BOE QV190FBM-N10 TFT Panel 19 inch Bar Type Screen 1920x360

SKU: DS50291
Tamaño:

Número de modelo

QV190FBM-N10

Resolución:

Interfaz:

Temperatura de funcionamiento:

-0℃~50℃

Brillo (cd/m²):

300

Compatible con pantallas táctiles:

Tipo de pantalla:

BOE QV190FBM-N10 TFT Panel, 19inch, 1920x360, IPS wide viewing angle, Long stretched screen for transportation and advertising.

Solicitar precios por volumen







    Descripción

    BOE QV190FBM-N10 Description

    BOE QV190FBM-N10: Original Grade A LCD Panels
    Excellent stability and reliability, 1920×360 bar-type panels are ideal for transportation, advertising, and other demanding applications. Widely sold both domestically and internationally, our strip-shaped displays deliver consistent performance and visual clarity for large-scale information display and commercial promotion.

    Key Features:

    BOE original Grade A panels with strict quality control
    Ultra-wide resolution 1920×360 for panoramic content display
    Engineered for high-reliability environments (transportation hubs, outdoor advertising)
    Global market presence with proven sales track record

    19" TFT Display Specifications

    Número de modelo QV190FBM-N10
    Talla 19
    Resolución 1920*360
    Contorno Dimensión 491.5*109.4*8.4
    Área activa 476.64*89.37
    Brillo(cd/m²) 300
    Interfaz LVDS
    Ver Dirección ALL
    Temperatura de funcionamiento -0~50
    Temperatura de almacenamiento -20~60
    Vida útil del LED 30000
    Soporte de pantalla táctil No
    Relación de contraste 1200:1
    Fuente de alimentación 3.3V
    Tipo de pantalla LCD en color

    19" TFT LCD Custom Solutions

    Optimice sus soluciones de cableado

    Ajuste la longitud, la posición y el pinout de sus cables, o añada conectores adicionales para mejorar la funcionalidad. Obtenga una solución de cable personalizada diseñada para agilizar sus conexiones y garantizar un rendimiento seguro y fiable.

    Personalización de la interfaz LCD

    Seleccione entre una amplia gama de opciones de interfaz o consulte a nuestros expertos para encontrar la ideal para su proyecto. Podemos integrar HDMI, USB, SPI, VGA y más en su pantalla, ayudándole a cumplir sus objetivos de diseño de forma eficiente.

    Mejore la experiencia del usuario con la tecnología de pantalla táctil

    Mejore su experiencia de usuario con tecnología de pantalla táctil capacitiva o resistiva. Personalizaremos el grosor del cristal y la forma del panel táctil para garantizar un ajuste perfecto a sus requisitos de diseño.

    custom touch

    Tapa de cristal a medida

    Equipe su pantalla con una cubierta de cristal cortada a medida para aumentar la durabilidad y el rendimiento. Elija entre varios grosores y opte por la adhesión óptica para protegerla de la humedad y la suciedad, garantizando una solución duradera y fiable.

    BOE QV190FBM-N10 19-Inch Stretched Bar LCD FAQ

    How do I confirm that I need the BOE QV190FBM-N10?

    Send us a clear photo showing the full model suffix and revision on the old panel label, the connector side, and the equipment model. Start with the listed 19-inch display, then check the drawing for the outline, visible opening, thickness, mounting points and connector clearance.

    Can I reuse the existing LVDS cable and controller with the BOE QV190FBM-N10?

    Check the connector pinout, video timing, panel supply and backlight enable or dimming against the exact drawing. Send us the controller model or cable diagram before reusing the harness.

    TFT LCD datasheet integration guide

    How do I qualify a different panel as a replacement for the BOE QV190FBM-N10?

    Use 1920 × 360 to shortlist a candidate while keeping the complete interface and mechanical requirements in your acceptance criteria. Compare the outline and mounting points, connector position and pinout, power and backlight signals, and video timing. Test the original graphics and controls on a sample before approving a substitute.

    Is the BOE QV190FBM-N10 still available, and how do I check for end of life?

    Send us the exact rear-label model and revision, requested quantity and required date. Ask for current supply for that revision and any dated manufacturer notice. If the revision is unavailable, we can review a candidate for sample qualification.

    Can I keep the original LCD and add touch, a cover, or a revised cable?

    The listed panel has no touch layer. We can review the cover, touch stack or cable around the original panel. Send us the enclosure drawing, required controller connections, sample quantity and production forecast. Ask for feasible changes, any one-time development charges, production MOQ and separate sample and production lead times.

    Información complementaria

    Tamaño:

    Número de modelo

    QV190FBM-N10

    Resolución:

    Interfaz:

    Temperatura de funcionamiento:

    -0℃~50℃

    Brillo (cd/m²):

    300

    Compatible con pantallas táctiles:

    Tipo de pantalla:
