24.3 inch Stretched LCD Display AA 597.6mm (H) x168.1mm (V)

Description

24.3″ Stretched LCD Monitors Features

This 24.3 inch Stretched LCD Display features an LED backlight with a brightness range of 300 to 500 cd/m² and a resolution of 1920 x 508 pixels, delivering clear visuals with a typical contrast ratio of 1200:1. It offers wide viewing angles of 89° in all directions and a fast response time of 8 ms (GtoG). Supporting 16.7 million colors (with options for 1.07 billion), the display is housed in a durable sheet metal frame, with an active area measuring 597.6 mm in height and 168.1 mm in vertical width. The overall dimensions are 639.3 mm x 213.2 mm x 49.5 mm, and while the shell color is black, customization options are available.

24.3″ Stretched LCD Monitors Application

The device is equipped with an A40 CPU, 1GB DDR3 memory, and 16GB of built-in storage, running on Android 7.1. It supports both Ethernet and Wi-Fi for network connectivity. The device is compatible with various video formats, including WMV, AVI, FLV, RM, RMVB, MPEG, TS, and MP4, as well as image formats such as BMP, JPEG, PNG, and GIF. It includes 2 USB 2.0 ports and features a 3.5mm headphone jack for audio output and input. For connectivity, it has 3 serial port sockets (including at least one RS232), and provides 1 RJ45 port for 100M adaptive Ethernet. Additionally, it supports 1080P output via its RS232 interface, making it a versatile solution for multimedia and connectivity needs.

24.3″ Stretched LCD Monitors Product Specifications

Diagonal Size	24.3″(Diagonal)
Pixel Number	1920*540 Pixels
Active Area	597.6mm (H) x168.1mm (V)
Outline Dimensions	639.3mm*213.2mm*49.5mm
CPU	A40
Memory	1GB DDR3
Operating System	Android 7.1
Network support	Ethernet, WIFI
Video Format Support	wmv、avi、flv、rm、rmvb、mpeg 、ts、mp4
Image Format Support	BMP、JPEG、PNG、GIF
USB	2 USB 2.0
Ethernet	3 serial port sockets (support at least RS232*1)
HDMI	1 RJ45, 100M adaptive Ethernet
RS232	1, support 1080P output
Touch	Without

24.3″ Stretched LCD Monitors Custom Solutions

Optimize Your Cable Solutions

Adjust the length, position, and pinout of your cables, or add additional connectors to enhance functionality. Get a customized cable solution designed to streamline your connections and ensure secure, reliable performance.

LCD Interface Customization

Select from a diverse range of interface options or consult our experts to find the ideal fit for your project. We can integrate HDMI, USB, SPI, VGA, and more into your display, helping you meet your design objectives efficiently.

Elevate User Experience with Touch Screen Technology

Enhance your user experience with either capacitive or resistive touch screen technology. We will customize the glass thickness and shape of the touch panel to ensure a perfect fit for your design requirements.

Custom Cover Glass

Equip your display with a custom-cut cover glass to boost durability and performance. Select from various thicknesses and opt for optical bonding to provide protection against moisture and debris, ensuring a long-lasting and reliable solution.
