15.6-inch Industrial LCD Display 1000cd/m² high brightness display

COD: DS50339
Dimensioni:

Risoluzione:

Interfaccia:

Temperatura di esercizio:

-30℃~ 85℃

Supporto per touchscreen:

Tipo di display:

Resources:

15.6-inch industrial LCD screen with ultra-high brightness of 1000cd/m² and a wide temperature range of -30~85°C. Suitable for harsh environments such as industrial control, vehicles, and outdoors. Reliable and durable.

Richiesta di prezzi a volume







    Descrizione

    15.6 inch industrial LCD display features:

    Ultra-high brightness wide temperature, designed for harsh environments. It offers an ultra-high brightness of 1000 cd/m², ensuring a clear and sharp view even outdoors in direct sunlight. The operating and storage temperature range is -30°C to 85°C, providing excellent wide temperature tolerance.

    15.6 inch industrial LCD screen applications:

    It is widely used in demanding environments such as industrial automation, vehicle navigation, outdoor advertising, and commercial displays. With its high brightness, anti-glare, wide temperature, and long lifespan, it is ideal for applications where reliability and visibility are critical, including vehicle central control systems, power monitoring, outdoor terminals, and cold chain equipment.



    13.3" Product Specifications

    Diagonal size 11.8 15.6 inches
    Number of pixels 1920(RGB)x1080
    Luminosità 1000 cd/m²
    Module size 363.8 (west) × 215.9 (high) × 10.82 (d) mm
    Active area 344.16 (west) × 193.59 (h) mm
    Look directions Symmetry
    Viewing Angle (U/D/R/L) 85/85/85/85
    interface LVDS
    Contrast 1000:1
    Operating temperature -30 ~ 85 °C
    Storage temperature -30 ~ 85 °C
    LED Lifespan 30000
    Power supply 3.3V
    Touch screen support Nope
    Tipo di display a-Si TFT-LCD

    IVO LCD display custom solutions

    Optimize your wired solution

    Adjust the cable's length, position, and pin configuration, or add additional connectors for enhanced functionality. Opt for customized wired solutions designed to simplify connections and ensure secure and reliable performance.

    PCB Modifications

    Choose from a variety of variations in PCB shape, size, pin and component layout to make it fully suitable for your application.

    Elevare l'esperienza dell'utente con la tecnologia touch screen

    Migliorate la vostra esperienza utente con la tecnologia touch screen capacitiva o resistiva. Personalizzeremo lo spessore del vetro e la forma del pannello tattile per garantire un adattamento perfetto ai vostri requisiti di progettazione.

    custom touch

    Vetro di copertura personalizzato

    Equipaggiate il vostro display con un vetro di copertura tagliato su misura per aumentare la durata e le prestazioni. Scegliete tra vari spessori e optate per l'incollaggio ottico per proteggere il display da umidità e detriti, garantendo una soluzione affidabile e duratura.

    IVO 15.6-Inch LCD Replacement FAQ

    How do I confirm the exact model, revision, and fit of this LCD?

    Send us a clear photo showing the full model suffix and revision on the old panel label, the connector side, and the equipment model. Start with the listed 15.6-inch display, then check the drawing for the outline, visible opening, thickness, mounting points and connector clearance.

    Can I reuse the existing LVDS cable and controller with this LCD?

    For the listed LVDS interface, match the connector pinout, channel count, data mapping and panel supply before applying power. Check the existing backlight supply and enable/dim signals as well. Two connectors that look identical can carry different signals.

    TFT LCD datasheet integration guide

    How do I qualify a different LCD as a replacement?

    Compare the outline and mounting points, connector position and pinout, power and backlight signals, and video timing. Test the original graphics and controls on a sample before approving a substitute.

    How do I verify availability or end-of-life status for this LCD?

    Send us the exact rear-label model and revision, requested quantity and required date. Ask for current supply for that revision and any dated manufacturer notice. If the revision is unavailable, we can review a candidate for sample qualification.

    Can I keep the original LCD and adapt its cable or front assembly?

    We can review the cover, touch stack or cable around the original panel. Send us the enclosure drawing, required controller connections, sample quantity and production forecast. Ask for feasible changes, any one-time development charges, production MOQ and separate sample and production lead times.

    Informazioni aggiuntive

    Dimensioni:

    Risoluzione:

    Interfaccia:

    Temperatura di esercizio:

    -30℃~ 85℃

    Supporto per touchscreen:

    Tipo di display:

    Soluzioni espositive personalizzate

    Collaborate con i nostri esperti di progettazione per creare il display perfetto per la vostra applicazione.
