57.2 inch Android LCD Monitors, ALL-In-One Machine for Train, Railway and Outdoor Advertising

SKU: DS30066
Tamaño:

Resolución:

Interfaz:

, ,

Compatible con pantallas táctiles:

abc

57.2 inch Android LCD Monitors, 1428.2*270 mm Bar Type screen, with Android system, 2+32GB, Brightness from 300-3000nits can be customized.

Solicitar precios por volumen







    Descripción

    57.2 inch Android LCD Monitors:

    • Built-in real-time clock battery and timer power on/off support
    • TF card expansion, up to 64GB
    • OSD languages: Chinese, English, and multi-language support
    • Supports 10/100Mbps Ethernet, 2.4G Wi-Fi, 802.11b/g/n protocols
    • Supports various image formats such as JPG, BMP, PNG, and GIF, and supports landscape and portrait switching for videos, images, and text. Rotates 90°, 180°, and 270°
    47.1 inch digital shelf edge labels



    57.2 inch Android LCD Monitors Specification
    Display Tamaño de la pantalla 57.2 inch
    Área activa 1428.2*270
    Esquema 1450*300*49
    Tipo de pantalla a-Si TFT-LCD
    Número de píxeles 4830*720
    Relación de aspecto 7:1
    Luminancia 700 cd/m2
    Relación de contraste 1200:1
    Ángulo de visión 89/89/89/89 (Typ.)(CR≥10)
    Profundidad de color 16,7M 68% NTSC
    Respuesta 8 (Typ.)(G to G) ms
    Paso de píxeles 0.3115×0.3115 mm (H×V)
    Placa base CPU RK3568
    Ram 2G(Optional)
    Flash 32G(Optional)
    O/S Android
    Interfaz USB OTG/USB HOST/RJ45/Micro SD/LINE OUT/HDMI OUT/DC2.0 IN
    Máquina Aspecto y estructura Chapa metálica
    Color Black(optional)
    Periférico
    Alimentación AC100-230V
    Consumo de energía ≦110W
    Temperatura de funcionamiento 0℃~50℃
    Temperatura de almacenamiento -20℃~60℃
    Tamaño Corton
    Método de instalación Colgante de pared
    Peso neto 18Kg
    Dimensiones del producto 47.1 inch ultra wide digital signage display

    Descargar

    57.2-Inch Monitor FAQ

    Will this monitor fit with the cables and controls accessible?

    Use the 57.2-inch diagonal to shortlist monitors, then check the exact drawing for fit. Compare the case depth, mount or stand, cable bend and access to the controls against your setup. Test the actual cable exit before approving a tight installation.

    Industrial touch monitor selection guide

    Can my computer, media player, or controller run this monitor?

    Send us your source model and OS or firmware version so we can check the required interface, pinout and electrical limits against the exact product documentation. Check which port carries video and how power is supplied.

    How should I compare this monitor with another for my installation?

    Get the native pixel layout first, then try your typical desktop, menu or signage layout at that layout before choosing a monitor. Compare readable text size at the intended distance, connector access and whether the installation needs a portable stand or fixed mounting. For the listed LCD, compare viewing-angle shifts and dark-screen appearance through the front cover.

    Can I specify the mount, ports, power adapter, or touch configuration?

    Share the enclosure or stand drawing, input sources, orientation and required ports. We can check available mounts, power and touch configurations and confirm which parts can be quoted together.

    What should I send for a monitor quote and sample schedule?

    Include the source ports and modes, mounting setup, accessories, quantities and required date. Ask for the hardware, accessories and any one-time setup itemized, with sample cost, production quantity breaks and separate delivery dates.

    Información complementaria

    Tamaño:

    Resolución:

    Interfaz:

    , ,

    Compatible con pantallas táctiles:

    Soluciones de exposición personalizadas

    Trabaje con nuestros expertos en ingeniería para crear la pantalla perfecta para su aplicación.
