TIANMA TM050RDH03-41 5.0 inch High-Performance LCD for Industrial & Embedded Systems

COD: DS50256
Dimensioni:

Numero di modello

M050RDH03-41

Risoluzione:

Interfaccia:

Temperatura di esercizio:

-20℃~70℃

Supporto per touchscreen:

Tipo di display:

TIANMA TM050RDH03-41 250cd/m² 5 inch 800×480 Sunlight-Readable LCD for Harsh Industrial Environments (-20°C~70°C).

Richiesta di prezzi a volume







    Descrizione

    TM050RDH03-41 General Desription

    The TIANMA TM050RDH03-41 is a 5.0-inch color LCD module with 800×480 resolution, delivering sharp visuals for critical applications. Featuring 250 cd/m² brightness and a 600:1 contrast ratio, it ensures clarity in direct sunlight or low-light environments. Engineered for reliability, it operates in extreme temperatures (-20°C to 70°C) and supports 3.3V low-power operation for energy efficiency. The TN panel with 70/70/50/70 viewing angles and RGB interface guarantees stable performance in industrial automation. With a compact design (120.7×75.8×3.1mm) and 20,000-hour LED lifespan, this non-touch display is built for 24/7 durability in harsh conditions.



    Application & Performanc

    Ideal for industrial HMIs, medical monitors, and automotive dashboards, the TM050RDH03-41 excels in demanding environments. Its wide temperature tolerance (-20°C~70°C) suits outdoor equipment like solar controllers and construction machinery, while the slim profile fits IoT devices and portable diagnostic tools. The high brightness ensures readability in agricultural sensors and logistics scanners. With fast RGB signal processing, it enables real-time data display for laboratory instruments and smart meters. Ruggedized for vibration resistance, it serves AGVs and factory robots. Medical OEMs leverage its stable performance for patient monitors, while embedded developers value its 3.3V compatibility for battery-powered solutions.

    5.0" Product Specifications

    Diagonal Size 5.0 inch
    Pixel Number 800×480
    Luminance 400
    Module Size 120.7×75.8×3.1
    Area attiva 108×64.8
    Viewing Direction TN
    View Angle(U/D/R/L) 70/70/50/70
    Interfaccia RGB
    Rapporto di contrasto 600 : 1
    Temperatura di esercizio -20 ~ 70 °C
    Temperatura di stoccaggio -30 ~ 80 °C
    Durata del LED 20000
    Supporto per touchscreen Senza
    Alimentazione 3.3V
    Tipo di display Color TFT

    TIANMA LCD Display Custom Solutions

    Ottimizzate le vostre soluzioni via cavo

    Regolate la lunghezza, la posizione e la piedinatura dei vostri cavi o aggiungete connettori supplementari per migliorare la funzionalità. Ottenete una soluzione di cavi personalizzata, progettata per semplificare le connessioni e garantire prestazioni sicure e affidabili.

    PCB Modifications

    Choose from a variety of variations in PCB shape, size, pin and component layout to make it fully suitable for your application.

    Elevare l'esperienza dell'utente con la tecnologia touch screen

    Migliorate la vostra esperienza utente con la tecnologia touch screen capacitiva o resistiva. Personalizzeremo lo spessore del vetro e la forma del pannello tattile per garantire un adattamento perfetto ai vostri requisiti di progettazione.

    custom touch

    Vetro di copertura personalizzato

    Equipaggiate il vostro display con un vetro di copertura tagliato su misura per aumentare la durata e le prestazioni. Scegliete tra vari spessori e optate per l'incollaggio ottico per proteggere il display da umidità e detriti, garantendo una soluzione affidabile e duratura.

    Tianma TM050RDH03-41 5-Inch LCD Replacement FAQ

    How do I confirm that I need the Tianma TM050RDH03-41?

    Send us a clear photo showing the full model suffix and revision on the old panel label, the connector side, and the equipment model. Start with the listed 5-inch display, then check the drawing for the outline, visible opening, thickness, mounting points and connector clearance.

    Can I reuse the existing RGB cable and controller with the Tianma TM050RDH03-41?

    For the listed RGB interface, match data width, pixel clock, sync polarities and blanking to the panel timing sheet. Check the existing backlight supply and enable/dim signals as well. Two connectors that look identical can carry different signals.

    TFT LCD datasheet integration guide

    How do I qualify a different panel as a replacement for the Tianma TM050RDH03-41?

    Use 800 × 480 to shortlist a candidate while keeping the complete interface and mechanical requirements in your acceptance criteria. Compare the outline and mounting points, connector position and pinout, power and backlight signals, and video timing. Test the original graphics and controls on a sample before approving a substitute.

    Is the Tianma TM050RDH03-41 still available, and how do I check for end of life?

    Send us the exact rear-label model and revision, requested quantity and required date. Ask for current supply for that revision and any dated manufacturer notice. If the revision is unavailable, we can review a candidate for sample qualification.

    Can I keep the original LCD and add touch, a cover, or a revised cable?

    The listed panel has no touch layer. We can review the cover, touch stack or cable around the original panel. Send us the enclosure drawing, required controller connections, sample quantity and production forecast. Ask for feasible changes, any one-time development charges, production MOQ and separate sample and production lead times.

    Informazioni aggiuntive

    Dimensioni:

    Numero di modello

    M050RDH03-41

    Risoluzione:

    Interfaccia:

    Temperatura di esercizio:

    -20℃~70℃

    Supporto per touchscreen:

    Tipo di display:

    Soluzioni espositive personalizzate

    Collaborate con i nostri esperti di progettazione per creare il display perfetto per la vostra applicazione.
