Tianma TM150XDHG01 15" 1600*1200 Sunlight Readable LCD - 80/80/80/80 TN -30℃~70℃

SKU: DS50092
Tamaño:

Número de modelo

TM150XDHG01

Compatible con pantallas táctiles:

Resolución:

Interfaz:

Tipo de pantalla:

Recursos:

Sunlight Readable LCD: 15'' 1600*1200 TN panel, LVDS interface, wide temp (-20℃~70℃). Perfect for HMIs, POS, and rugged environments. 30K hrs lifespan.

Solicitar precios por volumen







    Descripción

    Tianma tm150xdhg01 General Description

    Engineered for Demanding Visibility
    The Tianma TM150XDHG01 15-inch high-brightness LCD combats glare and environmental extremes, delivering crisp 1600x1200 (UXGA) visuals in direct sunlight or freezing temperatures. Designed for mission-critical systems requiring both precision and endurance, its LVDS interface and industrial-grade TN panel ensure stable signal transmission in high-EMI environments like oil rig control panels, aviation navigation displays, and mobile medical carts.



    Why Engineers Specify This Display

    ▸ Sunlight-Readable Clarity – High-bright backlight (contact for nit specs) cuts through glare on construction equipment and outdoor kiosks.
    ▸ Wide-Temperature Reliability – Operates flawlessly from -20℃ to 70℃, tested for thermal shock resistance in desert/mining applications.
    ▸ 30K-Hour Lifespan – Outlasts consumer-grade panels in 24/7 industrial HMIs and public transportation info screens.
    ▸ LVDS Noise Immunity – Integrates seamlessly with PLCs, reducing signal dropout risks in CNC machines or railway systems.

    Certified for Critical Deployments
    Compliant with RoHS and industrial EMC standards. Optional upgrades:
    • Anti-reflective coating for outdoor use
    • Resistive/capacitive touchscreen layers
    • Custom bezels or mounting brackets

    15" TFT-LCD Product Specifications

    Número de modelo TM150XDHG01
    Talla 15
    Resolución 1600(RGB)×1200
    Contorno Dimensión 318.7×242.5×6.5
    Área activa 304.8×228.6
    Brillo(cd/m²) 1000
    Interfaz LVDS 30pin
    Ver Dirección TN
    Temperatura de funcionamiento -20~70
    Temperatura de almacenamiento -30~80
    Vida útil del LED 30000
    Soporte de pantalla táctil Sin
    Relación de contraste 1000:1
    Fuente de alimentación 3.3V
    Tipo de pantalla LCD en color

    15" TFT LCD Custom Solutions

    Optimice sus soluciones de cableado

    Ajuste la longitud, la posición y el pinout de sus cables, o añada conectores adicionales para mejorar la funcionalidad. Obtenga una solución de cable personalizada diseñada para agilizar sus conexiones y garantizar un rendimiento seguro y fiable.

    Modificaciones de PCB

    Elija entre una gran variedad de variaciones en la forma de la placa de circuito impreso, el tamaño, la disposición de las patillas y los componentes para que se adapte totalmente a su aplicación.

    Mejore la experiencia del usuario con la tecnología de pantalla táctil

    Mejore su experiencia de usuario con tecnología de pantalla táctil capacitiva o resistiva. Personalizaremos el grosor del cristal y la forma del panel táctil para garantizar un ajuste perfecto a sus requisitos de diseño.

    custom touch

    Tapa de cristal a medida

    Equipe su pantalla con una cubierta de cristal cortada a medida para aumentar la durabilidad y el rendimiento. Elija entre varios grosores y opte por la adhesión óptica para protegerla de la humedad y la suciedad, garantizando una solución duradera y fiable.

    Tianma TM150XDHG01 15-Inch LCD Replacement FAQ

    How do I confirm that I need the Tianma TM150XDHG01?

    Send us a clear photo showing the full model suffix and revision on the old panel label, the connector side, and the equipment model. Start with the listed 15-inch display, then check the drawing for the outline, visible opening, thickness, mounting points and connector clearance.

    Can I reuse the existing LVDS cable and controller with the Tianma TM150XDHG01?

    For the listed LVDS interface, match the connector pinout, channel count, data mapping and panel supply before applying power. Check the existing backlight supply and enable/dim signals as well. Two connectors that look identical can carry different signals.

    TFT LCD datasheet integration guide

    How do I qualify a different panel as a replacement for the Tianma TM150XDHG01?

    Use 1600 × 1200 to shortlist a candidate while keeping the complete interface and mechanical requirements in your acceptance criteria. Compare the outline and mounting points, connector position and pinout, power and backlight signals, and video timing. Test the original graphics and controls on a sample before approving a substitute.

    Is the Tianma TM150XDHG01 still available, and how do I check for end of life?

    Send us the exact rear-label model and revision, requested quantity and required date. Ask for current supply for that revision and any dated manufacturer notice. If the revision is unavailable, we can review a candidate for sample qualification.

    Can I keep the original LCD and add touch, a cover, or a revised cable?

    The listed panel has no touch layer. We can review the cover, touch stack or cable around the original panel. Send us the enclosure drawing, required controller connections, sample quantity and production forecast. Ask for feasible changes, any one-time development charges, production MOQ and separate sample and production lead times.
