IVO M101NWWB R3 10.1 inch IPS Display 1280×800 Resolution LVDS Interface Harsh Environments

Artikelnummer: DS50258
Größe:

Modellnummer

M101NWWB

Auflösung:

Schnittstelle:

Betriebstemperatur:

-20℃~70℃

Touchscreen-Unterstützung:

Anzeige Typ:

Resources:

IVO m101nwwb r3 10.1 inch 1280×800350 cd/m² Brightness LVDS IPS Display with -20°C~70°C Range for Extreme Industrial Use.

Preisanfrage für Volumen







    Beschreibung

    M101NWWB R3 General Desription

    The IVO M101NWWB R3 is a 10.1-inch color LCD screen with 1280×800 resolution and IPS technology, delivering 85° wide viewing angles for consistent image quality. Boasting 350 cd/m² brightness and an 800:1 contrast ratio, it ensures vivid visuals even under direct sunlight. Designed for extreme conditions, it operates reliably in temperatures from -20°C to 70°C and survives storage at -30°C~80°C. The LVDS interface guarantees stable signal transmission for industrial systems, while the ultra-slim 4.56mm profile (229.46×149.1mm outline) saves space. With a 25,000-hour LED lifespan and low 3.3V power consumption, it’s built for 24/7 reliability in demanding applications.



    Application & Performanc

    Perfect for industrial automation, outdoor digital signage, and automotive dashboards, the IVO M101NWWB R3 thrives in harsh environments. Its wide temperature range supports freezer monitoring, desert machinery, and cold-chain logistics. The LVDS interface ensures noise-free connectivity for CNC controls, factory HMIs, and rugged IoT devices. The anti-glare IPS panel enhances readability in bright sunlight, ideal for construction equipment, EV charging stations, and agricultural displays. With shock-resistant construction and a 25,000-hour lifespan, it reduces maintenance costs in mining, transportation, and energy sectors. Compact and durable, it seamlessly integrates into portable medical devices, marine navigation systems, and smart retail kiosks.

    10.1" Product Specifications

    Diagonale Größe 10,1 Zoll
    Pixel Zahl 1280×800
    Luminance 350
    Module Size 229.46×149.1×4.56
    Aktiver Bereich 216.96×135.6
    Viewing Direction IPS
    View Angle(U/D/R/L) 85/85/85/85
    Schnittstelle LVDS
    Kontrastverhältnis 800 : 1
    Betriebstemperatur -20 ~ 70 °C
    Lagertemperatur -30 ~ 80 °C
    LED-Lebensdauer 25000
    Stromversorgung 3.3V
    Touchscreen-Unterstützung Ohne
    Anzeige Typ Color TFT

    IVO LCD Display Custom Solutions

    Optimieren Sie Ihre Kabellösungen

    Passen Sie die Länge, Position und Pinbelegung Ihrer Kabel an, oder fügen Sie zusätzliche Stecker hinzu, um die Funktionalität zu verbessern. Holen Sie sich eine maßgeschneiderte Kabellösung, um Ihre Verbindungen zu optimieren und eine sichere, zuverlässige Leistung zu gewährleisten.

    PCB Modifications

    Choose from a variety of variations in PCB shape, size, pin and component layout to make it fully suitable for your application.

    Erhöhen Sie die Benutzerfreundlichkeit mit Touchscreen-Technologie

    Verbessern Sie Ihr Benutzererlebnis mit kapazitiver oder resistiver Touchscreen-Technologie. Wir passen die Glasdicke und die Form des Touchscreens an, um eine perfekte Anpassung an Ihre Designanforderungen zu gewährleisten.

    custom touch

    Kundenspezifisches Deckglas

    Statten Sie Ihr Display mit einem individuell zugeschnittenen Deckglas aus, um die Haltbarkeit und Leistung zu erhöhen. Wählen Sie aus verschiedenen Stärken und entscheiden Sie sich für eine optische Verklebung, die Schutz vor Feuchtigkeit und Schmutz bietet und eine langlebige und zuverlässige Lösung gewährleistet.

    IVO M101NWWB R3 10.1-Inch LCD Replacement FAQ

    How do I confirm that I need the IVO M101NWWB R3?

    Send us a clear photo showing the full model suffix and revision on the old panel label, the connector side, and the equipment model. Start with the listed 10.1-inch display, then check the drawing for the outline, visible opening, thickness, mounting points and connector clearance.

    Can I reuse the existing LVDS cable and controller with the IVO M101NWWB R3?

    For the listed LVDS interface, match the connector pinout, channel count, data mapping and panel supply before applying power. Check the existing backlight supply and enable/dim signals as well. Two connectors that look identical can carry different signals.

    TFT LCD datasheet integration guide

    How does the IVO M101NWWB R3 compare with the AUO G101EAN02.1?

    Both catalog listings show 10.1 inches, 1280 × 800 and LVDS. The catalog lists −20 °C to +70 °C for the IVO panel and −20 °C to +60 °C for the AUO panel. Compare the outline and mounting points, connector position and pinout, power and backlight signals, and video timing. Test the original graphics and controls on a sample before approving a substitute.

    Compare AUO G101EAN02.1

    Is the IVO M101NWWB R3 still available, and how do I check for end of life?

    Send us the exact rear-label model and revision, requested quantity and required date. Ask for current supply for that revision and any dated manufacturer notice. If the revision is unavailable, we can review a candidate for sample qualification.

    Can I keep the original LCD and add touch, a cover, or a revised cable?

    The listed panel has no touch layer. We can review the cover, touch stack or cable around the original panel. Send us the enclosure drawing, required controller connections, sample quantity and production forecast. Ask for feasible changes, any one-time development charges, production MOQ and separate sample and production lead times.
