8.4-inch IVO M084GNS1 R1 TFT LCD showing a colorful demo image

IVO M084GNS1 R1 8.4'' TFT LCD Panel 800x600 LVDS 80/80/80/80 TN 50K Hrs -20℃~70℃

SKU: DS50090

Size:	8.4 inch
Resolution:	800*600
Interface:	LVDS
Touchscreen Support:	NO
Display Type:	Color LCD
Brightness(cd/m²):	350
Operating Temperature:	-20℃~70℃

Resources: abcd test efgh test

IVO M084GNS1 R1: 8.4'' TN LCD with 800x600 LVDS, -20℃~70℃ range, 50K lifespan. Ideal for industrial, medical & outdoor applications. RoHS compliant

Description

IVO m084gns1 r1 General Description

The IVO M084GNS1 R1 is an 8.4 inch TFT LCD panel engineered for industrial, commercial, and embedded applications requiring high durability and stable performance. With an 800x600 resolution (SVGA), this TN (Twisted Nematic) panel delivers sharp visuals and supports 80/80/80/80 viewing angles (horizontal/vertical, CR≥10), ensuring readability across diverse lighting conditions.

Key Features:

High Compatibility: LVDS interface ensures seamless integration with industrial control systems, medical devices, POS terminals, and automation equipment.
Extended Lifespan: Rated for 50,000 hours of continuous operation, minimizing downtime and maintenance costs.
Wide Temperature Range: Operates reliably in extreme environments (-20℃ to 70℃), ideal for outdoor or harsh industrial settings.
Robust Construction: TN panel technology balances cost-efficiency with performance, resistant to flicker and signal interference.
Standard Specifications: 4:3 aspect ratio, 6/5/6/6-bit color depth, and 300:1 contrast ratio for clear image reproduction.

8.4" TFT-LCD Product Specifications

Model Number	M084GNS1 R1
Size	8.4
Resolution	800(RGB)×600
Outline Dimension	203×142.5×6.2
Active Area	170.4×127.8
Brightness(cd/m²)	350
Interface	LVDS 20pin
View Direction	TN
Operating Temperature	-20~70
Storage Temperature	-30~80
LED Lifetime	50000
Touchscreen Support	Without
Contrast Ratio	600:1
Power Supply	3.3V
Display Type	Color LCD

8.4" TFT LCD Custom Solutions

Optimize Your Cable Solutions

Adjust the length, position, and pinout of your cables, or add additional connectors to enhance functionality. Get a customized cable solution designed to streamline your connections and ensure secure, reliable performance.

PCB Modifications

Choose from a variety of variations in PCB shape, size, pin and component layout to make it fully suitable for your application.

Elevate User Experience with Touch Screen Technology

Enhance your user experience with either capacitive or resistive touch screen technology. We will customize the glass thickness and shape of the touch panel to ensure a perfect fit for your design requirements.

Custom Cover Glass

Equip your display with a custom-cut cover glass to boost durability and performance. Select from various thicknesses and opt for optical bonding to provide protection against moisture and debris, ensuring a long-lasting and reliable solution.

DS50090 FAQ

Can I use DS50090 if my original label has a different model suffix?

Use M084GNS1 R1 as the listed panel reference, then compare the full part number and revision on the label. Send us photos of the old label and connector side. Compare the mounting holes, thickness, connector location and visible opening on both drawings before ordering.

Can I keep my existing LVDS cable and controller with DS50090?

For the listed LVDS interface, match the connector pinout, channel count, data mapping and panel supply before applying power. Check the existing backlight supply and enable/dim signals as well. Two connectors that look identical can carry different signals.

Will replacing my current panel with DS50090 require a change to the equipment software?

Try your service menus and startup graphics on a 800 × 600 canvas before approving the replacement. Compare the actual native timing and display orientation with the old module. Price any cable, firmware and mounting changes before committing to a substitute.

How do I check whether DS50090 will look right behind the original cover?

Use the listed 350 cd/m² to shortlist the display, then judge the assembled product with its final cover and ambient lighting. Test cold boot, restart, brightness control and a full diagnostic image. Use the listed −20 °C to +70 °C operating range to plan cold starts and hot running tests, with temperature measured at the panel. Check that the cable clears the frame with the equipment closed.

What should I order if my equipment uses touch with the LCD that DS50090 would replace?

The listed configuration has no touch. If your design needs it, confirm the overlay, controller and cable as separate items in the quote. Give us the equipment model, approved panel and touch revisions where applicable, quantity and required date. Ask for the quoted revision and how a substitution would be handled.

Additional information

Size:	8.4 inch
Resolution:	800*600
Interface:	LVDS
Touchscreen Support:	NO
Display Type:	Color LCD
Brightness(cd/m²):	350
Operating Temperature:	-20℃~70℃
