing for the outline, visible opening, thickness, mounting points and connector clearance.

    Can I reuse the existing LVDS cable and controller with the IVO M101GWT9 R4?

    For the listed LVDS interface, match the connector pinout, channel count, data mapping and panel supply before applying power. Check the existing backlight supply and enable/dim signals as well. Two connectors that look identical can carry different signals.

    TFT LCD datasheet integration guide

    How do I qualify a different panel as a replacement for the IVO M101GWT9 R4?

    Compare the outline and mounting points, connector position and pinout, power and backlight signals, and video timing. Test the original graphics and controls on a sample before approving a substitute.

    Is the IVO M101GWT9 R4 still available, and how do I check for end of life?

    Send us the exact rear-label model and revision, requested quantity and required date. Ask for current supply for that revision and any dated manufacturer notice. If the revision is unavailable, we can review a candidate for sample qualification.

    Can I keep the original LCD and add touch, a cover, or a revised cable?

    The listed panel has no touch layer. We can review the cover, touch stack or cable around the original panel. Send us the enclosure drawing, required controller connections, sample quantity and production forecast. Ask for feasible changes, any one-time development charges, production MOQ and separate sample and production lead times.

    Informazioni aggiuntive

    Dimensioni:

    Numero di modello

    M101GWT9

    Risoluzione:

    Interfaccia:

    Temperatura di esercizio:

    -0℃~60℃

    Supporto per touchscreen:

    Tipo di display:

    Soluzioni espositive personalizzate

    Collaborate con i nostri esperti di progettazione per creare il display perfetto per la vostra applicazione.
