3.95 Inch Square TFT LCD Display | 480×480 RGB Interface

SKU: DS20318
Size:

Resolution:

Interface:

Operating Temperature:

-20℃~70℃

Brightness(cd/m²):

450

Touchscreen Support:

Display Type:

3.95 inch square tft display, resolution 480*480, AA 71.86*70.18, brightness 250nits, -20~60 operation temperature, RGB interface, 85/85/85/85 wide temperature, 1200:1 high contrast ratio

$99.00
Request Volume Pricing







    Description

    3.95 inch square TFT LCD display Description

    This 3.95 inch square TFT LCD display features a 480×480 resolution and a balanced square format that supports flexible and intuitive user interface layouts. With an active area of 71.86 × 70.18 mm, the display is well suited for compact embedded designs and space-constrained applications.

    This 3.95-inch square TFT LCD is commonly used in smart home devices, handheld terminals, instrumentation, consumer electronics, and IoT interfaces, where compact size and reliable visual performance are required.

    Square TFT LCD Specifications

    Model Number TFT395BT029-B0
    Size 3.95
    Resolution 480*480
    Outline Dimension 84*84*3.7
    Active Area 71.86*70.18
    Brightness(cd/m²) 250
    Interface RGB
    View Direction IPS
    Operating Temperature -20~70
    Storage Temperature -30~80
    LED Lifetime 20000
    Touchscreen Support NO
    Contrast Ratio 1200:1
    Power Supply 3.3V
    Display Type Color LCD

    3.95" TFT Custom Solutions

    custom -01

    Optimize Your Cable Solutions

    Adjust the length, position, and pinout of your cables, or add additional connectors to enhance functionality. Get a customized cable solution designed to streamline your connections and ensure secure, reliable performance.

    SPI TFT LCD Display

    LCD Interface Customization

    Select from a diverse range of interface options or consult our experts to find the ideal fit for your project. We can integrate HDMI, USB, SPI, VGA, and more into your display, helping you meet your design objectives efficiently.

    touch add on

    Elevate User Experience with Touch Screen Technology

    Enhance your user experience with either capacitive or resistive touch screen technology. We will customize the glass thickness and shape of the touch panel to ensure a perfect fit for your design requirements.

    custom touch

    Custom Cover Glass

    Equip your display with a custom-cut cover glass to boost durability and performance. Select from various thicknesses and opt for optical bonding to provide protection against moisture and debris, ensuring a long-lasting and reliable solution.

    Additional information

    Size:

    Resolution:

    Interface:

    Operating Temperature:

    -20℃~70℃

    Brightness(cd/m²):

    450

    Touchscreen Support:

    Display Type:

    Custom Display Solutions

    Work with our engineering experts to create the perfect display for your application.
