14" AMOLED 1920x1200 Display | EDP Interface | 400nits | Touch Screen

UGS : DS10050
Taille :

Résolution :

Interface :

Température de fonctionnement :

-10℃~60℃

Luminosité (cd/m²) :

400

Prise en charge de l'écran tactile :

Type d'affichage :

Ressources :

14" AMOLED with 192x120 resolution, EDP interface & 400nits brightness. -10℃~60℃ operation, 178° full viewing angle, 10-point touch. Ideal for industrial/medical devices.

Demande de tarification au volume







    Description

    14" AMOLED

    14" FHD+ AMOLED Panel with EDP Interface & Industrial-Grade Touch
    Engineered for premium applications, this 14-inch AMOLED delivers 1920x1200 resolution (162 PPI) with 400nits brightness and 100% DCI-P3 color accuracy.



    14" AMOLED Core advantages

    EDP 1.4 Interface: 60Hz refresh rate, 6-lane support for 4K-ready performance
    10-Point Projected Capacitive Touch: Glove/wet-hand operation compatible
    Wide Temp Range: Stable performance from -10℃ to 60℃
    True 178° Viewing Angle: Anti-reflection coating for sunlight readability
    Certified IP65 dust/water resistance (optional). Ideal for aviation HMI, medical monitors, and rugged tablets. Custom OEM solutions with 100000:1 contrast ratio and <1ms response time.
    RoHS/CE/FCC compliant. Contact for volume pricing and technical support.

    14" Amoled Display Product Specifications

    LCD Size(inch) 14(Diagonal)
    Number of Pixels 1920*1200
    Pixel Pitch(um) 157.2*157.2
    Outline Dimension(mm) 67.716*140.654*0.84
    Active Area(mm) 301.824*188.640
    Display type AMOLED
    Interface EDP
    Voir la direction ALL
    Power Supply(v) 3.3
    Luminance(cd/m²) 400
    Drive IC HX8874
    Touch IC HX8191
    - -
    - -
    - -

    14" Amoled Custom Solutions

    Optimisez vos solutions de câblage

    Ajustez la longueur, la position et le brochage de vos câbles, ou ajoutez des connecteurs supplémentaires pour améliorer la fonctionnalité. Obtenez une solution de câblage personnalisée conçue pour rationaliser vos connexions et garantir des performances sûres et fiables.

    Personnalisation de l'interface LCD

    Choisissez parmi une gamme variée d'options d'interface ou consultez nos experts pour trouver celle qui convient le mieux à votre projet. Nous pouvons intégrer des interfaces HDMI, USB, SPI, VGA et autres dans votre écran, pour vous aider à atteindre efficacement vos objectifs de conception.

    Améliorer l'expérience de l'utilisateur grâce à la technologie de l'écran tactile

    Améliorez votre expérience utilisateur grâce à la technologie des écrans tactiles capacitifs ou résistifs. Nous personnaliserons l'épaisseur du verre et la forme de l'écran tactile pour qu'il réponde parfaitement à vos exigences en matière de conception.

    custom touch

    Verre de couverture sur mesure

    Équipez votre écran d'une vitre de protection découpée sur mesure pour améliorer sa durabilité et ses performances. Choisissez parmi différentes épaisseurs et optez pour le collage optique afin d'assurer une protection contre l'humidité et les débris, garantissant ainsi une solution durable et fiable.

    14-Inch eDP AMOLED Display Module FAQ

    Will this display fit my enclosure and show the whole interface?

    Use the 14-inch diagonal to shortlist display modules, then check the exact drawing for fit. Overlay the visible area, module outline and flex exit on your enclosure drawing. Get the native pixel layout first, then try your menus and text at that layout before committing to the enclosure.

    What must my controller support to drive this display module?

    For the listed eDP interface, match lane count, link rate, power sequencing and connector pinout. Before connecting it, check the power rails and reset sequence in the module documentation.

    How should I compare this display with a similar module for my device?

    For the listed AMOLED, compare dark-scene legibility and how your static icons look in an extended run at the intended brightness. Use the listed 400 cd/m² to shortlist the display, then judge the assembled product with its final cover and ambient lighting. Compare the cost and space of any changes to the cable, host board or front cover.

    Can I change the flex cable, add a cover, or integrate touch?

    Send us the mounting drawing, permitted flex exit, connector and cover or touch requirements. We can review which of those changes can be made around the existing display and which require a different module.

    What determines the cost and lead time of a custom display sample?

    Include your display outline, interface, target sample date and estimated annual volume. We can quote the proposed changes, any one-time tooling or engineering, sample price and production MOQ separately. Ask for distinct sample and production lead times on the quoted drawing revision.

    Solutions d'affichage personnalisées

    Informations complémentaires

    Taille :

    Résolution :

    Interface :

    Température de fonctionnement :

    -10℃~60℃

    Luminosité (cd/m²) :

    400

    Prise en charge de l'écran tactile :

    Type d'affichage :

    Solutions d'affichage personnalisées

    Travaillez avec nos experts en ingénierie pour créer le présentoir parfait pour votre application.
