69 inch Stretched LCD Screen Monitors 3840*1448 Brightness 500nits

COD: DS30020
Dimensioni:

Risoluzione:

Interfaccia:

, , , ,

Temperatura di esercizio:

-0℃~50℃

69 inch Stretched LCD Screen Monitors, offering resolution 3840*1448, Aspect Ratio 8:3,Brightness 500cd/m2, Interface with Audio/HDMI IN*2/USB/DP IN/DC IN, Optional Android motherboard

Richiesta di prezzi a volume







    Descrizione

    69 inch Stretched LCD screen monitors main features:

    • 178° ultra-wide viewing angle, 1200:1 high contrast ratio
    • High-definition picture quality, smooth playback
    • Long-strip display, can be hung horizontally or vertically
    • Sheet metal frame, protects screen from bumps
    • Brightness 500cd/m2 adjustable, appearance color customizable, driver motherboard solution customizable
     69 inch Stretched LCD Screen Monitors



    69 inch Streched LCD monitors Specification

    Display LCD Dimensioni dello schermo 69 inch
    Area attiva 1635.84*633.89(mm)
    Outline 1676*674*50(mm)
    Screen Type a-Si TFT-LCD
    Pixel Number 3840*1488
    Aspect Ratio 8 :3
    Luminance 500 cd/m2
    Rapporto di contrasto 1200:1
    Viewing Angle 89/89/89/89 (Typ.)(CR≥10)
    Profondità del colore 16.7M   68% NTSC
    Response 8 (Typ.)(G to G) ms
    Pixel Pitch 0.426×0.426  mm
    Mainboard CPU 9U13
    Ram -
    Flash -
    O/S -
    Interfaccia Audio/HDMI IN*2/USB/DP IN/DC IN
    Machine Appearance and Structure Sheet Metal
    Colore Black
    Peripheral WIFI/Speaker*2
    Power supply AC100~230V
    Power consumption ≦150W
    Temperatura di esercizio 0℃~50℃
    Temperatura di stoccaggio -20℃~60℃
    Installation method Wall hanging
    Peso netto 35Kg
    Corton size -
    Number of boxes 2PCS/Corton
    Corton weight 75Kg
    Drawing and photo 69 inch Streched LCD monitors

    69-Inch 3840 × 1448 Monitor FAQ

    Will this monitor fit with the cables and controls accessible?

    Use the 69-inch diagonal to shortlist monitors, then check the exact drawing for fit. Compare the case depth, mount or stand, cable bend and access to the controls against your setup. Test the actual cable exit before approving a tight installation.

    Industrial touch monitor selection guide

    Can my computer, media player, or controller run this monitor?

    The catalog mentions HDMI and DisplayPort. Send us your source model and OS or firmware version and ask us to confirm the role and wiring of each connection on the configuration you plan to order.

    How should I compare this monitor with another for my installation?

    Try your typical desktop, menu or signage layout on a 3840 × 1448 canvas before choosing a monitor. Compare readable text size at the intended distance, connector access and whether the installation needs a portable stand or fixed mounting. Use the listed 500 cd/m² to shortlist the display, then judge the assembled product with its final cover and ambient lighting.

    Can I specify the mount, ports, power adapter, or touch configuration?

    Share the enclosure or stand drawing, input sources, orientation and required ports. We can check available mounts, power and touch configurations and confirm which parts can be quoted together.

    What should I send for a monitor quote and sample schedule?

    Include the source ports and modes, mounting setup, accessories, quantities and required date. Ask for the hardware, accessories and any one-time setup itemized, with sample cost, production quantity breaks and separate delivery dates.

    Informazioni aggiuntive

    Dimensioni:

    Risoluzione:

    Interfaccia:

    , , , ,

    Temperatura di esercizio:

    -0℃~50℃
