3.92 inch Square LCD Panel 320*320 MCU

Description

3.92″ Square LCD Panel Features

The TFT display offers a wide viewing angle of 85° in all directions, ensuring consistent image quality and color accuracy. With a brightness level of 400 cd/m², it provides excellent visibility for both indoor and outdoor use. The LED backlight is rated for 30,000 hours, enhancing reliability, while a contrast ratio of 1200 boosts clarity and vibrancy. Operating efficiently within a temperature range of -30°C to 80°C and utilizing a 40-pin MCU interface, this display module is versatile and suitable for a variety of applications.

3.92” Square LCD Panel with Wide Temperature

The 3.92-inch display screen lcd operates efficiently within a wide temperature range of -30°C to 80°C, ensuring reliable performance across various environments and applications. This versatility allows it to function effectively in extreme conditions, making it suitable for outdoor devices, industrial equipment, and automotive displays. Its design enhances reliability, reducing the likelihood of performance degradation or failure, which is crucial for mission-critical applications like medical devices and automation systems. Additionally, the module provides protection against harsh environmental conditions, maintaining operational clarity regardless of external temperatures.

3.92″ TFT-LCD Product Specifications

Model Number	90-39201-001
Size	3.92
Resolution	320*320
Outline Dimension	74.86*76.73*2.15
Active Area	71.14*69.82
Brightness(cd/m²)	400
Interface	MCU
View Direction	ALL
Operating Temperature	-30~80
Storage Temperature	-30~85
LED Lifetime	30000
Touchscreen Support	Witout
Contrast Ratio	1200:1
Power Supply	3.3V
Display Type	Color LCD

3.92″ TFT LCD Custom Solutions

Optimize Your Cable Solutions

Adjust the length, position, and pinout of your cables, or add additional connectors to enhance functionality. Get a customized cable solution designed to streamline your connections and ensure secure, reliable performance.

LCD Interface Customization

Select from a diverse range of interface options or consult our experts to find the ideal fit for your project. We can integrate HDMI, USB, SPI, VGA, and more into your display, helping you meet your design objectives efficiently.

Elevate User Experience with Touch Screen Technology

Enhance your user experience with either capacitive or resistive touch screen technology. We will customize the glass thickness and shape of the touch panel to ensure a perfect fit for your design requirements.

Custom Cover Glass

Equip your display with a custom-cut cover glass to boost durability and performance. Select from various thicknesses and opt for optical bonding to provide protection against moisture and debris, ensuring a long-lasting and reliable solution.
