4.3" TFT LCD Display 480x800 | Industrial MCU Interface Screen

COD: DS20323-1
Dimensioni:

Risoluzione:

Interfaccia:

Temperatura di esercizio:

-20℃~70℃

Luminosità (cd/m²):

400

Supporto per touchscreen:

Tipo di display:

Industrial-grade 4.3 inch TFT LCD display with 480x800 WVGA resolution. Features 16-bit MCU interface, optional CTP/RTP touch, -20°C to 70°C operating temp. RoHS & REACH compliant. Get a sample now!

Richiesta di prezzi a volume







    Descrizione

    4.3 Inch Industrial TFT LCD Display Module Overview

    This industrial-grade **4.3-inch TFT LCD Display Module** delivers a crisp **480x800 WVGA resolution** in a sleek vertical screen layout. Built with standard **Normally Black transmissive display technology**, it provides superior color contrast and exceptional wide-angle readability. Equipped with an easy-to-drive **16-bit MCU interface** (powered by the reliable **ILI9806** driver IC), it simplifies your hardware layout and speeds up your development cycle.

    Engineered to endure harsh environments, this 4.3" display is fully **RoHS and REACH compliant** and operates flawlessly within a wide temperature range of **-20°C to +70°C**. It is the ultimate choice for smart home interfaces, medical devices, handheld instruments, and industrial control equipment.

    Key Features & Unique Advantages

    **Direct MCU 16-Bit Interface**: Say goodbye to complex hardware designs. Direct register writing streamlines controller matching and significantly cuts down time-to-market.
    * **Superior Visual Performance**: Vertical 480x800 high-density display using Normally Black technology, ensuring wider viewing angles, deeper contrast, and optimal color fidelity.
    * **Industrial-Grade Reliability**: Wide operating temperature range of -20°C to +70°C and storage temperature of -30°C to +80°C. Tested to pass 200-hour extreme high/low-temperature reliability criteria.
    * **Modular Touch Flexibility**:
    * **CTP Version**: Seamless multi-touch Capacitive Touch Panel powered by **GT911** (I2C interface).
    * **RTP Version**: Durable 4-wire Resistive Touch Panel for gloved or stylus operation.
    * **LCM Version**: Pure display module for low-cost setups.
    * **Full Technical & Customization Support**: RoHS & REACH certified. We supply complete hardware datasheets, sample kits, and comprehensive development guidance.

    Technical Specifications

    Numero di modello 43IPS37P-C
    Dimensione 4.3 inch
    Risoluzione 480*800
    Dimensione del contorno 61.56 (H) × 104.65 (V) × 3.73
    Area attiva 56.16 (H) × 93.60 (V)
    Luminosità (cd/m²) 400
    Interfaccia MCU
    Visualizza la direzione IPS
    Temperatura di esercizio -20~70
    Temperatura di stoccaggio -30~80
    Durata del LED 20000
    Supporto per touchscreen Capacitive touch
    Rapporto di contrasto 200:1
    Alimentazione 3.3V
    Tipo di display LCD a colori

    4.3" TFT Custom Solutions

    Ottimizzate le vostre soluzioni via cavo

    Regolate la lunghezza, la posizione e la piedinatura dei vostri cavi o aggiungete connettori supplementari per migliorare la funzionalità. Ottenete una soluzione di cavi personalizzata, progettata per semplificare le connessioni e garantire prestazioni sicure e affidabili.

    Personalizzazione dell'interfaccia LCD

    Scegliete tra una vasta gamma di opzioni di interfaccia o consultate i nostri esperti per trovare quella ideale per il vostro progetto. Possiamo integrare HDMI, USB, SPI, VGA e altro ancora nel vostro display, aiutandovi a raggiungere i vostri obiettivi di progettazione in modo efficiente.

    Elevare l'esperienza dell'utente con la tecnologia touch screen

    Migliorate la vostra esperienza utente con la tecnologia touch screen capacitiva o resistiva. Personalizzeremo lo spessore del vetro e la forma del pannello tattile per garantire un adattamento perfetto ai vostri requisiti di progettazione.

    custom touch

    Vetro di copertura personalizzato

    Equipaggiate il vostro display con un vetro di copertura tagliato su misura per aumentare la durata e le prestazioni. Scegliete tra vari spessori e optate per l'incollaggio ottico per proteggere il display da umidità e detriti, garantendo una soluzione affidabile e duratura.

    4.3-Inch 480 × 800 TFT LCD Display Module FAQ

    Will this display fit my enclosure and show the whole interface?

    Use the 4.3-inch diagonal to shortlist display modules, then check the exact drawing for fit. Overlay the visible area, module outline and flex exit on your enclosure drawing. Try your menus and text on a 480 × 800 canvas before committing to the enclosure.

    What must my controller support to drive this display module?

    For the listed MCU interface, match the exact bus mode, pin assignments, logic levels and display controller commands. Before connecting it, check the power rails and reset sequence in the module documentation.

    How should I compare this display with a similar module for my device?

    For the listed LCD, compare viewing-angle shifts and dark-screen appearance through the front cover. Use the listed 400 cd/m² to shortlist the display, then judge the assembled product with its final cover and ambient lighting. Compare the cost and space of any changes to the cable, host board or front cover.

    Can I change the flex cable, add a cover, or integrate touch?

    Send us the mounting drawing, permitted flex exit, connector and cover or touch requirements. We can review which of those changes can be made around the existing display and which require a different module.

    What determines the cost and lead time of a custom display sample?

    Include your display outline, interface, target sample date and estimated annual volume. We can quote the proposed changes, any one-time tooling or engineering, sample price and production MOQ separately. Ask for distinct sample and production lead times on the quoted drawing revision.

    Soluzioni espositive personalizzate

    Informazioni aggiuntive

    Dimensioni:

    Risoluzione:

    Interfaccia:

    Temperatura di esercizio:

    -20℃~70℃

    Luminosità (cd/m²):

    400

    Supporto per touchscreen:

    Tipo di display:

    Soluzioni espositive personalizzate

    Collaborate con i nostri esperti di progettazione per creare il display perfetto per la vostra applicazione.
