Description
3.4 inch square LCD display Description
This 3.4 inch square LCD display features a 480×480 resolution and an IPS panel that delivers consistent color performance and a wide 80/80/80/80 viewing angle.
With a MIPI interface, the display supports fast data transmission and is suitable for compact and performance-oriented embedded systems.
This 3.4-inch square LCD is commonly used in smart control panels, handheld devices, medical equipment, IoT terminals, instrumentation, and consumer electronics, where stable performance and compact size are required.
3.4 inch square LCD display Specifications
| Model Number | HYS-034BM5S2P002 |
|---|---|
| Size | 3.4 |
| Resolution | 480*480 |
| Outline Dimension | 65.72*69.64*2.54 |
| Active Area | 60.48*60.48 |
| Brightness(cd/m²) | 450 |
| Interface | MIPI |
| View Direction | IPS |
| Operating Temperature | -20~70 |
| Storage Temperature | -30~80 |
| LED Lifetime | 20000 |
| Touchscreen Support | NO |
| Contrast Ratio | 1000:1 |
| Power Supply | 3.3V |
| Display Type | Color LCD |
3.4" TFT Custom Solutions
Optimize Your Cable Solutions
Adjust the length, position, and pinout of your cables, or add additional connectors to enhance functionality. Get a customized cable solution designed to streamline your connections and ensure secure, reliable performance.
LCD Interface Customization
Select from a diverse range of interface options or consult our experts to find the ideal fit for your project. We can integrate HDMI, USB, SPI, VGA, and more into your display, helping you meet your design objectives efficiently.
Elevate User Experience with Touch Screen Technology
Enhance your user experience with either capacitive or resistive touch screen technology. We will customize the glass thickness and shape of the touch panel to ensure a perfect fit for your design requirements.
Custom Cover Glass
Equip your display with a custom-cut cover glass to boost durability and performance. Select from various thicknesses and opt for optical bonding to provide protection against moisture and debris, ensuring a long-lasting and reliable solution.
