7 inch TFT Screen High Brightness for Outdoor Display

COD: DS20292
Dimensioni:

Risoluzione:

Interfaccia:

Temperatura di esercizio:

-30℃~ 85℃

Luminosità (cd/m²):

1000

Supporto per touchscreen:

Tipo di display:

7 inch TFT screen, 1000 nits High brightness, 800x480, -30~85 wide Op Temp, Ideal for outdoor harsh environment

Richiesta di prezzi a volume







    Descrizione

    7 inch TFT Screen Description

    With an 800×480 resolution, 1000-nit brightness, and a wide operating temperature range of -30℃~85℃, this display delivers reliable performance in demanding environments. Engineered for industrial control, medical, and military applications, it combines:

    ✅ Extreme Temperature Stability: Operates flawlessly in arctic cold or high-heat conditions, ideal for outdoor machinery or field equipment.
    ✅ High-Brightness Visibility: 1000-nit luminance ensures clear viewing in direct sunlight or brightly lit industrial settings.
    ✅ Rugged Durability: Meets rigorous standards for shock resistance and electromagnetic interference (EMI) protection.
    Quality Assurance:
    Every unit undergoes 72-hour burn-in testing and thermal cycling to ensure industrial-grade reliability. Direct from the R&D team—competitive pricing without compromising on performance.
    Below the basic parameters for it, Tailor the interface (LVDS/RGB/MIPI), brightness, dimensions, and touch solutions (capacitive/resistive) to seamlessly integrate into your device—engineered for hassle-free system integration.

    7" TFT Display Specifications

    Numero di modello ZDX070TNCP50-DB10
    Dimensione 7
    Risoluzione 800*480
    Dimensione del contorno 164.9*100.0*5.7
    Area attiva 154.08*85.92
    Luminosità (cd/m²) 1000
    Interfaccia Digital
    Visualizza la direzione 6
    Temperatura di esercizio -30~85
    Temperatura di stoccaggio -30~85
    Durata del LED 20000
    Supporto per touchscreen No
    Rapporto di contrasto 1000:1
    Alimentazione 3.3V
    Tipo di display LCD a colori

    7" TFT LCD Custom Solutions

    Ottimizzate le vostre soluzioni via cavo

    Regolate la lunghezza, la posizione e la piedinatura dei vostri cavi o aggiungete connettori supplementari per migliorare la funzionalità. Ottenete una soluzione di cavi personalizzata, progettata per semplificare le connessioni e garantire prestazioni sicure e affidabili.

    Personalizzazione dell'interfaccia LCD

    Scegliete tra una vasta gamma di opzioni di interfaccia o consultate i nostri esperti per trovare quella ideale per il vostro progetto. Possiamo integrare HDMI, USB, SPI, VGA e altro ancora nel vostro display, aiutandovi a raggiungere i vostri obiettivi di progettazione in modo efficiente.

    Elevare l'esperienza dell'utente con la tecnologia touch screen

    Migliorate la vostra esperienza utente con la tecnologia touch screen capacitiva o resistiva. Personalizzeremo lo spessore del vetro e la forma del pannello tattile per garantire un adattamento perfetto ai vostri requisiti di progettazione.

    custom touch

    Vetro di copertura personalizzato

    Equipaggiate il vostro display con un vetro di copertura tagliato su misura per aumentare la durata e le prestazioni. Scegliete tra vari spessori e optate per l'incollaggio ottico per proteggere il display da umidità e detriti, garantendo una soluzione affidabile e duratura.

    7-Inch 800 × 480 High-Brightness LCD Display FAQ

    Will this display be readable through my outdoor enclosure window?

    Use the listed 1000 cd/m² to shortlist the display, then judge the assembled product with its final cover and ambient lighting. Test your smallest text in direct sun and at the worst reflection angle. Record the cover finish and viewing distance so you can repeat the test on later samples.

    Sunlight Readable TFT Displays

    What must my controller and power supply support in an outdoor installation?

    Send us your host model so we can check the required interface, pinout and electrical limits against the exact product documentation. Verify the backlight supply, dimming control and enclosure cooling using the exact panel documentation.

    How should I compare high-brightness displays behind the same cover?

    Use the 7-inch diagonal to shortlist high-brightness displays, then check the exact drawing for fit. Compare readability and temperature inside the same enclosure at the brightness needed to read the UI. Try your actual interface rather than a full-screen test image on a 800 × 480 canvas before committing to the enclosure.

    Can the cover treatment, touch, or brightness be adapted to my installation?

    Send the opening, viewing distance, ambient light and maximum temperature at the panel. We can review cover finish, optical bonding or touch options and where a different panel or backlight design may be needed.

    What information is needed for a sample quote for an outdoor display?

    Include the cover stack, ambient light, temperature range, annual volume and target sample date. We can quote the proposed changes, any one-time tooling or engineering, sample price and production MOQ separately. Ask for distinct sample and production lead times on the quoted drawing revision.

    Informazioni aggiuntive

    Dimensioni:

    Risoluzione:

    Interfaccia:

    Temperatura di esercizio:

    -30℃~ 85℃

    Luminosità (cd/m²):

    1000

    Supporto per touchscreen:

    Tipo di display:

    Soluzioni espositive personalizzate

    Collaborate con i nostri esperti di progettazione per creare il display perfetto per la vostra applicazione.
