TIANMA TM101JDHG33-00 10.1 inch Ultra-Bright IPS Screen LCD with 1280×800 Resolution for Extreme Environments

UGS : DS50249
Taille :

Numéro de modèle

M101JDHG33-00

Résolution :

Interface :

Température de fonctionnement :

-30℃~80℃

Prise en charge de l'écran tactile :

Type d'affichage :

TIANMA tm101jdhg33-00 900cd/m² Ultra-Bright IPS LCD Display for Sunlight Use – 1280×800 & -40°C~80°C Endurance.

Demande de tarification au volume







    Description

    TM101JDHG33-00 General Desription

    The TIANMA TM101JDHG33-00 is a 10.1-inch IPS LCD module featuring 1280×800 high resolution and 900 cd/m² ultra-high brightness, designed for applications demanding sunlight readability and wide viewing angles. Its IPS panel ensures consistent 85/85/85/85 viewing angles and 700:1 contrast ratio, delivering vivid visuals even in harsh lighting. Built for extreme durability, it operates in -30°C to 80°C and stores in -40°C to 80°C, supported by a 40,000-hour LED lifespan. The LVDS interface guarantees stable signal transmission for industrial systems, while the 3.3V low-power design reduces energy consumption. With a slim 229.8×149×9.6mm profile, it excels in rugged and space-sensitive installations.



    Application & Performanc

    Ideal for outdoor military displays, aviation cockpit panels, and maritime navigation systems, this display thrives in direct sunlight for solar power plant controls and desert logistics terminals. The 900 cd/m² brightness ensures clarity in airport runway signage and mining equipment HMIs, while its IPS technology suits medical imaging monitors and surgical equipment displays. The extended temperature range supports Arctic oilfield sensors and automotive test chamber dashboards. Compatible with industrial automation via LVDS, it powers smart grid control panels, robotic vision systems, and EV charging station interfaces. Perfect for public transport infotainment, emergency response vehicles, and high-altitude weather stations requiring unmatched reliability.

    10.1" Product Specifications

    Taille de la diagonale 10,1 pouces
    Nombre de pixels 1280×800
    Luminance 900
    Module Size 229.8×149×9.6
    Zone active 216.96×135.6
    Direction de visualisation IPS
    View Angle(U/D/R/L) 85/85/85/85
    Interface LVDS
    Rapport de contraste 700:1
    Température de fonctionnement -30 ~ 80 °C
    Température de stockage -40 ~ 80 °C
    Durée de vie des LED 40000
    Prise en charge de l'écran tactile Sans
    Alimentation électrique 3.3V
    Type d'affichage Color TFT

    TIANMA LCD Display Custom Solutions

    Optimisez vos solutions de câblage

    Ajustez la longueur, la position et le brochage de vos câbles, ou ajoutez des connecteurs supplémentaires pour améliorer la fonctionnalité. Obtenez une solution de câblage personnalisée conçue pour rationaliser vos connexions et garantir des performances sûres et fiables.

    Modifications de la carte de circuit imprimé

    Choisissez parmi une variété de variations dans la forme du circuit imprimé, la taille, la disposition des broches et des composants pour l'adapter parfaitement à votre application.

    Améliorer l'expérience de l'utilisateur grâce à la technologie de l'écran tactile

    Améliorez votre expérience utilisateur grâce à la technologie des écrans tactiles capacitifs ou résistifs. Nous personnaliserons l'épaisseur du verre et la forme de l'écran tactile pour qu'il réponde parfaitement à vos exigences en matière de conception.

    custom touch

    Verre de couverture sur mesure

    Équipez votre écran d'une vitre de protection découpée sur mesure pour améliorer sa durabilité et ses performances. Choisissez parmi différentes épaisseurs et optez pour le collage optique afin d'assurer une protection contre l'humidité et les débris, garantissant ainsi une solution durable et fiable.

    Tianma TM101JDHG33-00 10.1-Inch LCD Replacement FAQ

    How do I confirm that I need the Tianma TM101JDHG33-00?

    Send us a clear photo showing the full model suffix and revision on the old panel label, the connector side, and the equipment model. Start with the listed 10.1-inch display, then check the drawing for the outline, visible opening, thickness, mounting points and connector clearance.

    Can I reuse the existing LVDS cable and controller with the Tianma TM101JDHG33-00?

    For the listed LVDS interface, match the connector pinout, channel count, data mapping and panel supply before applying power. Check the existing backlight supply and enable/dim signals as well. Two connectors that look identical can carry different signals.

    TFT LCD datasheet integration guide

    How does the Tianma TM101JDHG33-00 compare with the AUO G101EAN02.1?

    Both catalog listings show 10.1 inches, 1280 × 800 and LVDS. The catalog lists −30 °C to +80 °C for the Tianma panel and −20 °C to +60 °C for the AUO panel. Compare the outline and mounting points, connector position and pinout, power and backlight signals, and video timing. Test the original graphics and controls on a sample before approving a substitute.

    Compare AUO G101EAN02.1

    Is the Tianma TM101JDHG33-00 still available, and how do I check for end of life?

    Send us the exact rear-label model and revision, requested quantity and required date. Ask for current supply for that revision and any dated manufacturer notice. If the revision is unavailable, we can review a candidate for sample qualification.

    Can I keep the original LCD and add touch, a cover, or a revised cable?

    The listed panel has no touch layer. We can review the cover, touch stack or cable around the original panel. Send us the enclosure drawing, required controller connections, sample quantity and production forecast. Ask for feasible changes, any one-time development charges, production MOQ and separate sample and production lead times.

    Informations complémentaires

    Taille :

    Numéro de modèle

    M101JDHG33-00

    Résolution :

    Interface :

    Température de fonctionnement :

    -30℃~80℃

    Prise en charge de l'écran tactile :

    Type d'affichage :

    Solutions d'affichage personnalisées

    Travaillez avec nos experts en ingénierie pour créer le présentoir parfait pour votre application.
