IVO M133NWF4 R0 13.3 inch Full HD IPS LCD Display 1920×1080 Resolution, eDP Interface, 1200:1 Contrast

Artikelnummer: DS50266
Größe:

Modellnummer

M133NWF4

Auflösung:

Schnittstelle:

Betriebstemperatur:

-0℃~50℃

Touchscreen-Unterstützung:

Anzeige Typ:

Resources:

IVO m133nwf4 r0 13.3inch 1920×1080 Full HD IPS Display eDP Interface, 85° Wide Viewing Angle Slim 2.5mm Profile .

Preisanfrage für Volumen







    Beschreibung

    M133NWF4 R0 General Desription

    The IVO M133NWF4 R0 is a 13.3-inch Full HD color LCD display engineered for precision and reliability. Boasting a crisp 1920×1080 resolution and 1200:1 contrast ratio, it delivers vibrant visuals with accurate color reproduction through its IPS panel and 85/85/85/85 viewing angles. The ultra-slim 2.5mm profile (300.26×187.75mm) enables seamless integration into space-sensitive setups. With an eDP interface for high-speed signal transmission and 3.3V low power consumption, it balances performance and energy efficiency. Rated for 15,000 hours of LED lifespan, it operates stably in 0°C to 50°C environments, making it ideal for controlled indoor applications.



    Application & Performanc

    Designed for indoor digital signage, medical monitors, and control panels, the M133NWF4 R0 excels in environments requiring sharp detail and color fidelity. Its IPS panel ensures consistent visibility for collaborative workspaces or retail displays, while the slim bezel suits multi-screen installations. The eDP interface supports high-resolution video transmission for industrial PCs, laboratory equipment, and interactive kiosks. Though not suited for extreme temperatures, its 0°C~50°C range handles climate-controlled factories, hospitals, and office settings. The 300cd/m² brightness adapts to indoor lighting, and the rugged design resists dust and minor vibrations in automation systems.

    13.3" Product Specifications

    Diagonal Size11.8 13.3 inch
    Pixel Zahl 1920×1080
    Luminance 940
    Module Size 300.26×187.75×2.5
    Aktiver Bereich 293.76×165.24
    Viewing Direction IPS
    View Angle(U/D/R/L) 85/85/85/85
    Schnittstelle eDP
    Kontrastverhältnis 1200:1
    Betriebstemperatur -0 ~ 50 °C
    Lagertemperatur -20 ~ 60 °C
    LED-Lebensdauer 30000
    Stromversorgung 3.3V
    Touchscreen-Unterstützung Ohne
    Anzeige Typ Color TFT

    IVO LCD Display Custom Solutions

    Optimieren Sie Ihre Kabellösungen

    Passen Sie die Länge, Position und Pinbelegung Ihrer Kabel an, oder fügen Sie zusätzliche Stecker hinzu, um die Funktionalität zu verbessern. Holen Sie sich eine maßgeschneiderte Kabellösung, um Ihre Verbindungen zu optimieren und eine sichere, zuverlässige Leistung zu gewährleisten.

    PCB Modifications

    Choose from a variety of variations in PCB shape, size, pin and component layout to make it fully suitable for your application.

    Erhöhen Sie die Benutzerfreundlichkeit mit Touchscreen-Technologie

    Verbessern Sie Ihr Benutzererlebnis mit kapazitiver oder resistiver Touchscreen-Technologie. Wir passen die Glasdicke und die Form des Touchscreens an, um eine perfekte Anpassung an Ihre Designanforderungen zu gewährleisten.

    custom touch

    Kundenspezifisches Deckglas

    Statten Sie Ihr Display mit einem individuell zugeschnittenen Deckglas aus, um die Haltbarkeit und Leistung zu erhöhen. Wählen Sie aus verschiedenen Stärken und entscheiden Sie sich für eine optische Verklebung, die Schutz vor Feuchtigkeit und Schmutz bietet und eine langlebige und zuverlässige Lösung gewährleistet.

    IVO M133NWF4 R0 13.3-Inch LCD Replacement FAQ

    How do I confirm that I need the IVO M133NWF4 R0?

    Send us a clear photo showing the full model suffix and revision on the old panel label, the connector side, and the equipment model. Start with the listed 13.3-inch display, then check the drawing for the outline, visible opening, thickness, mounting points and connector clearance.

    Can I reuse the existing eDP cable and controller with the IVO M133NWF4 R0?

    For the listed eDP interface, match lane count, link rate, power sequencing and connector pinout. Check the existing backlight supply and enable/dim signals as well. Two connectors that look identical can carry different signals.

    TFT LCD datasheet integration guide

    How does the IVO M133NWF4 R0 compare with the AUO G133HAN02.2?

    Both catalog listings show 13.3 inches, 1920 × 1080 and eDP. The catalog lists 0 °C to +50 °C for the IVO panel and 0 °C to +60 °C for the AUO panel. Compare the outline and mounting points, connector position and pinout, power and backlight signals, and video timing. Test the original graphics and controls on a sample before approving a substitute.

    Compare AUO G133HAN02.2

    Is the IVO M133NWF4 R0 still available, and how do I check for end of life?

    Send us the exact rear-label model and revision, requested quantity and required date. Ask for current supply for that revision and any dated manufacturer notice. If the revision is unavailable, we can review a candidate for sample qualification.

    Can I keep the original LCD and add touch, a cover, or a revised cable?

    The listed panel has no touch layer. We can review the cover, touch stack or cable around the original panel. Send us the enclosure drawing, required controller connections, sample quantity and production forecast. Ask for feasible changes, any one-time development charges, production MOQ and separate sample and production lead times.

    Zusätzliche Informationen

    Größe:

    Modellnummer

    M133NWF4

    Auflösung:

    Schnittstelle:

    Betriebstemperatur:

    -0℃~50℃

    Touchscreen-Unterstützung:

    Anzeige Typ:
