15.6 inch Industrial Display Panel 1366*768 with Capacitive Touch

UGS : DS30023
Taille :

Résolution :

Interface :

, , , ,

Prise en charge de l'écran tactile :

abc

15.6 inch Industrial Display Panel, offer resolution 1366*768, with 10 point capacitive screen, Standard HDMI/VGA display, Other Interface can be customized

Demande de tarification au volume







    Description

    15.6 inch Industrial Display Panel main features:

    • Original capacitive touch screen, high resolution, fingertip light touch, 3ms can quickly respond to high-speed transmission reaction, one-time correction, strong stability, strong anti-interference.
    • HDMI+VGA standard interface, we support interface customization and expansion
    • Multi-hole heat dissipation body, the back shell adopts multi-hole heat dissipation design, which can effectively and timely dissipate heat, so that the machine can work normally and stably for a long time
    • All-day standby, stable endurance; with 7*24h long-term continuous operation platform capability, providing a stable working environment, the power-on capability can be set through BIOS, and it can still run stably in an unstable environment.
    15.6 industrial touch display



    15.6 inch Industrial Display Panel specification

    Écran LCD Taille 15.6" Display solution configuration specifications
    Display area 344.232 × 193.536 mm (H×V) Interface VGA*1
    Résolution 1366*768 HDMI*1
    Dot pitch 0.084×0.252 mm (H×V) Audio*1
    Display ratio 16:9 USB*1 for touch
    Viewing angle (L/R/U/D) 85/85/80/80 (Typ.)(CR≥10) Alimentation électrique DC 12V(optional DC 9-36V wide voltage, Phoenix terminal interface)
    Contrast 500:1 Performance Industrial-grade motherboard, solid-state capacitor, anti-interference, anti-surge
    Couleur 16.7M Packing List monitor*1
    Response time 8ms HDMI cable*1
    Luminosité 300cd/m2 Instruction manual*1
    Écran tactile Touch type Capacitive touch (G+G), ILITEK solution Dual male USB cable*1
    Number of supported points 10 point Adapter*1
    Touch mode Finger touch Consommation électrique Rated power ≤16W
    Surface hardness ≥6H Standby power ≤0.5W
    Response time <3ms Rated voltage 100-240V (50/60Hz)
    Transmittance ≥85% Environnement Storage temperature and humidity: -20~60℃, 20~85RH, no condensation
    Service life >50 million times Working temperature and humidity: 0~50℃, 20~85RH, no condensation
    Linear error ≤2.5mm
    Haze 3%(Max)
    Châssis Appearance size 420*269*60.6mm
    Opening size 400*250mm
    Touch step thickness 3mm
    Wall mounting hole position 100*100mm
    Poids net 4.5KG
    Gross weight 5.3KG
    Packing size 520*435*140mm
    Dimensions du produit 15.6 capacitive touch screen

    Télécharger

    15.6-Inch 1366 × 768 Monitor FAQ

    Will this monitor fit with the cables and controls accessible?

    Use the 15.6-inch diagonal to shortlist monitors, then check the exact drawing for fit. Compare the case depth, mount or stand, cable bend and access to the controls against your setup. Test the actual cable exit before approving a tight installation.

    Industrial touch monitor selection guide

    Can my computer, media player, or controller run this monitor?

    For the listed VGA interface, confirm the source timing and check the image at the mode and cable length you intend to use.

    How should I compare this monitor with another for my installation?

    Try your typical desktop, menu or signage layout on a 1366 × 768 canvas before choosing a monitor. Compare readable text size at the intended distance, connector access and whether the installation needs a portable stand or fixed mounting. Compare the candidates with the same content, cover and lighting, then select against your minimum contrast and viewing-angle requirements.

    Can I specify the mount, ports, power adapter, or touch configuration?

    Share the enclosure or stand drawing, input sources, orientation and required ports. We can check available mounts, power and touch configurations and confirm which parts can be quoted together.

    What should I send for a monitor quote and sample schedule?

    Include the source ports and modes, mounting setup, accessories, quantities and required date. Ask for the hardware, accessories and any one-time setup itemized, with sample cost, production quantity breaks and separate delivery dates.

    Informations complémentaires

    Taille :

    Résolution :

    Interface :

    , , , ,

    Prise en charge de l'écran tactile :

    Solutions d'affichage personnalisées

    Travaillez avec nos experts en ingénierie pour créer le présentoir parfait pour votre application.
