28.6” Bar Type High Brightness TFT Display 1920x540 Innolux S290AJ1-LE2 Rev.C2

UGS : DS50307
Taille :

Numéro de modèle

S290AJ1-LE2 Rev.C2

Résolution :

Interface :

Température de fonctionnement :

-0℃~50℃

Luminosité (cd/m²) :

1000

Prise en charge de l'écran tactile :

Type d'affichage :

28.6" Bar Type High Brightness TFT Display, model number Innolux S290AJ1-LE2 Rev.C2, Resolution 1920x540, High contrast ratio, long lifespan

Demande de tarification au volume







    Description

    28.6" Bar Type High Brightness TFT Description

    This 28.6 inch Bar Type high brightness TFT Display screen, with a resolution of 1920x540, 1000nits can be used in information display boards in trains, subways, airports, etc., as well as in indoor and outdoor Android advertising displays.

    Offering original A-grade Innolux products. This model has been discontinued by the Innolux manufacturer, and we recommend other alternative products during the selection phase. For detailed alternative models, please consult our sales staff.

    28.6" LCD Display Specifications

    Numéro de modèle S290AJ1-LE2 Rev.C2
    Taille 28.6
    Résolution 1920*540
    Dimension de l'ébauche 720.8*226.3*26.8
    Zone active 698.4*196.425
    Luminosité (cd/m²) 1000
    Interface LVDS
    Voir la direction IPS
    Température de fonctionnement -0~50
    Température de stockage -20~60
    Durée de vie des LED 50000
    Prise en charge de l'écran tactile No
    Rapport de contraste 4500:1
    Alimentation électrique 12V
    Type d'affichage LCD couleur

    28.6" Bar Type TFT Display Custom Solutions

    Optimisez vos solutions de câblage

    Ajustez la longueur, la position et le brochage de vos câbles, ou ajoutez des connecteurs supplémentaires pour améliorer la fonctionnalité. Obtenez une solution de câblage personnalisée conçue pour rationaliser vos connexions et garantir des performances sûres et fiables.

    Personnalisation de l'interface LCD

    Choisissez parmi une gamme variée d'options d'interface ou consultez nos experts pour trouver celle qui convient le mieux à votre projet. Nous pouvons intégrer des interfaces HDMI, USB, SPI, VGA et autres dans votre écran, pour vous aider à atteindre efficacement vos objectifs de conception.

    Améliorer l'expérience de l'utilisateur grâce à la technologie de l'écran tactile

    Améliorez votre expérience utilisateur grâce à la technologie des écrans tactiles capacitifs ou résistifs. Nous personnaliserons l'épaisseur du verre et la forme de l'écran tactile pour qu'il réponde parfaitement à vos exigences en matière de conception.

    custom touch

    Verre de couverture sur mesure

    Équipez votre écran d'une vitre de protection découpée sur mesure pour améliorer sa durabilité et ses performances. Choisissez parmi différentes épaisseurs et optez pour le collage optique afin d'assurer une protection contre l'humidité et les débris, garantissant ainsi une solution durable et fiable.

    Innolux S290AJ1-LE2 REV.C2 28.6-Inch Stretched Bar LCD FAQ

    How do I confirm that I need the Innolux S290AJ1-LE2 REV.C2?

    Send us a clear photo showing the full model suffix and revision on the old panel label, the connector side, and the equipment model. Start with the listed 28.6-inch display, then check the drawing for the outline, visible opening, thickness, mounting points and connector clearance.

    Can I reuse the existing LVDS cable and controller with the Innolux S290AJ1-LE2 REV.C2?

    Check the connector pinout, video timing, panel supply and backlight enable or dimming against the exact drawing. Send us the controller model or cable diagram before reusing the harness.

    TFT LCD datasheet integration guide

    How do I qualify a different panel as a replacement for the Innolux S290AJ1-LE2 REV.C2?

    Use 1920 × 540 to shortlist a candidate while keeping the complete interface and mechanical requirements in your acceptance criteria. Compare the outline and mounting points, connector position and pinout, power and backlight signals, and video timing. Test the original graphics and controls on a sample before approving a substitute.

    Is the Innolux S290AJ1-LE2 REV.C2 still available, and how do I check for end of life?

    Send us the exact rear-label model and revision, requested quantity and required date. Ask for current supply for that revision and any dated manufacturer notice. If the revision is unavailable, we can review a candidate for sample qualification.

    Can I keep the original LCD and add touch, a cover, or a revised cable?

    The listed panel has no touch layer. We can review the cover, touch stack or cable around the original panel. Send us the enclosure drawing, required controller connections, sample quantity and production forecast. Ask for feasible changes, any one-time development charges, production MOQ and separate sample and production lead times.

    Informations complémentaires

    Taille :

    Numéro de modèle

    S290AJ1-LE2 Rev.C2

    Résolution :

    Interface :

    Température de fonctionnement :

    -0℃~50℃

    Luminosité (cd/m²) :

    1000

    Prise en charge de l'écran tactile :

    Type d'affichage :
