G080UAN02.2 AUO 8 pulgadas TFT LCD 1200*1920 píxeles

SKU: DS50005
Tamaño:

Número de modelo

G080UAN02.2

Resolución:

Interfaz:

Brillo (cd/m²):

460

Temperatura de funcionamiento:

-10℃~60℃

Compatible con pantallas táctiles:

Tipo de pantalla:

Recursos:

G080UAN02.2 from Brand AUO, Resolution 1200*1920, Operating Temperature from -0~50℃, 4 line MIPI, Stable supply, Original A grade quality

Solicitar precios por volumen







    Descripción

    G080UAN02.2 General Description

    G080UAN02.0 is a Color Active Matrix Liquid Crystal Display composed of a TFT LCD panel, a driver circuit, and LED backlight system. The screen format is intended to support the 16:10 , 1200(H) x1920(V) screen and 16.7M colors (RGB 8-bits data driver) without LED backlight driving circuit. All input signals are MIPI interface compatible. G080UAN02.0 is designed for a display unit of notebook style personal computer and industrial machine.



    G080UAN02.2 AUO Display Characteristics

    The G080UAN02.2 8 inch TFT LCD features an active area of 107.64 mm (H) x 172.224 mm (V), and a resolution of 1200 x 1920 pixels, arranged in a RGB vertical stripe format with a pixel pitch of 0.0897 mm. Operating in a normally black display mode, it achieves a white luminance of 390 cd/m², with a minimum luminance uniformity of 80% and a typical contrast ratio of 900:1. The module has a response time of 25 ms and operates at a nominal input voltage of +3.3V, with an LCD power consumption of 495 mW. Its physical dimensions include a length of approximately 114.6 mm, a width of 184.125 mm, and a thickness of 3.95 mm. The display utilizes a 4-lane MIPI electrical interface, features a glass thickness of 0.2 mm, and has a glare surface treatment. It supports RGB 8-bit color and operates effectively within a temperature range of 0°C to +50°C, with storage capabilities from -10°C to +60°C. The module is also RoHS compliant, ensuring adherence to environmental standards.

    8.0" TFT-LCD Product Specifications

    Número de modelo G080UAN02.2
    Talla 8.0
    Resolución 1200*1920
    Contorno Dimensión 114.6*184.125*3.95
    Área activa 107.64*172.224
    Brillo(cd/m²) 460
    Interfaz MIPI
    Ver Dirección ALL
    Temperatura de funcionamiento -10~60
    Temperatura de almacenamiento -20~70
    Vida útil del LED 15000
    Soporte de pantalla táctil Sin
    Relación de contraste 900:1
    Fuente de alimentación 3.3V
    Tipo de pantalla LCD en color

    8.0" TFT LCD Custom Solutions

    Optimice sus soluciones de cableado

    Ajuste la longitud, la posición y el pinout de sus cables, o añada conectores adicionales para mejorar la funcionalidad. Obtenga una solución de cable personalizada diseñada para agilizar sus conexiones y garantizar un rendimiento seguro y fiable.

    Modificaciones de PCB

    Elija entre una gran variedad de variaciones en la forma de la placa de circuito impreso, el tamaño, la disposición de las patillas y los componentes para que se adapte totalmente a su aplicación.

    Mejore la experiencia del usuario con la tecnología de pantalla táctil

    Mejore su experiencia de usuario con tecnología de pantalla táctil capacitiva o resistiva. Personalizaremos el grosor del cristal y la forma del panel táctil para garantizar un ajuste perfecto a sus requisitos de diseño.

    custom touch

    Tapa de cristal a medida

    Equipe su pantalla con una cubierta de cristal cortada a medida para aumentar la durabilidad y el rendimiento. Elija entre varios grosores y opte por la adhesión óptica para protegerla de la humedad y la suciedad, garantizando una solución duradera y fiable.

    AUO G080UAN02.2 8-Inch LCD Replacement FAQ

    How do I confirm that I need the AUO G080UAN02.2?

    Send us a clear photo showing the full model suffix and revision on the old panel label, the connector side, and the equipment model. Start with the listed 8-inch display, then check the drawing for the outline, visible opening, thickness, mounting points and connector clearance.

    Can I reuse the existing MIPI cable and controller with the AUO G080UAN02.2?

    For the listed MIPI interface, match the display lane count, lane mapping, operating mode and panel initialization sequence. Check the existing backlight supply and enable/dim signals as well. Two connectors that look identical can carry different signals.

    TFT LCD datasheet integration guide

    How do I qualify a different panel as a replacement for the AUO G080UAN02.2?

    Use 1200 × 1920 to shortlist a candidate while keeping the complete interface and mechanical requirements in your acceptance criteria. Compare the outline and mounting points, connector position and pinout, power and backlight signals, and video timing. Test the original graphics and controls on a sample before approving a substitute.

    Is the AUO G080UAN02.2 still available, and how do I check for end of life?

    Send us the exact rear-label model and revision, requested quantity and required date. Ask for current supply for that revision and any dated manufacturer notice. If the revision is unavailable, we can review a candidate for sample qualification.

    Can I keep the original LCD and add touch, a cover, or a revised cable?

    The listed panel has no touch layer. We can review the cover, touch stack or cable around the original panel. Send us the enclosure drawing, required controller connections, sample quantity and production forecast. Ask for feasible changes, any one-time development charges, production MOQ and separate sample and production lead times.

    Información complementaria

    Tamaño:

    Número de modelo

    G080UAN02.2

    Resolución:

    Interfaz:

    Brillo (cd/m²):

    460

    Temperatura de funcionamiento:

    -10℃~60℃

    Compatible con pantallas táctiles:

    Tipo de pantalla:

    Soluciones de exposición personalizadas

    Trabaje con nuestros expertos en ingeniería para crear la pantalla perfecta para su aplicación.
