1.04” Round screen IPS QSPI 360x360 for Smart Appliance Device

The page shows different pixel matrices in its title and table, and its descriptions also differ on display technology. Ask us to confirm the native matrix, panel technology, driver IC and mechanical drawing for the exact revision offered. Use that set to approve the framebuffer, power design and bill of materials.

A QSPI label alone does not establish compatibility. Compare the offered panel’s command and data framing, line modes, logic levels and reset sequence with your host’s display interface and firmware. Check the FPC pinout before wiring and prove initialization and a test image on a sample.

Place critical marks inside a safe circle based on the confirmed visible opening, not the corners of the framebuffer. Check the complete bezel and cover with a concentric test pattern; allow for panel centering, mask tolerance and off-axis viewing before releasing the artwork.

Calculate frame size from the confirmed native matrix and the negotiated pixel format. Test the complete update on the intended controller, with the UI and other tasks running. If bandwidth is tight, measure updates limited to the needle or changing regions where supported by the offered driver.

DS50333-1 is listed without touch. If the controls move from a physical knob to the screen, budget separately for the touch sensor, its controller connection and the cover stack. Share the cover drawing and test touch reach near the circular edge on the assembled sample.
