1.504 inch Color OLED display 466x466 Round Oled

SKU: DS10010
Temperatura de funcionamiento:

-20℃~70℃

Brillo (cd/m²):

600

Compatible con pantallas táctiles:

Tipo de pantalla:

Tamaño:

Resolución:

Interfaz:

, ,

Recursos:

1.504 inch Color OLED display  Offering Resolution 466*466 with Round Shape Optional MIPI&SPI  Interface 600 nits High Brightness LCD  Industrial Application

Solicitar precios por volumen







    Descripción

    1.504" Amoled Displays Features

    The Color OLED display utilizes AMOLED technology, delivering superior color reproduction and contrast to enhance the visual experience. With a typical luminance of 600 cd/m², it remains visible under various lighting conditions. The display supports both MIPI and SPI interfaces, providing flexibility for different system configurations. Its wide viewing angles allow for all-direction visibility, making it ideal for applications where multiple users need to see the screen simultaneously. Additionally, its compact dimensions, measuring only 0.82 mm thick, facilitate integration into sleek and lightweight designs. Operating at a standard voltage of 3.3V, it ensures compatibility with a wide range of electronic devices.



    1.504" Amoled Display Application

    This AMOLED display module is perfect for a variety of applications, including wearable devices like smartwatches, fitness trackers, and health monitoring devices that demand high-quality displays in a compact form factor. It is also well-suited for portable electronics such as smartphones, handheld gaming devices, and portable media players, where space and power efficiency are critical. Additionally, the module can be utilized in IoT devices, providing a compact display for user interaction in various Internet of Things applications. Furthermore, it integrates seamlessly into consumer electronics, including digital cameras, remote controls, and other gadgets, enhancing the user experience with its high-resolution capabilities.

    1.504" Amoled Display Product Specifications

    Tamaño LCD (pulgadas) 1.504(Diagonal)
    Número de píxeles 466*466
    Pixel Pitch(um) 81.99*81.99
    Dimensiones exteriores (mm) 40.71 ×40.81 ×0.82
    Área activa (mm) 38.207 ×38.207
    Tipo de pantalla AMOLED
    Interfaz SPI/MI PI
    Ver Dirección ALL
    Power Supply(v) 3.3
    Luminance(cd/m²) 600
    Drive IC CH13613-SSS32
    - -
    - -
    - -
    - -

    1.504" Amoled Custom Solutions

    Optimice sus soluciones de cableado

    Ajuste la longitud, la posición y el pinout de sus cables, o añada conectores adicionales para mejorar la funcionalidad. Obtenga una solución de cable personalizada diseñada para agilizar sus conexiones y garantizar un rendimiento seguro y fiable.

    Personalización de la interfaz LCD

    Seleccione entre una amplia gama de opciones de interfaz o consulte a nuestros expertos para encontrar la ideal para su proyecto. Podemos integrar HDMI, USB, SPI, VGA y más en su pantalla, ayudándole a cumplir sus objetivos de diseño de forma eficiente.

    Mejore la experiencia del usuario con la tecnología de pantalla táctil

    Mejore su experiencia de usuario con tecnología de pantalla táctil capacitiva o resistiva. Personalizaremos el grosor del cristal y la forma del panel táctil para garantizar un ajuste perfecto a sus requisitos de diseño.

    custom touch

    Tapa de cristal a medida

    Equipe su pantalla con una cubierta de cristal cortada a medida para aumentar la durabilidad y el rendimiento. Elija entre varios grosores y opte por la adhesión óptica para protegerla de la humedad y la suciedad, garantizando una solución duradera y fiable.

    1.504-Inch 466 × 466 Round AMOLED Display FAQ

    Can I drive this 466 × 466 round AMOLED with an ESP32-S3 or STM32?

    Send us the exact board and its available display bus. The linked Rev. A specification documents SPI and MIPI for the CH13613-SSS32 driver. Confirm the pinout, logic levels, power rails and initialization before laying out your PCB. If your board requires QSPI, ask us to confirm support for the revision being quoted.

    Round AMOLED module specification, Rev. A

    Will the round AMOLED fit behind my bezel without clipping the dial labels?

    The drawing lists a 40.71 × 40.81 × 0.82 mm module outline without cover glass. Compare the visible circle, rear clearance and flex exit with your enclosure. Check the dial labels and edge icons on a sample fitted with the intended bezel and cover.

    Can I add touch or customize the cover glass and flex cable?

    The catalog configuration comes without touch. Send us the cover profile, thickness, print or finish, flex length and exit direction, and the host touch interface if needed. We can review a cover-only configuration and a separate touch assembly for your design.

    How much does a custom round AMOLED sample cost, and how long does it take?

    Share your drawing, sample quantity, expected production volume and target date. We can review the cover-only option and any touch or flex changes separately. The quote can show one-time engineering or tooling charges, sample cost, production MOQ, and separate lead times for samples and production.

    Custom cover and touch sampling process

    Will the round AMOLED stay readable behind my cover in bright light?

    The module is rated at 600 cd/m² typical. Check small text and icons on a finished sample under your expected lighting and viewing angles. For battery-powered products, measure current with your actual bright and dark layouts, including icons that stay on for long periods.
