15.6 inch 10 Point Capacitive Touch Panels with USB Interface, mxT1664T3 IC, 3mm G+G Glass

SKU: DS40047

Size 4	15.6 inch
Interface 4	USB
Thickness	3 mm
Structure	G+G
Touch IC	microchip

Capacitive Touch Panels, G+G structure, Unlock Collaboration: 10-User Multi-Touch, Sunlight-Readable, CE/FCC Certified, Idea for Industrial control systems

$99.00

Description

15.6 inch 10 Point Capacitive Touch Panels with USB Interface:

15.6-inch capacitive touch panel, engineered for seamless interactivity and industrial reliability. Designed to meet demanding commercial and industrial requirements, this panel combines cutting-edge technology with robust construction for superior user experiences.

Advanced Features:
✓ Enables smooth, responsive multi-user interaction for collaborative workflows or advanced applications
✓ Features a 3mm tempered glass cover lens for enhanced scratch resistance, impact protection, and optical clarity. Ideal for high-traffic public or industrial settings.
✓ Rated for 50 million+ touch cycles and operates reliably in temperatures from -20°C to 70°C
✓ Custom firmware and mounting solutions available upon request

15.6 inch 10 Point Capacitive Touch Panels with USB Interface
Construction	Cover Glass	Thickness: 2.8 mm±0.05mm
	OCR	Thickness: 0.2mm ± 0.05mm
	ITO Glass	Double side ITO glass: Thickness: 0.7mm ± 0.05mm
Machanical Characteristics	Touch size	15.6 inch
	Outer Dimension	381.4*241.6
	View Area	345.50*194.80
	Sensor Area	361.80*213.90
	Cover Thickness	2.8
	Number of Touch	10
	Interface	USB
	Controller	Microchip
