15″ Capacitive Touch Panel–5-Finger Multi-Touch, USB, mxT1664T3 IC, G+G 4mm Cover Glass

COD: DS40048

Dimensioni:	15 inch
Interfaccia:	USB
Thickness	4 mm
Structure	G+G
Touch IC	microchip

Capacitive Touch Panel, G+G structure, Precision Multi-Touch, Built to Last: 5-Finger Control Meets 4mm Industrial-Grade Glass, Idea for Medical diagnostic equipment, Factory automation HMIs

$99.00

Descrizione

15″ Capacitive Touch Panel:

Introducing the 15 inch Capacitive Touchscreen – engineered for precision and durability in demanding environments. Featuring 5-finger multi-touch technology, this panel delivers seamless interaction for collaborative workflows, gaming, or industrial applications. Equipped with the advanced mxT1664T3 IC, it ensures fast response times (<10ms) and exceptional accuracy (±1mm), supporting gesture recognition and palm rejection for error-free operation.

Advanced Features:
✓ Anti-glare coating ensures readability under direct sunlight
✓ 4mm thickened cover glass resists impacts and chemical corrosion
✓ Certified with CE/FCC/RoHS standards
✓ Custom firmware and driver support are available upon request

15″ Capacitive Touch Panel
Construction	Cover Glass	Thickness: 4 mm±0.05mm
	OCR	Thickness: 0.175mm ± 0.05mm
	ITO Glass	Double side ITO glass: Thickness: 1.1mm ± 0.05mm
Machanical Characteristics	Touch size	15 inch
	Outer Dimension	374.65*298.45
	View Area	305.13*229.10
	Sensor Area	328.32*252.50
	Cover Thickness	4
	Number of Touch	10
	Interfaccia	USB
	Controller	Microchip
