7 inch TFT Screen High Brightness for Outdoor Display

SKU: DS20292
Tamaño:

Resolución:

Interfaz:

Temperatura de funcionamiento:

-30℃~ 85℃

Brillo (cd/m²):

1000

Compatible con pantallas táctiles:

Tipo de pantalla:

7 inch TFT screen, 1000 nits High brightness, 800x480, -30~85 wide Op Temp, Ideal for outdoor harsh environment

Solicitar precios por volumen







    Descripción

    7 inch TFT Screen Description

    With an 800×480 resolution, 1000-nit brightness, and a wide operating temperature range of -30℃~85℃, this display delivers reliable performance in demanding environments. Engineered for industrial control, medical, and military applications, it combines:

    ✅ Extreme Temperature Stability: Operates flawlessly in arctic cold or high-heat conditions, ideal for outdoor machinery or field equipment.
    ✅ High-Brightness Visibility: 1000-nit luminance ensures clear viewing in direct sunlight or brightly lit industrial settings.
    ✅ Rugged Durability: Meets rigorous standards for shock resistance and electromagnetic interference (EMI) protection.
    Quality Assurance:
    Every unit undergoes 72-hour burn-in testing and thermal cycling to ensure industrial-grade reliability. Direct from the R&D team—competitive pricing without compromising on performance.
    Below the basic parameters for it, Tailor the interface (LVDS/RGB/MIPI), brightness, dimensions, and touch solutions (capacitive/resistive) to seamlessly integrate into your device—engineered for hassle-free system integration.

    7" TFT Display Specifications

    Número de modelo ZDX070TNCP50-DB10
    Talla 7
    Resolución 800*480
    Contorno Dimensión 164.9*100.0*5.7
    Área activa 154.08*85.92
    Brillo(cd/m²) 1000
    Interfaz Digital
    Ver Dirección 6
    Temperatura de funcionamiento -30~85
    Temperatura de almacenamiento -30~85
    Vida útil del LED 20000
    Soporte de pantalla táctil No
    Relación de contraste 1000:1
    Fuente de alimentación 3.3V
    Tipo de pantalla LCD en color

    7" TFT LCD Custom Solutions

    Optimice sus soluciones de cableado

    Ajuste la longitud, la posición y el pinout de sus cables, o añada conectores adicionales para mejorar la funcionalidad. Obtenga una solución de cable personalizada diseñada para agilizar sus conexiones y garantizar un rendimiento seguro y fiable.

    Personalización de la interfaz LCD

    Seleccione entre una amplia gama de opciones de interfaz o consulte a nuestros expertos para encontrar la ideal para su proyecto. Podemos integrar HDMI, USB, SPI, VGA y más en su pantalla, ayudándole a cumplir sus objetivos de diseño de forma eficiente.

    Mejore la experiencia del usuario con la tecnología de pantalla táctil

    Mejore su experiencia de usuario con tecnología de pantalla táctil capacitiva o resistiva. Personalizaremos el grosor del cristal y la forma del panel táctil para garantizar un ajuste perfecto a sus requisitos de diseño.

    custom touch

    Tapa de cristal a medida

    Equipe su pantalla con una cubierta de cristal cortada a medida para aumentar la durabilidad y el rendimiento. Elija entre varios grosores y opte por la adhesión óptica para protegerla de la humedad y la suciedad, garantizando una solución duradera y fiable.

    7-Inch 800 × 480 High-Brightness LCD Display FAQ

    Will this display be readable through my outdoor enclosure window?

    Use the listed 1000 cd/m² to shortlist the display, then judge the assembled product with its final cover and ambient lighting. Test your smallest text in direct sun and at the worst reflection angle. Record the cover finish and viewing distance so you can repeat the test on later samples.

    Sunlight Readable TFT Displays

    What must my controller and power supply support in an outdoor installation?

    Send us your host model so we can check the required interface, pinout and electrical limits against the exact product documentation. Verify the backlight supply, dimming control and enclosure cooling using the exact panel documentation.

    How should I compare high-brightness displays behind the same cover?

    Use the 7-inch diagonal to shortlist high-brightness displays, then check the exact drawing for fit. Compare readability and temperature inside the same enclosure at the brightness needed to read the UI. Try your actual interface rather than a full-screen test image on a 800 × 480 canvas before committing to the enclosure.

    Can the cover treatment, touch, or brightness be adapted to my installation?

    Send the opening, viewing distance, ambient light and maximum temperature at the panel. We can review cover finish, optical bonding or touch options and where a different panel or backlight design may be needed.

    What information is needed for a sample quote for an outdoor display?

    Include the cover stack, ambient light, temperature range, annual volume and target sample date. We can quote the proposed changes, any one-time tooling or engineering, sample price and production MOQ separately. Ask for distinct sample and production lead times on the quoted drawing revision.

    Información complementaria

    Tamaño:

    Resolución:

    Interfaz:

    Temperatura de funcionamiento:

    -30℃~ 85℃

    Brillo (cd/m²):

    1000

    Compatible con pantallas táctiles:

    Tipo de pantalla:

    Soluciones de exposición personalizadas

    Trabaje con nuestros expertos en ingeniería para crear la pantalla perfecta para su aplicación.
