Descrizione
G190ETN01.204 Key Features：
The AUO G190ETN01.204 is a rugged 19-inch TN LCD panel built for extreme environments. Boasting 350cd/m² brightness and 1000:1 contrast ratio, it ensures sharp visibility even under harsh lighting or direct sunlight. With an ultra-wide operating temperature range (-30°C to 85°C) and 50,000-hour LED lifespan, it delivers reliable performance in the most demanding industrial or outdoor settings. The LVDS interface ensures stable signal transmission in electrically noisy environments, while the 5V power supply simplifies integration with low-voltage systems. Its 85/85/80/80 viewing angles provide consistent visuals for multi-user applications, and the slim 15.68mm profile (396×324mm outline) allows seamless installation in space-constrained setups. Anti-glare coating minimizes reflections, ideal for outdoor kiosks or high-glare industrial floors. Designed to withstand vibrations, dust, and extreme temperatures, it’s a durable choice for 24/7 operations in energy, transportation, or heavy machinery sectors.
Applications & Performance：
The AU Optronics 19-inch G190ETN01.204 excels in industrial automation, outdoor digital signage, and transportation systems. Its 350cd/m² brightness ensures sunlight readability for EV charging stations, mining equipment interfaces, or highway information displays. The -30°C~85°C tolerance supports deployment in Arctic logistics hubs, desert solar farms, or unheated warehouses. The LVDS interface resists electromagnetic interference, perfect for factory robotics, CNC machines, or power grid control panels. The 1280×1024 resolution delivers crisp text and graphics for SCADA systems, warehouse management dashboards, and maritime navigation displays. With 1000:1 contrast ratio, it enhances grayscale accuracy for medical imaging or security surveillance in bright environments. Applications include ruggedized HMIs, airport ground support systems, and military-grade field equipment. Its TN panel’s fast response time reduces motion blur for dynamic environments like construction vehicle interfaces or automated production lines.
19.0″ TFT-LCD Product Specifications
| Numero di modello | G190ETN01.204 |
|---|---|
| Dimensione | 19.0 |
| Risoluzione | 1280×1024 |
| Dimensione del contorno | 396×324×15.68 |
| Area attiva | 376.32×301.056 |
| Luminosità (cd/m²) | 350 |
| Interfaccia | LVDS |
| Visualizza la direzione | TN |
| Temperatura di esercizio | -30~85 |
| Temperatura di stoccaggio | -30~85 |
| Durata del LED | 50000 |
| Supporto per touchscreen | Senza |
| Rapporto di contrasto | 1000:1 |
| Alimentazione | 5.0V |
| Tipo di display | LCD a colori |
19.0″ TFT LCD Custom Solutions
Ottimizzate le vostre soluzioni via cavo
Regolate la lunghezza, la posizione e la piedinatura dei vostri cavi o aggiungete connettori supplementari per migliorare la funzionalità. Ottenete una soluzione di cavi personalizzata, progettata per semplificare le connessioni e garantire prestazioni sicure e affidabili.
PCB Modifications
Choose from a variety of variations in PCB shape, size, pin and component layout to make it fully suitable for your application.
Elevare l'esperienza dell'utente con la tecnologia touch screen
Migliorate la vostra esperienza utente con la tecnologia touch screen capacitiva o resistiva. Personalizzeremo lo spessore del vetro e la forma del pannello tattile per garantire un adattamento perfetto ai vostri requisiti di progettazione.
Vetro di copertura personalizzato
Equipaggiate il vostro display con un vetro di copertura tagliato su misura per aumentare la durata e le prestazioni. Scegliete tra vari spessori e optate per l'incollaggio ottico per proteggere il display da umidità e detriti, garantendo una soluzione affidabile e duratura.
