5 Inch In-cell Touch TFT LCD Display 720x1440 MIPI IPS | 500 Nits High Brightness

UGS : DS20341
Taille :

Résolution :

Interface :

Température de fonctionnement :

-20℃~70℃

Luminosité (cd/m²) :

500

Prise en charge de l'écran tactile :

Type d'affichage :

Industrial-grade 5" TFT LCD module with integrated In-cell capacitive touch, 720x1440 HD resolution, and MIPI interface. IPS full viewing angle, -20~70°C working temp. Supports custom brightness, glass & logo.

Demande de tarification au volume







    Description

    5 inch In-cell touch display

    This high-performance 5-inch TFT LCD module features a state-of-the-art In-cell capacitive touch design, integrating the touch sensor directly into the display for an ultra-slim profile and superior optical clarity. With 720x1440 HD resolution and IPS technology, it delivers vibrant colors and a full viewing angle (80/80/80/80). Engineered for reliability, it operates within -20°C to 70°C, making it perfect for handheld devices, medical monitors, and smart home controllers. No MOQ and full OEM/ODM customization (logo, interface, brightness) supported.

    Key Advantages:
    In-cell Integrated Touch: Ultra-thin design with higher light transmittance and better touch sensitivity compared to traditional OGS/G+G structures.
    HD Portrait Screen: 720x1440 high-density resolution provides crisp visuals for modern UI interfaces.
    IPS All-around View: Consistent color and contrast from any angle, essential for handheld and industrial applications.
    Industrial Grade Reliability: Wide temperature range (-20~70°C) and long-life backlight ensure stable performance in harsh environments.
    Flexible Customization: Direct support for interface conversion, brightness enhancement (up to 1000+ nits), and cover glass branding.

    Technical Specifications

    Numéro de modèle ZXYQ050MF025G
    Taille 5 pouces
    Résolution 720(RGB)*1440
    Dimension de l'ébauche 64.6 (H) × 117.3 (V) × 2.38(D)(with touch cover
    Zone active 62.10 (H) × 110.40 (V)
    Luminosité (cd/m²) 500
    Interface MIPI(4-Lane)
    Voir la direction IPS
    Température de fonctionnement -20~70
    Température de stockage -30~80
    Durée de vie des LED 30000
    Prise en charge de l'écran tactile Sur mesure
    Rapport de contraste 800:1
    Alimentation électrique 3.3V
    Type d'affichage LCD couleur

    5" TFT Custom Solutions

    Optimisez vos solutions de câblage

    Ajustez la longueur, la position et le brochage de vos câbles, ou ajoutez des connecteurs supplémentaires pour améliorer la fonctionnalité. Obtenez une solution de câblage personnalisée conçue pour rationaliser vos connexions et garantir des performances sûres et fiables.

    Personnalisation de l'interface LCD

    Choisissez parmi une gamme variée d'options d'interface ou consultez nos experts pour trouver celle qui convient le mieux à votre projet. Nous pouvons intégrer des interfaces HDMI, USB, SPI, VGA et autres dans votre écran, pour vous aider à atteindre efficacement vos objectifs de conception.

    Améliorer l'expérience de l'utilisateur grâce à la technologie de l'écran tactile

    Améliorez votre expérience utilisateur grâce à la technologie des écrans tactiles capacitifs ou résistifs. Nous personnaliserons l'épaisseur du verre et la forme de l'écran tactile pour qu'il réponde parfaitement à vos exigences en matière de conception.

    custom touch

    Verre de couverture sur mesure

    Équipez votre écran d'une vitre de protection découpée sur mesure pour améliorer sa durabilité et ses performances. Choisissez parmi différentes épaisseurs et optez pour le collage optique afin d'assurer une protection contre l'humidité et les débris, garantissant ainsi une solution durable et fiable.

    5-Inch 720 × 1440 High-Brightness LCD Display FAQ

    Will this display be readable through my outdoor enclosure window?

    Use the listed 500 cd/m² to shortlist the display, then judge the assembled product with its final cover and ambient lighting. Test your smallest text in direct sun and at the worst reflection angle. Record the cover finish and viewing distance so you can repeat the test on later samples.

    Sunlight Readable TFT Displays

    What must my controller and power supply support in an outdoor installation?

    For the listed MIPI interface, match the display lane count, lane mapping, operating mode and panel initialization sequence. Verify the backlight supply, dimming control and enclosure cooling using the exact panel documentation.

    How should I compare high-brightness displays behind the same cover?

    Use the 5-inch diagonal to shortlist high-brightness displays, then check the exact drawing for fit. Compare readability and temperature inside the same enclosure at the brightness needed to read the UI. Try your actual interface rather than a full-screen test image on a 720 × 1440 canvas before committing to the enclosure.

    Can the cover treatment, touch, or brightness be adapted to my installation?

    Send the opening, viewing distance, ambient light and maximum temperature at the panel. We can review cover finish, optical bonding or touch options and where a different panel or backlight design may be needed.

    What information is needed for a sample quote for an outdoor display?

    Include the cover stack, ambient light, temperature range, annual volume and target sample date. We can quote the proposed changes, any one-time tooling or engineering, sample price and production MOQ separately. Ask for distinct sample and production lead times on the quoted drawing revision.

    Informations complémentaires

    Taille :

    Résolution :

    Interface :

    Température de fonctionnement :

    -20℃~70℃

    Luminosité (cd/m²) :

    500

    Prise en charge de l'écran tactile :

    Type d'affichage :

    Solutions d'affichage personnalisées

    Travaillez avec nos experts en ingénierie pour créer le présentoir parfait pour votre application.
