3.5 inch TFT Displays with Glass Cover Lens

Description

3.5 inch TFT Displays Features

This 3.5 inch TFT Displays, with a resolution of 320×480 pixels, offers clear visuals within a compact form factor, featuring an active area of 48.96 mm x 73.44 mm. Its 80° viewing angles in all directions ensure consistent image quality, With a contrast ratio of 1000:1, and a 20,000-hour LED lifetime, it provides reliable performance in well-lit environments. Its wide operating temperature range of -20°C to 70°C, makes it suitable for both indoor and outdoor applications in industrial controls, portable devices, and consumer electronics.

3.5 inch TFT Displays with Cover Glass

The 3.5 inch TFT displays features a durable cover glass that enhances protection against impacts, scratches, and environmental factors, making it ideal for industrial applications, portable devices, and rugged electronics. This protective layer shields the display, ensuring resilience in harsh conditions such as rough handling, dust, or moisture exposure. Additionally, the cover glass improves optical clarity by reducing reflections and enhancing touch sensitivity, offering a more responsive and clear viewing experience. Overall, it ensures the display is suited for demanding environments while maintaining high visual performance.

3.5″ TFT-LCD Product Specifications

Model Number	91-03523-001
Size	3.5
Resolution	320*480
Outline Dimension	60.06*91.06*4.3
Active Area	48.96*73.44
Brightness(cd/m²)	300
Interface	MCU&RGB
View Direction	ALL
Operating Temperature	-20~70
Storage Temperature	-30~80
LED Lifetime	20000
Touchscreen Support	Without
Contrast Ratio	1000:1
Power Supply	3.3V
Display Type	Color LCD

3.5″ TFT LCD Custom Solutions

Optimize Your Cable Solutions

Adjust the length, position, and pinout of your cables, or add additional connectors to enhance functionality. Get a customized cable solution designed to streamline your connections and ensure secure, reliable performance.

LCD Interface Customization

Select from a diverse range of interface options or consult our experts to find the ideal fit for your project. We can integrate HDMI, USB, SPI, VGA, and more into your display, helping you meet your design objectives efficiently.

Elevate User Experience with Touch Screen Technology

Enhance your user experience with either capacitive or resistive touch screen technology. We will customize the glass thickness and shape of the touch panel to ensure a perfect fit for your design requirements.

Custom Cover Glass

Equip your display with a custom-cut cover glass to boost durability and performance. Select from various thicknesses and opt for optical bonding to provide protection against moisture and debris, ensuring a long-lasting and reliable solution.
