Description
M118AW41 R0 General Desription
The IVO M118AW41 R0 is an 11.8-inch IPS LCD with 1200×1600 resolution, delivering ultra-sharp visuals and 85° wide viewing angles for consistent color accuracy. Boasting 750 cd/m² brightness and a 1000:1 contrast ratio, it excels in direct sunlight or low-light environments. Engineered for extreme conditions, it operates reliably from -30°C to 85°C and survives storage at -40°C~85°C. The LVDS interface ensures stable signal transmission for mission-critical systems, while the 3.3V power supply enhances energy efficiency. With a 30,000-hour LED lifespan and rugged 10.6mm profile (194×258.55mm outline), it’s built for 24/7 reliability in harsh industrial, medical, and outdoor applications.
Application & Performanc
Ideal for high-precision medical imaging, aviation control panels, and outdoor digital signage, the IVO M118AW41 R0 thrives in extreme environments. Its ultra-wide temperature range supports Arctic oil rig monitors, desert solar farms, and freezer warehouse systems. The 750cd/m² brightness ensures readability under intense sunlight for railway dashboards, EV charging stations, and construction site displays. The IPS panel’s color consistency benefits laboratory equipment, military HUDs, and marine navigation systems. With shock-resistant construction and a 30k-hour lifespan, it reduces downtime in mining, logistics, and energy sectors. Compact yet robust, it integrates into portable diagnostic tools, smart factory robots, and rugged IoT edge devices.
11.8" Product Specifications
| Diagonal Size11.8 | inch |
|---|---|
| Pixel Number | 1200×1600 |
| Luminance | 750 |
| Module Size | 194×258.55×10.6 |
| Active Area | 180×240 |
| Viewing Direction | IPS |
| View Angle(U/D/R/L) | 85/85/85/85 |
| Interface | LVDS |
| Contrast Ratio | 1000 : 1 |
| Operating Temperature | -30 ~ 85 °C |
| Storage Temperature | -40 ~ 85 °C |
| LED Lifetime | 30000 |
| Power Supply | 3.3V |
| Touchscreen Support | Without |
| Display Type | Color TFT |
IVO LCD Display Custom Solutions
Optimize Your Cable Solutions
Adjust the length, position, and pinout of your cables, or add additional connectors to enhance functionality. Get a customized cable solution designed to streamline your connections and ensure secure, reliable performance.
PCB Modifications
Choose from a variety of variations in PCB shape, size, pin and component layout to make it fully suitable for your application.
Elevate User Experience with Touch Screen Technology
Enhance your user experience with either capacitive or resistive touch screen technology. We will customize the glass thickness and shape of the touch panel to ensure a perfect fit for your design requirements.
Custom Cover Glass
Equip your display with a custom-cut cover glass to boost durability and performance. Select from various thicknesses and opt for optical bonding to provide protection against moisture and debris, ensuring a long-lasting and reliable solution.
