15" Capacitive Touch Panel–5-Finger Multi-Touch, USB, mxT1664T3 IC, G+G 4mm Cover Glass

SKU: DS40048
Size:

Interface:

Thickness

4 mm

Structure

G+G

Touch IC

microchip

abc

Capacitive Touch Panel, G+G structure, Precision Multi-Touch, Built to Last: 5-Finger Control Meets 4mm Industrial-Grade Glass, Idea for Medical diagnostic equipment, Factory automation HMIs

Request Volume Pricing







    Description

    15" Capacitive Touch Panel:



    Introducing the 15 inch Capacitive Touchscreen – engineered for precision and durability in demanding environments. Featuring 5-finger multi-touch technology, this panel delivers seamless interaction for collaborative workflows, gaming, or industrial applications. Equipped with the advanced mxT1664T3 IC, it ensures fast response times (<10ms) and exceptional accuracy (±1mm), supporting gesture recognition and palm rejection for error-free operation.

    Advanced Features:
    ✓ Anti-glare coating ensures readability under direct sunlight
    ✓ 4mm thickened cover glass resists impacts and chemical corrosion
    ✓ Certified with CE/FCC/RoHS standards
    ✓ Custom firmware and driver support are available upon request



    15" Capacitive Touch Panel
    Construction Cover Glass Thickness: 4 mm±0.05mm
    OCR Thickness: 0.175mm ± 0.05mm
    ITO Glass Double side ITO glass: Thickness: 1.1mm ± 0.05mm
    Machanical Characteristics Touch size 15 inch
    Outer Dimension 374.65*298.45
    View Area 305.13*229.10
    Sensor Area 328.32*252.50
    Cover Thickness 4
    Number of Touch 10
    Interface USB
    Controller Microchip
    capacitive touch screen USB

    Download

    15-Inch Capacitive Touch Panel FAQ

    Will this touch panel align with the visible area and opening of my display?

    Use the 15-inch diagonal to shortlist touch overlays, then check the exact drawing for fit. Superimpose the touch active area, glass outline and cable exit on the display and bezel drawings. Check cover thickness, edge overlap and clearance at the flex tail.

    Can my current host read touch input from this panel?

    For the listed USB interface, verify the port’s role, driver support and power needs on the exact configuration. Send us the host and OS version and verify the exact touch controller and driver. Test coordinate mapping, orientation and resume after power loss.

    Should I use a touch overlay or a display with integrated touch?

    Compare the added glass thickness, reflections, attachment process and space for a separate touch cable. If gloves, moisture or precise edge input matter, compare both options in the finished front assembly.

    Can I customize the cover, flex cable, or touch settings for gloves and water?

    Send the active area, cover outline and thickness, flex exit and touch interface. We can review the glass and sensor stack, then agree glove and moisture conditions to try on a sample.

    Custom Touch Screen Solutions

    How much does a custom touch sample cost and how long does it take?

    Include drawings for the existing LCD, cover and flex, controller interface, quantities and target date. We can quote the proposed changes, any one-time tooling or engineering, sample price and production MOQ separately. Ask for distinct sample and production lead times on the quoted drawing revision.

    Additional information

    Size:

    Interface:

    Thickness

    4 mm

    Structure

    G+G

    Touch IC

    microchip

    Custom Display Solutions

    Work with our engineering experts to create the perfect display for your application.
