IVO M084GNS1 R1 8.4'' TFT LCD Panel 800x600 LVDS 80/80/80/80 TN 50K Hrs -20℃~70℃

UGS : DS50090
Taille :

Numéro de modèle

M084GNS1 R1

Résolution :

Interface :

Prise en charge de l'écran tactile :

Type d'affichage :

Luminosité (cd/m²) :

350

Température de fonctionnement :

-20℃~70℃

Ressources :

IVO M084GNS1 R1: 8.4'' TN LCD with 800x600 LVDS, -20℃~70℃ range, 50K lifespan. Ideal for industrial, medical & outdoor applications. RoHS compliant

Demande de tarification au volume







    Description

    IVO m084gns1 r1 General Description

    The IVO M084GNS1 R1 is an 8.4 inch TFT LCD panel engineered for industrial, commercial, and embedded applications requiring high durability and stable performance. With an 800x600 resolution (SVGA), this TN (Twisted Nematic) panel delivers sharp visuals and supports 80/80/80/80 viewing angles (horizontal/vertical, CR≥10), ensuring readability across diverse lighting conditions.



    Key Features:

    High Compatibility: LVDS interface ensures seamless integration with industrial control systems, medical devices, POS terminals, and automation equipment.
    Extended Lifespan: Rated for 50,000 hours of continuous operation, minimizing downtime and maintenance costs.
    Wide Temperature Range: Operates reliably in extreme environments (-20℃ to 70℃), ideal for outdoor or harsh industrial settings.
    Robust Construction: TN panel technology balances cost-efficiency with performance, resistant to flicker and signal interference.
    Standard Specifications: 4:3 aspect ratio, 6/5/6/6-bit color depth, and 300:1 contrast ratio for clear image reproduction.

    8.4" TFT-LCD Product Specifications

    Numéro de modèle M084GNS1 R1
    Taille 8.4
    Résolution 800(RGB)×600
    Dimension de l'ébauche 203×142.5×6.2
    Zone active 170.4×127.8
    Luminosité (cd/m²) 350
    Interface LVDS 20pin
    Voir la direction TN
    Température de fonctionnement -20~70
    Température de stockage -30~80
    Durée de vie des LED 50000
    Prise en charge de l'écran tactile Sans
    Rapport de contraste 600:1
    Alimentation électrique 3.3V
    Type d'affichage LCD couleur

    8.4" TFT LCD Custom Solutions

    Optimisez vos solutions de câblage

    Ajustez la longueur, la position et le brochage de vos câbles, ou ajoutez des connecteurs supplémentaires pour améliorer la fonctionnalité. Obtenez une solution de câblage personnalisée conçue pour rationaliser vos connexions et garantir des performances sûres et fiables.

    Modifications de la carte de circuit imprimé

    Choisissez parmi une variété de variations dans la forme du circuit imprimé, la taille, la disposition des broches et des composants pour l'adapter parfaitement à votre application.

    Améliorer l'expérience de l'utilisateur grâce à la technologie de l'écran tactile

    Améliorez votre expérience utilisateur grâce à la technologie des écrans tactiles capacitifs ou résistifs. Nous personnaliserons l'épaisseur du verre et la forme de l'écran tactile pour qu'il réponde parfaitement à vos exigences en matière de conception.

    custom touch

    Verre de couverture sur mesure

    Équipez votre écran d'une vitre de protection découpée sur mesure pour améliorer sa durabilité et ses performances. Choisissez parmi différentes épaisseurs et optez pour le collage optique afin d'assurer une protection contre l'humidité et les débris, garantissant ainsi une solution durable et fiable.

    IVO M084GNS1 R1 8.4-Inch LCD Replacement FAQ

    How do I confirm that I need the IVO M084GNS1 R1?

    Send us a clear photo showing the full model suffix and revision on the old panel label, the connector side, and the equipment model. Start with the listed 8.4-inch display, then check the drawing for the outline, visible opening, thickness, mounting points and connector clearance.

    Can I reuse the existing LVDS cable and controller with the IVO M084GNS1 R1?

    For the listed LVDS interface, match the connector pinout, channel count, data mapping and panel supply before applying power. Check the existing backlight supply and enable/dim signals as well. Two connectors that look identical can carry different signals.

    TFT LCD datasheet integration guide

    How does the IVO M084GNS1 R1 compare with the AUO G084SN05 V904?

    Both catalog listings show 8.4 inches, 800 × 600 and LVDS. The catalog lists −20 °C to +70 °C for the IVO panel and −30 °C to +80 °C for the AUO panel. Compare the outline and mounting points, connector position and pinout, power and backlight signals, and video timing. Test the original graphics and controls on a sample before approving a substitute.

    Compare AUO G084SN05 V904

    Is the IVO M084GNS1 R1 still available, and how do I check for end of life?

    Send us the exact rear-label model and revision, requested quantity and required date. Ask for current supply for that revision and any dated manufacturer notice. If the revision is unavailable, we can review a candidate for sample qualification.

    Can I keep the original LCD and add touch, a cover, or a revised cable?

    The listed panel has no touch layer. We can review the cover, touch stack or cable around the original panel. Send us the enclosure drawing, required controller connections, sample quantity and production forecast. Ask for feasible changes, any one-time development charges, production MOQ and separate sample and production lead times.
