11.6 inch G+G capacitive touch screen, IIC, 5 point Touch

COD: DS40052-1-1-1
Dimensioni:

Interfaccia:

Thickness

3 mm

Structure

G+G

Touch IC

microchip

abc

11.6 inch G+G capacitive touch screen, I²C interface,  5-point multi-touch,suitable for industrial, commercial, or consumer applications.

Richiesta di prezzi a volume







    Descrizione

    11.6 inch G+G capacitive touch screen:

    Introduce this 11.6 inch G+G capacitive touch screen, supports 5-point multi-touch with touch + gesture operation.it operates reliably within a -20 ~ 70 °C temperature range, withstand diverse environments, suitable for industrial, commercial, or consumer applications.
    Advanced Features:
    ✓ Multi-touch capability with fast response and precise positioning
    Enables smooth interaction with rapid feedback and high-precision touch localization.
    ✓ Passed rigorous tests for high/low temperature, vibration, and heavy ball drop
    Proven durability under extreme environmental conditions and mechanical impacts.
    ✓ 24/7 online technical support from an in-house team, the factory-direct advantage, and worry-free after-sales service
    Immediate expert assistance, vertically integrated manufacturing, and comprehensive post-sales support.



    11.6 inch G+G capacitive touch screen
    Construction Cover Glass Thickness: 1.1 mm±0.05mm
    OCR Thickness: 0.175mm ± 0.05mm
    Sensor Thickness: 0.7mm ± 0.05mm
    Machanical Characteristics Touch size 11.6 inch
    Outer Dimension 289.5*184 mm
    View Area 257.32*145.18 mm
    Area attiva 259.32*147.18 mm
    TP Thickness 1.98 mm±0.2
    Number of Touch 5
    Interfaccia IIC
    Controller Microchip
    capacitive touch drawings

    Scaricare

    11.6-Inch I²C Display Module FAQ

    Will this display fit my enclosure and show the whole interface?

    Use the 11.6-inch diagonal to shortlist display modules, then check the exact drawing for fit. Overlay the visible area, module outline and flex exit on your enclosure drawing. Get the native pixel layout first, then try your menus and text at that layout before committing to the enclosure.

    What must my controller support to drive this display module?

    For the listed I²C interface, check the controller address, logic levels and bus pull-ups on the intended host. Before connecting it, check the power rails and reset sequence in the module documentation.

    How should I compare this display with a similar module for my device?

    Compare the candidates with the same content, cover and lighting, then select against your minimum contrast and viewing-angle requirements. Judge readability on the assembled product with its final cover and ambient lighting. Compare the cost and space of any changes to the cable, host board or front cover.

    Can I change the flex cable, add a cover, or integrate touch?

    Send us the mounting drawing, permitted flex exit, connector and cover or touch requirements. We can review which of those changes can be made around the existing display and which require a different module.

    What determines the cost and lead time of a custom display sample?

    Include your display outline, interface, target sample date and estimated annual volume. We can quote the proposed changes, any one-time tooling or engineering, sample price and production MOQ separately. Ask for distinct sample and production lead times on the quoted drawing revision.
