2.76 inch Circular TFT Display 480x480 RGB

Artikelnummer: 90-27601-001
Größe:

Auflösung:

Schnittstelle:

Betriebstemperatur:

-20℃~70℃

Helligkeit (cd/m²):

450

Touchscreen-Unterstützung:

Anzeige Typ:

2.76 inch color tft screen  480*480 Pixels  Serial RGB Interface  40 pin FFC connection  Customized touch screen

Preisanfrage für Volumen







    Beschreibung

    2.76" Circular TFT Display Features

    The 2.76 inch Round Circular TFT Display features a resolution of 480x480 pixels, making it ideal for applications requiring high-quality, detailed visuals. The lcd display offers a viewing angle of 85° in all directions, ensuring consistent image quality and color accuracy. With a brightness level of 450 cd/m², it provides excellent visibility in diverse lighting conditions, suitable for both indoor and outdoor use. The LED backlight has a lifespan of 30,000 hours, and the high contrast ratio of 1200 enhances clarity and vibrancy.



    2.76" Circular LCD Display with Long Lifespan

    This 2.76-inch TFT display module is engineered for longevity, featuring an LED backlight rated for 30,000 hours of operation. Key factors contributing to its extended lifespan include the use of high-quality components that enhance durability and performance, effective thermal management to prevent overheating, and low power consumption that reduces thermal stress on internal parts. These features collectively ensure reliable operation and prolonged longevity, making the display suitable for various applications.

    2.76" TFT-LCD Product Specifications

    Modellnummer  90-27601-001
    Größe 2.76
    Auflösung 480*480
    Umriss Dimension 73.03*76.48*2.24
    Aktiver Bereich 70.13*70.13
    Helligkeit(cd/m²) 450
    Schnittstelle RGB
    Ansicht Richtung ALLE
    Betriebstemperatur -20~70
    Lagertemperatur -30~80
    LED-Lebensdauer 30000
    Touchscreen-Unterstützung Witout
    Kontrastverhältnis 1200:1
    Stromversorgung 3.3V
    Anzeige Typ Farb-LCD

    2.76" TFT LCD Kundenspezifische Lösungen

    Optimieren Sie Ihre Kabellösungen

    Passen Sie die Länge, Position und Pinbelegung Ihrer Kabel an, oder fügen Sie zusätzliche Stecker hinzu, um die Funktionalität zu verbessern. Holen Sie sich eine maßgeschneiderte Kabellösung, um Ihre Verbindungen zu optimieren und eine sichere, zuverlässige Leistung zu gewährleisten.

    Anpassung der LCD-Schnittstelle

    Wählen Sie aus einer Vielzahl von Schnittstellenoptionen oder lassen Sie sich von unseren Experten beraten, um die ideale Lösung für Ihr Projekt zu finden. Wir können HDMI, USB, SPI, VGA und mehr in Ihr Display integrieren und Ihnen helfen, Ihre Designziele effizient zu erreichen.

    Erhöhen Sie die Benutzerfreundlichkeit mit Touchscreen-Technologie

    Verbessern Sie Ihr Benutzererlebnis mit kapazitiver oder resistiver Touchscreen-Technologie. Wir passen die Glasdicke und die Form des Touchscreens an, um eine perfekte Anpassung an Ihre Designanforderungen zu gewährleisten.

    custom touch

    Kundenspezifisches Deckglas

    Statten Sie Ihr Display mit einem individuell zugeschnittenen Deckglas aus, um die Haltbarkeit und Leistung zu erhöhen. Wählen Sie aus verschiedenen Stärken und entscheiden Sie sich für eine optische Verklebung, die Schutz vor Feuchtigkeit und Schmutz bietet und eine langlebige und zuverlässige Lösung gewährleistet.

    2.76-Inch 480 × 480 Round LCD Display FAQ

    Will the bezel cover any of my dial labels or icons?

    Use the 2.76-inch diagonal to shortlist round displays, then check the exact drawing for fit. Make a mask from the active circle and bezel drawing. Try your dial, long labels and controls with the mask applied on a 480 × 480 canvas before committing to the enclosure.

    How do I check that the driver and artwork align with the visible circle?

    For the listed RGB interface, match data width, pixel clock, sync polarities and blanking to the panel timing sheet. Check orientation and any address-window offsets in the initialization code, then show a marked test grid to verify the center and edge alignment.

    Should I choose a round display or place a rectangular display behind a round bezel?

    Compare the visible arc, text clipping, module clearance and flex routing for both approaches. Use the listed 450 cd/m² to shortlist the display, then judge the assembled product with its final cover and ambient lighting. A mock-up with your longest labels will show how much of the nominal screen you can actually use.

    Can I add custom cover glass, change the flex cable, or add touch?

    Send the visible circle, cover outline and thickness, desired flex exit and touch interface. We can evaluate a cover-only design and a separate touch assembly around the panel.

    Custom Touch Screen Solutions

    What affects the cost and lead time of a custom round display sample?

    Include your cover drawing, host board, sample quantity and annual volume. We can quote the proposed changes, any one-time tooling or engineering, sample price and production MOQ separately. Ask for distinct sample and production lead times on the quoted drawing revision.

    Zusätzliche Informationen

    Größe:

    Auflösung:

    Schnittstelle:

    Betriebstemperatur:

    -20℃~70℃

    Helligkeit (cd/m²):

    450

    Touchscreen-Unterstützung:

    Anzeige Typ:

    Individuelle Display-Lösungen

    Arbeiten Sie mit unseren technischen Experten zusammen, um das perfekte Display für Ihre Anwendung zu entwickeln.
