1.28 Round TFT Display 240*240 IPS for Smart knob

UGS : DS20283
Taille :

Résolution :

Interface :

Température de fonctionnement :

-20℃~70℃

Luminosité (cd/m²) :

350

Prise en charge de l'écran tactile :

Type d'affichage :

1.28 Round TFT Display, circular display interactive interface makes home devices smarter, support FPC/Cover glass/touch custom, support small MOQ.

Demande de tarification au volume







    Description

    1.28 Round TFT Display overview:

    The basic parameters for this 1.28 inch small round lcd screen: resolution 240*240, IPS viewing angle, operating temperature -20~70℃. Featured circular form factor, is optimized for intuitive knob-style interfaces, complemented by ultra-narrow 1.6mm bezels that achieve an 85% screen-to-body ratio—maximizing display area in compact devices. Its low-power design extends battery life in portable systems.



    Why choose us?

    Our mature supply chain and production lines ensure we have strong advantages in both cost control and product quality. With a robust system equipped with professional R&D personnel and comprehensive product documentation, we enable technical teams to quickly select the right products, streamline development and debugging, and troubleshoot issues efficiently. Backed by a one-year warranty and reliable after-sales maintenance, you can purchase with complete peace of mind.

    1.28" Round TFT Display Specifications

    Numéro de modèle  90-12804-001
    Taille 1.28
    Résolution 240*240
    Dimension de l'ébauche 35.6*38.1*1.55
    Zone active 32.4*32.4
    Luminosité (cd/m²) 350
    Interface SPI
    Voir la direction ALL
    Température de fonctionnement -20~70
    Température de stockage -30~80
    Durée de vie des LED 20000
    Prise en charge de l'écran tactile Witout
    Rapport de contraste 1200:1
    Alimentation électrique 3.3V
    Type d'affichage LCD couleur

    1.28" TFT LCD Custom Solutions

    Optimisez vos solutions de câblage

    Ajustez la longueur, la position et le brochage de vos câbles, ou ajoutez des connecteurs supplémentaires pour améliorer la fonctionnalité. Obtenez une solution de câblage personnalisée conçue pour rationaliser vos connexions et garantir des performances sûres et fiables.

    Personnalisation de l'interface LCD

    Choisissez parmi une gamme variée d'options d'interface ou consultez nos experts pour trouver celle qui convient le mieux à votre projet. Nous pouvons intégrer des interfaces HDMI, USB, SPI, VGA et autres dans votre écran, pour vous aider à atteindre efficacement vos objectifs de conception.

    Améliorer l'expérience de l'utilisateur grâce à la technologie de l'écran tactile

    Améliorez votre expérience utilisateur grâce à la technologie des écrans tactiles capacitifs ou résistifs. Nous personnaliserons l'épaisseur du verre et la forme de l'écran tactile pour qu'il réponde parfaitement à vos exigences en matière de conception.

    custom touch

    Verre de couverture sur mesure

    Équipez votre écran d'une vitre de protection découpée sur mesure pour améliorer sa durabilité et ses performances. Choisissez parmi différentes épaisseurs et optez pour le collage optique afin d'assurer une protection contre l'humidité et les débris, garantissant ainsi une solution durable et fiable.

    1.28-Inch 240 × 240 Round LCD Display FAQ

    Will the bezel cover any of my dial labels or icons?

    Use the 1.28-inch diagonal to shortlist round displays, then check the exact drawing for fit. Make a mask from the active circle and bezel drawing. Try your dial, long labels and controls with the mask applied on a 240 × 240 canvas before committing to the enclosure.

    How do I check that the driver and artwork align with the visible circle?

    For the listed SPI interface, check the exact controller, SPI mode, logic levels and update time with a representative screen. Check orientation and any address-window offsets in the initialization code, then show a marked test grid to verify the center and edge alignment.

    Should I choose a round display or place a rectangular display behind a round bezel?

    Compare the visible arc, text clipping, module clearance and flex routing for both approaches. Use the listed 350 cd/m² to shortlist the display, then judge the assembled product with its final cover and ambient lighting. A mock-up with your longest labels will show how much of the nominal screen you can actually use.

    Can I add custom cover glass, change the flex cable, or add touch?

    Send the visible circle, cover outline and thickness, desired flex exit and touch interface. We can evaluate a cover-only design and a separate touch assembly around the panel.

    Custom Touch Screen Solutions

    What affects the cost and lead time of a custom round display sample?

    Include your cover drawing, host board, sample quantity and annual volume. We can quote the proposed changes, any one-time tooling or engineering, sample price and production MOQ separately. Ask for distinct sample and production lead times on the quoted drawing revision.

    Informations complémentaires

    Taille :

    Résolution :

    Interface :

    Température de fonctionnement :

    -20℃~70℃

    Luminosité (cd/m²) :

    350

    Prise en charge de l'écran tactile :

    Type d'affichage :

    Solutions d'affichage personnalisées

    Travaillez avec nos experts en ingénierie pour créer le présentoir parfait pour votre application.
