BOE 12.1 inch TFT Panel 1024x768 PV121X0M-N10 for Medical Device

Artikelnummer: DS50294
Größe:

Modellnummer

PV121X0M-N10

Auflösung:

Schnittstelle:

Betriebstemperatur:

-20℃~70℃

Helligkeit (cd/m²):

500

Touchscreen-Unterstützung:

Anzeige Typ:

BOE 12.1 inch TFT Panel, model number PV121X0M-N10, 1024x768 resolution, 86/86/86/86 IPS wide viewing angle, LVDS interface

Preisanfrage für Volumen







    Beschreibung

    BOE 12.1 inch TFT Panel Description

    BOE 12.1 inch TFT Panel model number PV121X0M-N10

    Original A-grade panel, in-stock & ready to ship
    In-house R&D support for touch screen integration and driver solutions
    Competitive pricing with comprehensive after-sales guarantee

    Perfect for industrial control, commercial display, and smart device applications. Contact us for customization!

    12.1" TFT Display Specifications

    Modellnummer PV121X0M-N10
    Größe 12.1
    Auflösung 1024*768
    Umriss Dimension 260.5*204*8.7
    Aktiver Bereich 245.76*184.32
    Helligkeit(cd/m²) 500
    Schnittstelle LVDS
    Ansicht Richtung ALLE
    Betriebstemperatur -20~70
    Lagertemperatur -30~80
    LED-Lebensdauer 50000
    Touchscreen-Unterstützung No
    Kontrastverhältnis 1200:1
    Stromversorgung 3.3V
    Anzeige Typ Farb-LCD

    12.1" TFT LCD Custom Solutions

    Optimieren Sie Ihre Kabellösungen

    Passen Sie die Länge, Position und Pinbelegung Ihrer Kabel an, oder fügen Sie zusätzliche Stecker hinzu, um die Funktionalität zu verbessern. Holen Sie sich eine maßgeschneiderte Kabellösung, um Ihre Verbindungen zu optimieren und eine sichere, zuverlässige Leistung zu gewährleisten.

    Anpassung der LCD-Schnittstelle

    Wählen Sie aus einer Vielzahl von Schnittstellenoptionen oder lassen Sie sich von unseren Experten beraten, um die ideale Lösung für Ihr Projekt zu finden. Wir können HDMI, USB, SPI, VGA und mehr in Ihr Display integrieren und Ihnen helfen, Ihre Designziele effizient zu erreichen.

    Erhöhen Sie die Benutzerfreundlichkeit mit Touchscreen-Technologie

    Verbessern Sie Ihr Benutzererlebnis mit kapazitiver oder resistiver Touchscreen-Technologie. Wir passen die Glasdicke und die Form des Touchscreens an, um eine perfekte Anpassung an Ihre Designanforderungen zu gewährleisten.

    custom touch

    Kundenspezifisches Deckglas

    Statten Sie Ihr Display mit einem individuell zugeschnittenen Deckglas aus, um die Haltbarkeit und Leistung zu erhöhen. Wählen Sie aus verschiedenen Stärken und entscheiden Sie sich für eine optische Verklebung, die Schutz vor Feuchtigkeit und Schmutz bietet und eine langlebige und zuverlässige Lösung gewährleistet.

    BOE PV121X0M-N10 12.1-Inch LCD Replacement FAQ

    How do I confirm that I need the BOE PV121X0M-N10?

    Send us a clear photo showing the full model suffix and revision on the old panel label, the connector side, and the equipment model. Start with the listed 12.1-inch display, then check the drawing for the outline, visible opening, thickness, mounting points and connector clearance.

    Can I reuse the existing LVDS cable and controller with the BOE PV121X0M-N10?

    For the listed LVDS interface, match the connector pinout, channel count, data mapping and panel supply before applying power. Check the existing backlight supply and enable/dim signals as well. Two connectors that look identical can carry different signals.

    TFT LCD datasheet integration guide

    How does the BOE PV121X0M-N10 compare with the Innolux G121XCE-L01?

    Both catalog listings show 12.1 inches, 1024 × 768 and LVDS. The catalog lists −20 °C to +70 °C for the BOE panel and −30 °C to +85 °C for the Innolux panel. Compare the outline and mounting points, connector position and pinout, power and backlight signals, and video timing. Test the original graphics and controls on a sample before approving a substitute.

    Compare Innolux G121XCE-L01

    Is the BOE PV121X0M-N10 still available, and how do I check for end of life?

    Send us the exact rear-label model and revision, requested quantity and required date. Ask for current supply for that revision and any dated manufacturer notice. If the revision is unavailable, we can review a candidate for sample qualification.

    Can I keep the original LCD and add touch, a cover, or a revised cable?

    The listed panel has no touch layer. We can review the cover, touch stack or cable around the original panel. Send us the enclosure drawing, required controller connections, sample quantity and production forecast. Ask for feasible changes, any one-time development charges, production MOQ and separate sample and production lead times.

    Zusätzliche Informationen

    Größe:

    Modellnummer

    PV121X0M-N10

    Auflösung:

    Schnittstelle:

    Betriebstemperatur:

    -20℃~70℃

    Helligkeit (cd/m²):

    500

    Touchscreen-Unterstützung:

    Anzeige Typ:

    Individuelle Display-Lösungen

    Arbeiten Sie mit unseren technischen Experten zusammen, um das perfekte Display für Ihre Anwendung zu entwickeln.
