Description
15.6 inch MIPI LCD display with touch
This 15.6 inch MIPI LCD display is designed specifically for medical applications, offering Full HD resolution (1920×1080) and integrated capacitive touch panel (PCAP).
With stable performance, high clarity, and reliable touch response, it is ideal for use in medical devices such as patient monitoring systems, diagnostic equipment, and healthcare terminals.
Key Features
Full HD Resolution (1920×1080)
Delivers sharp image quality for precise medical data visualization
15.6 Inch Standard Size
Widely compatible with medical display system integration
MIPI Interface
High-speed signal transmission with low power consumption
Capacitive Touch (PCAP)
Smooth, accurate multi-touch interaction for medical environments
Reliable Performance for Medical Use
Stable operation suitable for continuous and critical applications
15.6 Inch LCD Display Specifications
| Model Number | ZC-156004-1021 |
|---|---|
| Size | 15.6 inch |
| Resolution | 1920*1080 |
| Outline Dimension | 445*391*14.92 |
| Active Area | 344.16*193.59 |
| Brightness(cd/m²) | 400 |
| Interface | MIPI |
| View Direction | IPS |
| Operating Temperature | -20~70 |
| Storage Temperature | -30~80 |
| LED Lifetime | 20000 |
| Touchscreen Support | With capacitive touch |
| Contrast Ratio | 1000:1 |
| Power Supply | 3.3V |
| Display Type | Color LCD |
15.6" TFT Custom Solutions
Optimize Your Cable Solutions
Adjust the length, position, and pinout of your cables, or add additional connectors to enhance functionality. Get a customized cable solution designed to streamline your connections and ensure secure, reliable performance.
LCD Interface Customization
Select from a diverse range of interface options or consult our experts to find the ideal fit for your project. We can integrate HDMI, USB, SPI, VGA, and more into your display, helping you meet your design objectives efficiently.
Elevate User Experience with Touch Screen Technology
Enhance your user experience with either capacitive or resistive touch screen technology. We will customize the glass thickness and shape of the touch panel to ensure a perfect fit for your design requirements.
Custom Cover Glass
Equip your display with a custom-cut cover glass to boost durability and performance. Select from various thicknesses and opt for optical bonding to provide protection against moisture and debris, ensuring a long-lasting and reliable solution.
