AT070TN94 Écran LCD 7 pouces - Luminosité 400cd/m², fonctionnement à température élevée (-30°C~85°C)

UGS : DS50213
Taille :

Numéro de modèle

T070TN94

Résolution :

Interface :

Température de fonctionnement :

-30℃~ 85℃

Luminosité (cd/m²) :

400

Prise en charge de l'écran tactile :

Type d'affichage :

Ressources :

Innolux AT070TN94 7" Sunlight-Readable LCD: 400cd/m² Brightness, -30°C~85°C Endurance for Industrial Automation & Outdoor Tech.

Demande de tarification au volume







    Description

    AT070TN94 General Desription

    The Innolux AT070TN94 is a 7-inch TFT LCD designed for demanding applications, featuring 800×480 resolution and 400cd/m² high brightness for clear visibility under direct sunlight. With a TN panel offering 500:1 contrast ratio and a compact outline (164.9×100×6mm), it integrates seamlessly into space-constrained systems. Its industrial-grade design supports operation from -30°C to 85°C, ensuring reliability in extreme conditions. The RGB interface delivers stable signal transmission, while a low-power design (3.3V~16V) reduces energy consumption. Backed by 20,000-hour LED lifespan, this display is built for long-term deployment in automation, transportation, or outdoor digital signage without touchscreen distractions.



    Application & Performanc

    Engineered for rugged environments, the AT070TN94 excels in industrial control panels, heavy machinery HMI, and outdoor kiosks where temperature fluctuations and dust exposure are common. Its 70/70/50/70 viewing angles ensure readability from multiple positions in vehicle dashboards or medical monitoring devices. The anti-glare surface and 400cd/m² brightness combat sunlight interference in agricultural equipment or construction-site displays. With vibration resistance and wide voltage compatibility (3.3~16V), it reliably powers logistics tracking systems, factory automation, and HVAC controllers. The 6mm slim profile allows integration into portable field instruments or compact IoT terminals requiring durable visual feedback.

    7.0" Product Specifications

    Taille de la diagonale 7.0"
    Nombre de pixels 800×480
    Luminance 400
    Module Size 164.9×100×6
    Zone active 154.08×85.92
    Direction de visualisation TN
    View Angle(U/D/R/L) 70/70/50/70
    Interface RVB
    Rapport de contraste 500:1
    Température de fonctionnement -30~85℃
    Température de stockage -30~85℃
    Durée de vie des LED 20000
    Prise en charge de l'écran tactile Sans
    Alimentation électrique 3.3/10.4/16.0/-7.0V
    Type d'affichage Color TFT

    Innolux LCD Display Custom Solutions

    Optimisez vos solutions de câblage

    Ajustez la longueur, la position et le brochage de vos câbles, ou ajoutez des connecteurs supplémentaires pour améliorer la fonctionnalité. Obtenez une solution de câblage personnalisée conçue pour rationaliser vos connexions et garantir des performances sûres et fiables.

    Modifications de la carte de circuit imprimé

    Choisissez parmi une variété de variations dans la forme du circuit imprimé, la taille, la disposition des broches et des composants pour l'adapter parfaitement à votre application.

    Améliorer l'expérience de l'utilisateur grâce à la technologie de l'écran tactile

    Améliorez votre expérience utilisateur grâce à la technologie des écrans tactiles capacitifs ou résistifs. Nous personnaliserons l'épaisseur du verre et la forme de l'écran tactile pour qu'il réponde parfaitement à vos exigences en matière de conception.

    custom touch

    Verre de couverture sur mesure

    Équipez votre écran d'une vitre de protection découpée sur mesure pour améliorer sa durabilité et ses performances. Choisissez parmi différentes épaisseurs et optez pour le collage optique afin d'assurer une protection contre l'humidité et les débris, garantissant ainsi une solution durable et fiable.

    Innolux AT070TN94 7-Inch LCD Replacement FAQ

    How do I confirm that I need the Innolux AT070TN94?

    Send us a clear photo showing the full model suffix and revision on the old panel label, the connector side, and the equipment model. Start with the listed 7-inch display, then check the drawing for the outline, visible opening, thickness, mounting points and connector clearance.

    Can I reuse the existing RGB cable and controller with the Innolux AT070TN94?

    For the listed RGB interface, match data width, pixel clock, sync polarities and blanking to the panel timing sheet. Check the existing backlight supply and enable/dim signals as well. Two connectors that look identical can carry different signals.

    TFT LCD datasheet integration guide

    How do I qualify a different panel as a replacement for the Innolux AT070TN94?

    Compare the outline and mounting points, connector position and pinout, power and backlight signals, and video timing. Test the original graphics and controls on a sample before approving a substitute.

    Is the Innolux AT070TN94 still available, and how do I check for end of life?

    Send us the exact rear-label model and revision, requested quantity and required date. Ask for current supply for that revision and any dated manufacturer notice. If the revision is unavailable, we can review a candidate for sample qualification.

    Can I keep the original LCD and add touch, a cover, or a revised cable?

    The listed panel has no touch layer. We can review the cover, touch stack or cable around the original panel. Send us the enclosure drawing, required controller connections, sample quantity and production forecast. Ask for feasible changes, any one-time development charges, production MOQ and separate sample and production lead times.
