BOE DV190E0M-N11 19” LCD Screen 1280×1024 LVDS Display

UGS : DS50269-1
Taille :

Numéro de modèle

V190E0M-N11

Interface :

Température de fonctionnement :

-0℃~50℃

Luminosité (cd/m²) :

250

Prise en charge de l'écran tactile :

Type d'affichage :

BOE DV190E0M-N11, Resolution 1280×1024, LVDS interface, IPS screen, Idea for Consumer Electronics, products in stock, volume discount.

Demande de tarification au volume







    Description

    BOE DV190E0M-N11 Desription

    This BOE DV190E0M-N11 module is equipped with an LVDS interface supporting 2 pixels per clock, With a 6-bit (Hi-FRC) color depth, it delivers vibrant 16.7 million colors for rich and accurate color representation. Designed with a wide viewing angle for versatile installation, it operates in DE (Data Enable) only mode to simplify signal integration. Leveraging HADS (High Advanced Hyper Driving System) technology, it enhances display quality through optimized pixel control and contrast.



    15+ Years TFT Expertise: Full-Suite Solutions & Dedicated Support

    Leverage our 15-year technical team for end-to-end TFT displays—from hardware design (custom sizes, specs) to firmware/driver development, mechanical integration, and rigorous testing. We deliver plug-and-play solutions for OS, rapid prototyping (10–15 days), and 24/7 support. Trusted in industrial, medical, and consumer sectors, our expertise ensures seamless integration, low risk, and 99.8% first-time compatibility. Your single source for reliable, tailored TFT technology

    19" Product Specifications

    Diagonal Size11.8 19 pouces
    Nombre de pixels 1280×1024
    Luminance 250
    Module Size 396×324×10.4
    Zone active 374.784×299.827
    Direction de visualisation IPS
    View Angle(U/D/R/L) 89/89/89/89
    Interface LVDS
    Rapport de contraste 1000 : 1
    Température de fonctionnement -0 ~ 50 °C
    Température de stockage -20 ~ 60 °C
    Durée de vie des LED 30000
    Alimentation électrique 5.0V
    Prise en charge de l'écran tactile Sans
    Type d'affichage Color TFT



    BOE LCD Display Solutions sur mesure

    Optimisez vos solutions de câblage

    Ajustez la longueur, la position et le brochage de vos câbles, ou ajoutez des connecteurs supplémentaires pour améliorer la fonctionnalité. Obtenez une solution de câblage personnalisée conçue pour rationaliser vos connexions et garantir des performances sûres et fiables.

    Modifications de la carte de circuit imprimé

    Choisissez parmi une variété de variations dans la forme du circuit imprimé, la taille, la disposition des broches et des composants pour l'adapter parfaitement à votre application.

    Améliorer l'expérience de l'utilisateur grâce à la technologie de l'écran tactile

    Améliorez votre expérience utilisateur grâce à la technologie des écrans tactiles capacitifs ou résistifs. Nous personnaliserons l'épaisseur du verre et la forme de l'écran tactile pour qu'il réponde parfaitement à vos exigences en matière de conception.

    custom touch

    Verre de couverture sur mesure

    Équipez votre écran d'une vitre de protection découpée sur mesure pour améliorer sa durabilité et ses performances. Choisissez parmi différentes épaisseurs et optez pour le collage optique afin d'assurer une protection contre l'humidité et les débris, garantissant ainsi une solution durable et fiable.

    BOE DV190E0M-N11 19-Inch LCD Replacement FAQ

    How do I confirm that I need the BOE DV190E0M-N11?

    Send us a clear photo showing the full model suffix and revision on the old panel label, the connector side, and the equipment model. Start with the listed 19-inch display, then check the drawing for the outline, visible opening, thickness, mounting points and connector clearance.

    Can I reuse the existing LVDS cable and controller with the BOE DV190E0M-N11?

    For the listed LVDS interface, match the connector pinout, channel count, data mapping and panel supply before applying power. Check the existing backlight supply and enable/dim signals as well. Two connectors that look identical can carry different signals.

    TFT LCD datasheet integration guide

    How does the BOE DV190E0M-N11 compare with the AUO G190ETN01.601?

    Both catalog listings show 19 inches, 1280 × 1024 and LVDS. The catalog lists 0 °C to +50 °C for the BOE panel and −30 °C to +70 °C for the AUO panel. Compare the outline and mounting points, connector position and pinout, power and backlight signals, and video timing. Test the original graphics and controls on a sample before approving a substitute.

    Compare AUO G190ETN01.601

    Is the BOE DV190E0M-N11 still available, and how do I check for end of life?

    Send us the exact rear-label model and revision, requested quantity and required date. Ask for current supply for that revision and any dated manufacturer notice. If the revision is unavailable, we can review a candidate for sample qualification.

    Can I keep the original LCD and add touch, a cover, or a revised cable?

    The listed panel has no touch layer. We can review the cover, touch stack or cable around the original panel. Send us the enclosure drawing, required controller connections, sample quantity and production forecast. Ask for feasible changes, any one-time development charges, production MOQ and separate sample and production lead times.
