8 inch Display Panel 800×600 IPS LVDS High Bright LCD

SKU: DS20293
Size:

Resolution:

Interface:

Operating Temperature:

-10℃~50℃

Brightness(cd/m²):

700

Touchscreen Support:

Display Type:

8 inch Display Panel , Resolution 800×600, with 700 nits High brightness, IPS wide viewing angle, Ideal for HMI and consumer electrical projects

$99.00
Request Volume Pricing







    Description

    8 inch Display Panel Description

    Featuring an 800×600 resolution, this display is specifically designed for compatibility with legacy driver boards, making it an ideal retrofit solution for older systems. With 700-nit brightness and IPS full-view technology, it delivers consistent visuals across 178° angles, ensuring clear monitoring in security setups or consumer electronics.
    Key Specs:
    • LVDS interface for seamless integration with traditional and modern controllers
    • 700-nit luminance for indoor clarity without glare
    • IPS panel eliminates color distortion from any viewing angle
    Target Applications:
    • Security monitoring systems (CCTV consoles, access control panels)
    • Consumer electronics (portable media players, digital signage kiosks)
    • Retrofit projects for industrial equipment requiring legacy driver support
    Engineered to bridge old-school hardware with modern display standards, this panel balances compatibility with performance for cost-effective upgrades.
    Below the basic parameters for it, Tailor the interface (LVDS/RGB/MIPI), brightness, dimensions, and touch solutions (capacitive/resistive) to seamlessly integrate into your device—engineered for hassle-free system integration.

    8″ TFT Display Specifications

    Model Number HS08007BEP50-27A
    Size 8
    Resolution 1024*768
    Outline Dimension 183*141*3.5
    Active Area 162.05*121.54
    Brightness(cd/m²) 700
    Interface LVDS
    View Direction ALL
    Operating Temperature -10~50
    Storage Temperature -20~60
    LED Lifetime 20000
    Touchscreen Support No
    Contrast Ratio 1000:1
    Power Supply 3.3V
    Display Type Color LCD

    8″ TFT LCD Custom Solutions

    Optimize Your Cable Solutions

    Adjust the length, position, and pinout of your cables, or add additional connectors to enhance functionality. Get a customized cable solution designed to streamline your connections and ensure secure, reliable performance.

    LCD Interface Customization

    Select from a diverse range of interface options or consult our experts to find the ideal fit for your project. We can integrate HDMI, USB, SPI, VGA, and more into your display, helping you meet your design objectives efficiently.

    Elevate User Experience with Touch Screen Technology

    Enhance your user experience with either capacitive or resistive touch screen technology. We will customize the glass thickness and shape of the touch panel to ensure a perfect fit for your design requirements.

    custom touch

    Custom Cover Glass

    Equip your display with a custom-cut cover glass to boost durability and performance. Select from various thicknesses and opt for optical bonding to provide protection against moisture and debris, ensuring a long-lasting and reliable solution.

    Additional information

    Size:

    Resolution:

    Interface:

    Operating Temperature:

    -10℃~50℃

    Brightness(cd/m²):

    700

    Touchscreen Support:

    Display Type:
