0.96 inch TFT Display 80x160 High Bright LCD for Smart Home Appliance

SKU: DS20288
Tamaño:

Resolución:

Interfaz:

Temperatura de funcionamiento:

-20℃~70℃

Brillo (cd/m²):

400

Compatible con pantallas táctiles:

Tipo de pantalla:

0.96 inch TFT Display, resolution 80x160, RGB interface, 400nits brightness, Drive IC ST7735S, IPS wide viewing angle, idea for smart home appliance.

Solicitar precios por volumen







    Descripción

    0.96 inch TFT Display Product Description:

    Featuring a tiny 0.96-inch form factor, this TFT LCD delivers 400nits high brightness—clear and readable even under direct sunlight. Its IPS wide viewing angle technology ensures consistent clarity from any perspective, while the -20°C to 70°C operating temperature range meets industrial-grade reliability standards. Perfect for smart home applications, it balances durability with space-saving design.

    Below the basic parameters for it, Tailor the interface (SPI/MCU), brightness, dimensions, and touch solutions (capacitive/resistive) to seamlessly integrate into your device—engineered for hassle-free system integration.

    0.96" TFT Display Specifications

    Número de modelo GX-T096- C08
    Talla 0.96
    Resolución 80*160
    Contorno Dimensión 13.5*27.95*1.5
    Área activa 10.8*21.7
    Brillo(cd/m²) 400
    Interfaz 4 Line SPI
    Ver Dirección ALL
    Temperatura de funcionamiento -20~70
    Temperatura de almacenamiento -30~80
    Vida útil del LED 20000
    Soporte de pantalla táctil Capacitive touch
    Relación de contraste 1000:1
    Fuente de alimentación 3.0V
    Tipo de pantalla LCD en color

    0.96" TFT LCD Custom Solutions

    Optimice sus soluciones de cableado

    Ajuste la longitud, la posición y el pinout de sus cables, o añada conectores adicionales para mejorar la funcionalidad. Obtenga una solución de cable personalizada diseñada para agilizar sus conexiones y garantizar un rendimiento seguro y fiable.

    Personalización de la interfaz LCD

    Seleccione entre una amplia gama de opciones de interfaz o consulte a nuestros expertos para encontrar la ideal para su proyecto. Podemos integrar HDMI, USB, SPI, VGA y más en su pantalla, ayudándole a cumplir sus objetivos de diseño de forma eficiente.

    Mejore la experiencia del usuario con la tecnología de pantalla táctil

    Mejore su experiencia de usuario con tecnología de pantalla táctil capacitiva o resistiva. Personalizaremos el grosor del cristal y la forma del panel táctil para garantizar un ajuste perfecto a sus requisitos de diseño.

    custom touch

    Tapa de cristal a medida

    Equipe su pantalla con una cubierta de cristal cortada a medida para aumentar la durabilidad y el rendimiento. Elija entre varios grosores y opte por la adhesión óptica para protegerla de la humedad y la suciedad, garantizando una solución duradera y fiable.

    0.96-Inch 80 × 160 TFT LCD Display Module FAQ

    Will this display fit my enclosure and show the whole interface?

    Use the 0.96-inch diagonal to shortlist display modules, then check the exact drawing for fit. Overlay the visible area, module outline and flex exit on your enclosure drawing. Try your menus and text on a 80 × 160 canvas before committing to the enclosure.

    What must my controller support to drive this display module?

    Send us your host model so we can check the required interface, pinout and electrical limits against the exact product documentation. Before connecting it, check the power rails and reset sequence in the module documentation.

    How should I compare this display with a similar module for my device?

    For the listed LCD, compare viewing-angle shifts and dark-screen appearance through the front cover. Use the listed 400 cd/m² to shortlist the display, then judge the assembled product with its final cover and ambient lighting. Compare the cost and space of any changes to the cable, host board or front cover.

    Can I change the flex cable, add a cover, or integrate touch?

    Send us the mounting drawing, permitted flex exit, connector and cover or touch requirements. We can review which of those changes can be made around the existing display and which require a different module.

    What determines the cost and lead time of a custom display sample?

    Include your display outline, interface, target sample date and estimated annual volume. We can quote the proposed changes, any one-time tooling or engineering, sample price and production MOQ separately. Ask for distinct sample and production lead times on the quoted drawing revision.

    Soluciones de exposición personalizadas

    Información complementaria

    Tamaño:

    Resolución:

    Interfaz:

    Temperatura de funcionamiento:

    -20℃~70℃

    Brillo (cd/m²):

    400

    Compatible con pantallas táctiles:

    Tipo de pantalla:

    Soluciones de exposición personalizadas

    Trabaje con nuestros expertos en ingeniería para crear la pantalla perfecta para su aplicación.
